Filler Elements Colours All filler elements are uncoloured (natural). Sheath Colour The inner and outer sheath colour is black. Sheath Marking The outer sheath is marked in 1 meter intervals as follows: DRAKA   year of manufacture   number x SMF   length marking in meter Packing Wooden drums with protection. Delivery Lengths Standard delivery lengths are 2 km, 4 km, 6 km with a tolerance of  - 1% / + 3% Fiber Colours No. Colour 1 blue 2 orange 3 green 4 brown 5 grey 6 white 7 red 8 black 9 yellow 10 violet 11 pink 12 turquoise Identification and Packing Buffer Tube Colours  No. Colour 1 blue 2 orange 3 green 4 brown 5 grey 6 white 7 red 8 black 9 yellow 10 violet 11 pink 12 turquoise No. of Fibers 12 24 36 48 72 96 144 Design 1x12 2x12 3x12 4x12 6x12 8x12 12x12 Loose Tube / Filler - Ø mm 2.5 CSM – Ø mm 2.1 2.6 3.0 3.5 CSM-Oversheathing - Ø mm - - 4.2 7.5 Outer Sheath Thickness mm 1.5 Cable Diameter mm 13.5 14.0 16.0 19.0 Cable Weight kg / km 190 205 255 355 Temperature Range Transportation & Storage: - 40 to + 70°C Minimum Bending Radius Installation: - 30 to + 60°C Under Maximum Tension: 20 x Cable-Ø Operation: - 40 to + 70°C Without Tension: 10 x Cable-Ø Configuration Application Test  Test Standard Specified Value Acceptance Criteria Max. Installation Tension  IEC 60794–1-2-E1  3 W [N], min. 5000 N Δα reversible, fiber strain ≤ 0.33% Max. Operation Tension IEC 60794–1–2-E1 1.5 W [N], min. 2500 N no fiber strain,  Δα ≤ 0.05 dB Crush  IEC 60794–1–2-E3 5000 N / 100 mm, max. 15 min Δα ≤ 0.05 dB, no damage Impact IEC 60794–1–2-E4 40 Nm, 3 impacts, R= 300 mm Δα ≤ 0.05 dB after the test Torsion IEC 60794–1–2-E7 100N, +/- 180°, 10 cycles Δα ≤ 0.05 dB, no damage Repeated Bending IEC 60794–1–2-E6 R=20x D, 100 N, 35 cycles no damage Cable Bend IEC 60794–1–2-E11 R=20x D, 4 turns, 3 cycles Δα ≤ 0.05 dB, no damage Temperature Cycling IEC 60794–1–2-F1 -40°C to +70°C Δα ≤ 0.05 dB/km Water Penetration IEC 60794–1–2-F5B sample=3m, water column=1m no water leakage in 24h Main Mechanical and Environmental Characteristics All optical measurements at 1550 nm. Fire Performance Premium range PreLT 10 – Indoor, dielectric armoured, double HFFR sheath Cable Design Acc. to IEC 60794-3-10 Loose Tube Fiber Optic Cable  -  Dielectric Armoured  -  Dry Core  -   Double HFFR Sheath Central Strength Member (CSM):  glass fiber reinforced plastic rod (FRP), with plastic oversheathing when needed. Loose Tube:  thermoplastic material, containing up to 12 fibers and filled with a suitable water tightness compound. Filler Elements:  thermoplastic rods, where needed. Stranding:  loose tubes (and fillers), SZ stranded around the CSM. Longitudinal Water Tightness:  dry core with water swellable elements. Inner Sheath:  HFFR. 2 ripcords. Peripheral Strength Elements and Non Metallic Armour:  glass yarns. 2 Ripcords:  Underneath sheath Outer Sheath: HFFR. Test  Test Standard Specified Value Acceptance Criteria Single Cable Test IEC 60332-1 unburnt cable length  50 mm Smoke Density IEC 61034 transmission of light 60 % Halogen Content IEC 60754-1 halogen content  0.5 % Corrosivity of Smoke Gases IEC 60754-2 pH-value ≥ 4.3 Conductivity of Smoke Gases IEC 60754-2 conductivity  10  µS 19 2  Value Innovation is a way of looking at the world. What we can do to help our customers do more, make more, save more and achieve more? A lot. We help our customers to stay ahead. By combining market insight with technological know-how and building strong, long-lasting relationships, we add value to their business with advanced communication solutions and services that are designed  to last. No matter how complex your challenge, we have a product or solution that will do more than meet your needs. And if for some  reason we don’t, we’ll make it for you.  New applications, breakthrough cables,  custom connectors or complete network  designs – it’s all part of what we call  Value Innovation, and it’s what drives us. Value Innovation

4  Fiber Optics is our business More and more telecom operators find themselves needing to upgrade or extend their optical fiber networks. With our family of Regular and Premium optical fiber cables, we offer the options you need. Optical fiber cable choices We offer 12 cable types in two ranges:  Regular and Premium. The basic cable is  the LT1, which comes in Regular (Reg) and  Premium (Pre) versions. There are four  cables in the Regular range, and eight in  the Premium range. The arrows explain  the changes we make to deliver specific  performance benefits. The result of this has been the development of a family of Regular and Premium ready-to-go optical fiber cables that meet the most common needs. Cables for indoor or outdoor use. For direct-buried or duct installation.  In armoured and non-armoured versions.  And if you need something really advanced, we have that too. Fully dielectric cables? Extra-tough sheathing? Breakthrough high- performance yarns? We offer all these as well.  Our experience tells us that for most situations, our ready-to-go cables are often all you need. And they are available right now. Draka Communications is Europe’s largest manufacturer of optical fiber and optical fiber cables. We have production facilities and offices across the continent. And every day, we talk with telecom network operators about their markets, their challenges and their needs, so that we understand them too.

5 Draka optical fiber Besides producing cutting-edge optical cables, Draka Communications also has its own fiber-making division and is a leader in advanced production techniques. Draka Communications Optical Fiber is com- mitted to developing solutions that not only answer today's bandwidth requirements but also anticipate the needs and technologies of tomorrow.  Unique processes  Thanks to unique in-house processes like PCVD (Plasma-Activated Chemical Vapour Deposition) and APVD (Advanced Plasma Vapour Deposition), and a strong commit- ment to R&D, Draka Communications Optical Fiber has everything needed to provide  customers with the right product for their needs. Draka Communications Optical Fiber products include Single-mode fibers, Multimode fibers and Specialty fibers.  For more information, please visit our  website www.drakafiber.com. Global presence Draka Communications Optical Fiber operates worldwide, so we’re where our customers are. In addition to various research and development facilities and local sales offices, we have six factories in the Netherlands, France, the United States, China, Japan and Brazil, covering Europe, Asia and the Americas respectively. Draka single mode optical fiber All Draka optical fiber is made of a high grade doped silica core surrounded by a  silica cladding. This is finished with a dual layer, UV-cured acrylate coating. Standards and Norms G652D IEC / EN 60793-2-50 Category B1.3 ITU-T Recommendation G.652. D and C, B, A IEEE 802.3 – 2002 incl. 802.3ae EN 50 173-1: 2007 Cat. OS1 and OS2 ISO / IEC 11801: 2002 Cat. OS1 ISO / IEC 24702: 2006 Cat. OS2 and OS1 Attenuation ( cabled fibers) IEC 60793-1-40 1310 nm 0.35 dB/km 1383 nm 0.35 dB/km 1460 nm 0.26 dB/km 1550 nm 0.22 dB/km 1625 nm 0.24 dB/km Max. attenuation change in interval 1285-1330 nm (ref. 1310 nm) 0.03 dB/km Max. attenuation change in interval 1525-1575 nm (ref. 1550 nm)  0.02 dB/km Point discontinuity at 1310 and 1550 nm   ± 0.05 dB/km Group index of refraction IEC 60793-1-22 Effective group index at 1310 nm 1.467 Effective group index at 1550 and 1625 nm 1.468 Fiber properties according to IEC IEC 60793-1 Mode field diameter at 1310 nm IEC/EN 60793-1-45 µm 9.0  ± 0.4 Mode field diameter at 1550 nm IEC/EN 60793-1-45 µm 10.1  ± 0.5 Chromatic dispersion coefficient: IEC/EN 60793-1-42 Interval 1285 – 1310 nm ps/km•nm  | 3 | At 1550 nm ps/km•nm  18.0 At 1625 nm ps/km•nm  22.0 Zero dispersion wavelength,  λ0 Nm Zero dispersion slope ps/(nm2•km) 0.090 Cut-off wavelength IEC/EN 60793-1-44 λcc nm 1260 Polarisation mode dispersion  IEC/EN 60793-1-48 ps/√km 0.1 (PMD) coefficient, max. uncabledPMDQ Link Design Value(calculated with Q=0.01%) IEC/EN 60794-3 ps/√km 0.06 Fiber curl radius IEC/EN 60793-1-34 m 4 Strip force (peak) IEC/EN 60793-1-32 N 1.2 Fpeaks.strip 8.9 Dynamic fatigue resistance,aged and unaged (Nd) IEC/EN 60793-1-33 20 Static fatigue resistance (Ns) IEC/EN 60793-1-33 23 Cladding diameter, Cladding non-circularity, Core - cladding concentricity error, Primary coating non circularity, Primary coating - cladding concentricity error, Macrobending loss, Proof stress level, all comply to the international standards.

Regular optical fiber cables Each cable in our Regular range has been designed with a focus on achieving  an economic trade-off between cost and performance, ensuring an optimal  fit-for-purpose cable that more than meets ‘standard’ requirements. Core Stranded Loose Tube Cables Sheath Options Fiber c ount o f C able Fiber c ount per T ube B u ff er / T ube Diame te r Minimum T emp . (0 ,0 5 dB /k m ) T ensile S tr ength T hickne s s  She ath Out door , Non Armour ed Out door , Armour ed, Single She ath Out door , Armour ed, Double She ath In- / Out door , single HFFR she a th Regular (RegLT) Qty 12 24 36 48 72 96 144 Qty 12 12 12 12 12 12 12 (mm) 2,2 2,2 2,2 2,2 2,2 2,2 2,2 (oC) -3º -3º -3º -3º -3º -3º -3º (N ) 1,5 W/1500 1,5 W/1500 1,5 W/1500 1,5 W/1500 1,5 W/1500 1,5 W/1500 1,5 W/1500 ( mm ) 1,3 1,3 1,3 1,3 1,3 1,3 1,3 (RegLT 1) OD (mm) 9,5 9,5 9,5 9,5 9,5 11,0 14,0 (RegLT 2) OD (mm) 11,5 11,5 11,5 11,5 11,5 13,0 16,5 (RegLT 3) OD (mm) 13,0 13,0 13,0 13,0 13,0 14,0 17,5 (RegLT 6) OD (mm) 9,5 9,5 9,5 9,5 9,5 11,0 14,0 Our Regular range comprises four cable choices: one non-armoured dielectric; two armoured cables (with one or two sheaths); and one in-/outdoor type, sheathed to out- door-use standard. All our Regular cables are available  immediately from stock. Our logistical  support includes on-site, just-in-time  deliveries, tailored cable lengths and  cable-drum pick up. 6

Regular range RegLT 1 – Outdoor, non armoured No. of Fibers 12 24 36 48 72 96 144 Design 1x12 2x12 3x12 4x12 6x12 8x12 12x12 Loose Tube / Filler - Ø mm 2.2 2.2 2.2 2.2 2.2 2.2 2.2 CSM – Ø mm 2.3 2.3 2.3 2.3 2.3 3.0 3.5 CSM-Oversheathing  -  Ø mm - - - - - 3.7 6.7 Outer Sheath Thickness mm 1.3 1.3 1.3 1.3 1.3 1.3 1.3 Cable Diameter mm 9.5 9.5 9.5 9.5 9.5 11.0 14.0 Cable Weight kg / km 70 70 70 70 70 95 155 Temperature Range Transportation & Storage: - 40 to + 70°C Minimum Bending Radius Installation: - 30 to + 60°C Under Maximum Tension: 20 x Cable-Ø Operation: - 30 to + 70°C Without Tension: 10 x Cable-Ø Cable Design Acc. to IEC 60794-3-10 Loose Tube Fiber Optic Cable   -  Non Armoured  -  Dielectric  -  Dry Core Central Strength Member (CSM):  glass fiber reinforced plastic rod (FRP), with plastic oversheathing when needed. Loose Tube:  thermoplastic material, containing 12 fibers and filled with a suitable water tightness compound. Filler Elements: thermoplastic rods, where needed. Stranding:  loose tubes (and fillers), SZ stranded around the CSM. Longitudinal Water Tightness: dry core with water swellable elements. 2 Ripcords:  Underneath sheath. Outer Sheath: LDPE. Configuration Application Test  Test Standard Specified Value Acceptance Criteria Max. Installation Tension  IEC 60794–1-2-E1  1.5 W [N], min. 1500 N Δα reversible, fiber strain ≤ 0.33% Max. Operation Tension IEC 60794–1–2-E1 0.5 W [N], min. 500 N no fiber strain,  Δα ≤ 0.05 dB Crush  IEC 60794–1–2-E3 2000 N / 100 mm, max. 15 min Δα ≤ 0.05 dB, no damage Impact IEC 60794–1–2-E4 12 Nm, 3 impacts, R= 300 mm Δα ≤ 0.05 dB after the test Torsion IEC 60794–1–2-E7 100N, +/- 180°, 10 cycles Δα ≤ 0.05 dB, no damage Repeated Bending IEC 60794–1–2-E6 R=20x D, 100 N, 35 cycles no damage Cable Bend IEC 60794–1–2-E11 R=20x D, 4 turns, 3 cycles Δα ≤ 0.05 dB, no damage Temperature Cycling IEC 60794–1–2-F1 -30°C to +70°C Δα ≤ 0.05 dB/km Water Penetration IEC 60794–1–2-F5B sample=3m, water column=1m no water leakage in 24h Main Mechanical and Environmental Characteristics All optical measurements at 1550 nm. 7

Regular range RegLT 2 – Outdoor, armoured, single sheath No. of Fibers 12 24 36 48 72 96 144 Design 1x12 2x12 3x12 4x12 6x12 8x12 12x12 Loose Tube / Filler - Ø mm 2.2 2.2 2.2 2.2 2.2 2.2 2.2 CSM – Ø mm 2.3 2.3 2.3 2.3 2.3 3.0 3.5 CSM-Oversheathing  -  Ø mm - - - - - 3.7 6.7 Outer Sheath Thickness mm 1.3 1.3 1.3 1.3 1.3 1.3 1.3 Cable Diameter mm 11.5 11.5 11.5 11.5 11.5 13.0 16.5 Cable Weight kg / km 130 130 130 130 130 155 240 Temperature Range Transportation & Storage: - 40 to + 70°C Minimum Bending Radius Installation: - 30 to + 60°C Under Maximum Tension: 20 x Cable-Ø Operation: - 30 to + 70°C Without Tension: 15 x Cable-Ø Cable Design Acc. to IEC 60794-3-10 Loose Tube Fiber Optic Cable  -  Armoured  -  Dry Core  -  Single Central Strength Member (CSM): glass fiber reinforced plastic rod (FRP), with plastic oversheathing when needed. Loose Tube:  thermoplastic material, containing 12 fibers and filled with a suitable water tightness compound. Filler Elements: thermoplastic rods, where needed. Stranding: loose tubes (and fillers), SZ stranded around the CSM. Longitudinal Water Tightness: dry core with water swellable elements. Armour:  both sides copolymer coated corrugated steel tape with overlap, water swellable elements.  Steel thickness:  0.15 mm.  2 Ripcords:  Underneath sheath. Outer Sheath: HDPE. Application Test  Test Standard Specified Value Acceptance Criteria Max. Installation Tension  IEC 60794–1-2-E1  1.5 W [N], min. 1500 N Δα reversible, fiber strain ≤ 0.33% Max. Operation Tension IEC 60794–1–2-E1 0.5 W [N], min. 700 N no fiber strain,  Δα ≤ 0.05 dB Crush  IEC 60794–1–2-E3 3000 N / 100 mm, max. 15 min Δα ≤ 0.05 dB, no damage Impact IEC 60794–1–2-E4 25 Nm, 3 impacts, R= 300 mm Δα ≤ 0.05 dB after the test Torsion IEC 60794–1–2-E7 100N, +/- 180°, 10 cycles Δα ≤ 0.05 dB, no damage Repeated Bending IEC 60794–1–2-E6 R=20x D, 100 N, 35 cycles no damage Cable Bend IEC 60794–1–2-E11 R=20x D, 4 turns, 3 cycles Δα ≤ 0.05 dB, no damage Temperature Cycling IEC 60794–1–2-F1 -30°C to +70°C Δα ≤ 0.05 dB/km Water Penetration IEC 60794–1–2-F5B sample=3m, water column=1m no water leakage in 24h Main Mechanical and Environmental Characteristics All optical measurements at 1550 nm. Configuration 8

Configuration Regular range RegLT 3 – Outdoor, armoured, double sheath No. of Fibers 12 24 36 48 72 96 144 Design 1x12 2x12 3x12 4x12 6x12 8x12 12x12 Loose Tube / Filler - Ø mm 2.2 2.2 2.2 2.2 2.2 2.2 2.2 CSM – Ø mm 2.3 2.3 2.3 2.3 2.3 3.0 3.5 CSM-Oversheathing  -  Ø mm - - - - - 3.7 6.7 Outer Sheath Thickness mm 1.3 1.3 1.3 1.3 1.3 1.3 1.3 Cable Diameter mm 13.0 13.0 13.0 13.0 13.0 14.0 17.5 Cable Weight kg / km 155 155 155 155 155 190 275 Temperature Range Transportation & Storage: - 40 to + 70°C Minimum Bending Radius Installation: - 30 to + 60°C Under Maximum Tension: 20 x Cable-Ø Operation: - 30 to + 70°C Without Tension: 15 x Cable-Ø Cable Design Acc. to IEC 60794-3-10 Loose Tube Fiber Optic Cable  -  Armoured  -  Dry Core  -  Double Sheath Central Strength Member (CSM):  glass fiber reinforced plastic rod (FRP), with plastic oversheathing when needed. Loose Tube:  thermoplastic material, containing 12 fibers and filled with a suitable water tightness compound. Filler Elements: thermoplastic rods, where needed. Stranding: loose tubes (and fillers), SZ stranded around the CSM. Longitudinal Water Tightness: dry core with water swellable elements. Inner Sheath: PE, 2 ripcord. Armour: both sides copolymer coated corrugated steel tape with overlap, water swellable elements.  Steel thickness: 0.15 mm. 2 Ripcords:  Underneath sheath. Outer Sheath: HDPE. Application Test  Test Standard Specified Value Acceptance Criteria Max. Installation Tension  IEC 60794–1-2-E1  1.5 W [N], min. 1500 N Δα reversible, fiber strain ≤ 0.33% Max. Operation Tension IEC 60794–1–2-E1 0.5 W [N], min. 700 N no fiber strain,  Δα ≤ 0.05 dB Crush  IEC 60794–1–2-E3 4000 N / 100 mm, max. 15 min Δα ≤ 0.05 dB, no damage Impact IEC 60794–1–2-E4 30 Nm, 3 impacts, R= 300 mm Δα ≤ 0.05 dB after the test Torsion IEC 60794–1–2-E7 100N, +/- 180°, 10 cycles Δα ≤ 0.05 dB, no damage Repeated Bending IEC 60794–1–2-E6 R=20x D, 100 N, 35 cycles no damage Cable Bend IEC 60794–1–2-E11 R=20x D, 4 turns, 3 cycles Δα ≤ 0.05 dB, no damage Temperature Cycling IEC 60794–1–2-F1 -30°C to +70°C Δα ≤ 0.05 dB/km Water Penetration IEC 60794–1–2-F5B Sample=3m, water column=1m no water leakage in 24h Main Mechanical and Environmental Characteristics All optical measurements at 1550 nm. 9

Configuration Regular range RegLT 6 – Indoor / Outdoor, single HFFR sheath No. of Fibers 12 24 36 48 72 96 144 Design 1x12 2x12 3x12 4x12 6x12 8x12 12x12 Loose Tube / Filler - Ø mm 2.2 2.2 2.2 2.2 2.2 2.2 2.2 CSM – Ø mm 2.3 2.3 2.3 2.3 2.3 3.0 3.5 CSM-Oversheathing  -  Ø mm - - - - - 3.7 6.7 Outer Sheath Thickness mm 1.3 1.3 1.3 1.3 1.3 1.3 1.3 Cable Diameter mm 9.5 9.5 9.5 9.5 9.5 11.0 14.0 Cable Weight kg / km 90 90 90 90 90 115 175 Temperature Range Transportation & Storage: - 40 to + 70°C Minimum Bending Radius Installation: - 30 to + 60°C Under Maximum Tension: 20 x Cable-Ø Operation: - 30 to + 70°C Without Tension: 10 x Cable-Ø Cable Design Acc. to IEC 60794-3-10 Loose Tube Fiber Optic Cable  -  Non Armoured  -  Dry Core  -  Single HFFR Sheath Central Strength Member (CSM): glass fiber reinforced plastic rod (FRP), with plastic oversheathing when needed. Loose Tube:  thermoplastic material, containing 12 fibers and filled with a suitable water tightness compound. Filler Elements:  thermoplastic rods, where needed. Stranding: loose tubes (and fillers), SZ stranded around the CSM. Longitudinal Water Tightness:  dry core with water swellable elements. 2 Ripcords:  Underneath sheath. Outer Sheath:  HFFR. Application Test  Test Standard Specified Value Acceptance Criteria Max. Installation Tension  IEC 60794–1-2-E1  1.5 W [N], min. 1500 N Δα reversible, fiber strain ≤ 0.33% Max. Operation Tension IEC 60794–1–2-E1 0.5 W [N], min. 700 N no fiber strain,  Δα ≤ 0.05 dB Crush  IEC 60794–1–2-E3 2000 N / 100 mm, max. 15 min Δα ≤ 0.05 dB, no damage Impact IEC 60794–1–2-E4 12 Nm, 3 impacts, R= 300 mm Δα ≤ 0.05 dB after the test Torsion IEC 60794–1–2-E7 100N, +/- 180°, 10 cycles Δα ≤ 0.05 dB, no damage Repeated Bending IEC 60794–1–2-E6 R=20x D, 100 N, 35 cycles no damage Cable Bend IEC 60794–1–2-E11 R=20x D, 4 turns, 3 cycles Δα ≤ 0.05 dB, no damage Temperature Cycling IEC 60794–1–2-F1 -30°C to +70°C Δα ≤ 0.05 dB/km Water Penetration IEC 60794–1–2-F5B sample=3m, water column=1m no water leakage in 24h Main Mechanical and Environmental Characteristics All optical measurements at 1550 nm. Test  Test Standard Specified Value Acceptance Criteria Single Cable Test IEC 60332-1 unburnt cable length  50 mm Smoke Density IEC 61034 transmission of light 60 % Halogen Content IEC 60754-1 halogen content  0.5 % Corrosivity of Smoke Gases IEC 60754-2 pH-value ≥ 4.3 Conductivity of Smoke Gases IEC 60754-2 conductivity  10  µS Fire Performance 10

Premium optical fiber cables Our Premium optical fiber cable range offers higher levels of performance, a choice of specialist cables and an unmatched technical specification for an extra-long operational life. The Premium range comprises eight product types: one non-armoured dielectric; four armoured (one or two sheaths and metallic or dielectric armour); one in-outdoor type and two special-dielectric-armoured for  protection against rodents. All our Premium cables are available  immediately from stock. Our logistical  support includes on-site, just-in-time  deliveries, tailored cable lengths and  cable-drum pick up. Fiber c ount o f C able Fiber c ount per T ube B u ff er / T ube Diame te r Minimum T emp . (0 ,0 5 dB /k m ) T ensile S tr ength T hickne s s  She ath Out door , Non Armour ed Out door , Armour ed, Single She ath Out door , Armour ed, Double She ath Out door , Dielectric Armour ed,  Single She ath Premium (PreLT) Qty 12 24 36 48 72 96 144 Qty 12 12 12 12 12 12 12 (mm) 2,5 2,5 2,5 2,5 2,5 2,5 2,5 (oC) -4º  -4º  -4º  -4º  -4º  -4º  -4º (N) 1,5 W/2700 1,5 W/2700 1,5 W/2700 1,5 W/2700 1,5 W/2700 1,5 W/2700 1,5 W/2700 (mm) 1,5 1,5 1,5 1,5 1,5 1,5 1,5 (PreLT 1) OD (mm) 11,0 11,0 11,0 11,0 11,5 12,5 16,0 (PreLT 2) OD (mm) 12,5 12,5 12,5 12,5 13,0 14,5 18,0 (PreLT 3) OD (mm) 14,0 14,0 14,0 14,0 14,5 16,5 19,5 (PreLT 4) OD (mm) 11,5 11,5 11,5 11,5 12,0 13,5 17,0 Out door , Dielectric Armour ed,  Double She ath In- / Out door , single HFFR she a th Indoor , Dielectric Armour ed,  Single HFFR She ath Indoor , Dielectric Armour ed,  Double HFFR She ath (PreLT 5) OD (mm) 13,5 13,5 13,5 13,5 14,0 16,0 19,0 (PreLT 6) OD (mm) 11,0 11,0 11,0 11,0 11,5 12,5 16,0 (PreLT 9) OD (mm) 11,5 11,5 11,5 11,5 12,0 13,5 17,0 (PreLT 10) OD (mm) 13,5 13,5 13,5 13,5 14,0 16,0 19,0 Core Stranded Loose Tube Cables Sheath Options 11

Premium range PreLT 1 – Outdoor, non armoured No. of Fibers 12 24 36 48 72 96 144 Design 1x12 2x12 3x12 4x12 6x12 8x12 12x12 Loose Tube / Filler - Ø mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 CSM – Ø mm 2.1 2.1 2.1 2.1 2.6 3.0 3.5 CSM-Oversheathing  -  Ø mm - - - - - 4.2 7.5 Outer Sheath Thickness mm 1.5 1.5 1.5 1.5 1.5 1.5 1.5 Cable Diameter mm 11.0 11.0 11.0 11.0 11.5 12.5 16.0 Cable Weight kg / km 85 85 85 85 95 120 190 Temperature Range Transportation & Storage: - 40 to + 70°C Minimum Bending Radius Installation: - 30 to + 60°C Under Maximum Tension: 20 x Cable-Ø Operation: - 40 to + 70°C Without Tension: 10 x Cable-Ø Cable Design Acc. to IEC 60794-3-10 Loose Tube Fiber Optic Cable   -  Non Armoured  -  Dielectric  -  Dry Core Central Strength Member (CSM):  glass fiber reinforced plastic rod (FRP), with plastic oversheathing when needed. Loose Tube: thermoplastic material, containing 12 fibers and filled with a suitable water tightness compound. Filler Elements: thermoplastic rods, where needed. Stranding: loose tubes (and fillers), SZ stranded around the CSM. Longitudinal Water Tightness:  dry core with water swellable elements. Peripheral Strength Elements:  aramide yarns (if required). 2 Ripcords:  Underneath sheath. Outer Sheath:  LDPE. Configuration Application Test  Test Standard Specified Value Acceptance Criteria Max. Installation Tension  IEC 60794–1-2-E1  1.5 W [N], min. 2700 N Δα reversible, fiber strain ≤ 0.33% Max. Operation Tension IEC 60794–1–2-E1 0.5 W [N], min. 900 N no fiber strain,  Δα ≤ 0.05 dB Crush  IEC 60794–1–2-E3 2000 N / 100 mm, max. 15 min Δα ≤ 0.05 dB, no damage Impact IEC 60794–1–2-E4 15 Nm, 3 impacts, R= 300 mm Δα ≤ 0.05 dB after the test Torsion IEC 60794–1–2-E7 100N, +/- 180°, 10 cycles Δα ≤ 0.05 dB, no damage Repeated Bending IEC 60794–1–2-E6 R=20x D, 100 N, 35 cycles no damage Cable Bend IEC 60794–1–2-E11 R=20x D, 4 turns, 3 cycles Δα ≤ 0.05 dB, no damage Temperature Cycling IEC 60794–1–2-F1 -40°C to +70°C Δα ≤ 0.05 dB/km Water Penetration IEC 60794–1–2-F5B sample=3m, water column=1m no water leakage in 24h Main Mechanical and Environmental Characteristics All optical measurements at 1550 nm. 12

No. of Fibers 12 24 36 48 72 96 144 DDesign 1x12 2x12 3x12 4x12 6x12 8x12 12x12 Loose Tube / Filler - Ø mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 CSM – Ø mm 2.1 2.1 2.1 2.1 2.6 3.0 3.5 CSM-Oversheathing  -  Ø mm - - - - - 4.2 7.5 Outer Sheath Thickness mm 1.5 1.5 1.5 1.5 1.5 1.5 1.5 Cable Diameter mm 12.5 12.5 12.5 12.5 13.0 14.5 18.0 Cable Weight kg / km 135 135 135 135 150 190 290 Temperature Range Transportation & Storage: - 40 to + 70°C Minimum Bending Radius Installation: - 30 to + 60°C Under Maximum Tension: 20 x Cable-Ø Operation: - 40 to + 70°C Without Tension: 15 x Cable-Ø Configuration Application Main Mechanical and Environmental Characteristics All optical measurements at 1550 nm. Premium range PreLT 2 – Outdoor, armoured, single sheath Cable Design Acc. to IEC 60794-3-10 Loose Tube Fiber Optic Cable  -  Armoured  -  Dry Core  -  Single Sheath Central Strength Member (CSM): glass fiber reinforced plastic rod (FRP), with plastic oversheathing when needed. Loose Tube: thermoplastic material, containing 12 fibers and filled with a suitable water tightness compound. Filler Elements:  thermoplastic rods, where needed. Stranding:  loose tubes (and fillers), SZ stranded around the CSM. Longitudinal Water Tightness:  dry core with water swellable elements. Peripheral Strength Elements:  aramide yarns (if required). Armour: both sides copolymer coated corrugated steel tape with overlap, water swellable elements.  Steel thickness:  0.15 mm.  2 Ripcords:  Underneath sheath. Outer Sheath:  HDPE. Test  Test Standard Specified Value Acceptance Criteria Max. Installation Tension  IEC 60794–1-2-E1  1.5 W [N], min. 2700 N Δα reversible, fiber strain ≤ 0.33% Max. Operation Tension IEC 60794–1–2-E1 0.5 W [N], min. 900 N no fiber strain,  Δα ≤ 0.05 dB Crush  IEC 60794–1–2-E3 4000 N / 100 mm, max. 15 min Δα ≤ 0.05 dB, no damage Impact IEC 60794–1–2-E4 30 Nm, 3 impacts, R= 300 mm Δα ≤ 0.05 dB after the test Torsion IEC 60794–1–2-E7 100N, +/- 180°, 10 cycles Δα ≤ 0.05 dB, no damage Repeated Bending IEC 60794–1–2-E6 R=20x D, 100 N, 35 cycles no damage Cable Bend IEC 60794–1–2-E11 R=20x D, 4 turns, 3 cycles Δα ≤ 0.05 dB, no damage Temperature Cycling IEC 60794–1–2-F1 -40°C to +70°C Δα ≤ 0.05 dB/km Water Penetration IEC 60794–1–2-F5B sample=3m, water column=1m no water leakage in 24h 13

Premium range PreLT 3 - Outdoor, armoured, double sheath No. of Fibers 12 24 36 48 72 96 144 Design 1x12 2x12 3x12 4x12 6x12 8x12 12x12 Loose Tube / Filler - Ø mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 CSM – Ø mm 2.1 2.1 2.1 2.1 2.6 3.0 3.5 CSM-Oversheathing  -  Ø mm - - - - - 4.2 7.5 Outer Sheath Thickness mm 1.5 1.5 1.5 1.5 1.5 1.5 1.5 Cable Diameter mm 14.0 14.0 14.0 14.0 14.5 16.5 19.5 Cable Weight kg / km 175 175 175 175 195 245 345 Temperature Range Transportation & Storage: - 40 to + 70°C Minimum Bending Radius Installation: - 30 to + 60°C Under Maximum Tension: 20 x Cable-Ø Operation: - 40 to + 70°C Without Tension: 10 x Cable-Ø Configuration Application Test  Test Standard Specified Value Acceptance Criteria Max. Installation Tension  IEC 60794–1-2-E1  1.5 W [N], min. 2700 N Δα reversible, fiber strain ≤ 0.33% Max. Operation Tension IEC 60794–1–2-E1 0.5 W [N], min. 900 N no fiber strain,  Δα ≤ 0.05 dB Crush  IEC 60794–1–2-E3 5000 N / 100 mm, max. 15 min Δα ≤ 0.05 dB, no damage Impact IEC 60794–1–2-E4 40 Nm, 3 impacts, R= 300 mm Δα ≤ 0.05 dB after the test Torsion IEC 60794–1–2-E7 100N, +/- 180°, 10 cycles Δα ≤ 0.05 dB, no damage Repeated Bending IEC 60794–1–2-E6 R=20x D, 100 N, 35 cycles no damage Cable Bend IEC 60794–1–2-E11 R=20x D, 4 turns, 3 cycles Δα ≤ 0.05 dB, no damage Temperature Cycling IEC 60794–1–2-F1 -40°C to +70°C Δα ≤ 0.05 dB/km Water Penetration IEC 60794–1–2-F5B sample=3m, water column=1m no water leakage in 24h Main Mechanical and Environmental Characteristics All optical measurements at 1550 nm. Cable Design Acc. to IEC 60794-3-10 Loose Tube Fiber Optic Cable  -  Dielectric Armoured  -  Dry Core  -  Double Sheath Central Strength Member (CSM):  glass fiber reinforced plastic rod (FRP), with plastic oversheathing when needed. Loose Tube:  thermoplastic material, containing 12 fibers and filled with a suitable water tightness compound. Filler Elements:  thermoplastic rods, where needed. Stranding: l oose tubes (and fillers), SZ stranded around the CSM. Longitudinal Water Tightness:  dry core with water swellable elements. Peripheral Strength Elements:  aramide yarns (if required). Inner Sheath:  PE, 2 ripcord. Armour:  both sides copolymer coated corrugated steel tape with overlap, water swellable elements. Steel thickness: 0.15 mm. 2 Ripcords:  Underneath sheath. Outer Sheath:  HDPE. 14

No. of Fibers 12 24 36 48 72 96 144 Design 1x12 2x12 3x12 4x12 6x12 8x12 12x12 Loose Tube / Filler - Ø mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 CSM – Ø mm 2.1 2.1 2.1 2.1 2.6 3.0 3.5 CSM-Oversheathing  -  Ø mm - - - - - 4.2 7.5 Outer Sheath Thickness mm 1.5 1.5 1.5 1.5 1.5 1.5 1.5 Cable Diameter mm 11.5 11.5 11.5 11.5 12.0 13.5 17.0 Cable Weight kg / km 105 105 105 105 120 150 230 Temperature Range Transportation & Storage: - 40 to + 70°C Minimum Bending Radius Installation: - 30 to + 60°C Under Maximum Tension: 20 x Cable-Ø Operation: - 40 to + 70°C Without Tension: 15 x Cable-Ø Configuration Application Test  Test Standard Specified Value Acceptance Criteria Max. Installation Tension  IEC 60794–1-2-E1  3 W [N], min. 2700 N Δα reversible, fiber strain ≤ 0.33% Max. Operation Tension IEC 60794–1–2-E1 1.5 W [N], min. 900 N no fiber strain,  Δα ≤ 0.05 dB Crush  IEC 60794–1–2-E3 4000 N / 100 mm, max. 15 min Δα ≤ 0.05 dB, no damage Impact IEC 60794–1–2-E4 30 Nm, 3 impacts, R= 300 mm Δα ≤ 0.05 dB after the test Torsion IEC 60794–1–2-E7 100N, +/- 180°, 10 cycles Δα ≤ 0.05 dB, no damage Repeated Bending IEC 60794–1–2-E6 R=20x D, 100 N, 35 cycles no damage Cable Bend IEC 60794–1–2-E11 R=20x D, 4 turns, 3 cycles Δα ≤ 0.05 dB, no damage Temperature Cycling IEC 60794–1–2-F1 -40°C to +70°C Δα ≤ 0.05 dB/km Water Penetration IEC 60794–1–2-F5B Sample=3m, water column=1m no water leakage in 24h Main Mechanical and Environmental Characteristics All optical measurements at 1550 nm. Premium range PreLT 4 - Outdoor, dielectric armoured, single sheath Cable Design Acc. to IEC 60794-3-10 Loose Tube Fiber Optic Cable  -  Dielectric armoured  -  Dry Core  -  Single Sheath Central Strength Member (CSM):  glass fiber reinforced plastic rod (FRP), with plastic oversheathing when needed. Loose Tube:  thermoplastic material, containing 12 fibers and filled with a suitable water tightness compound. Filler Elements:  thermoplastic rods, where needed. Stranding:  loose tubes (and fillers), SZ stranded around the CSM. Longitudinal Water Tightness:  dry core with water swellable elements. Peripheral Strength Elements and Non Metallic Armour:  glass yarns. 2 Ripcords:  Underneath sheath. Outer Sheath:  HDPE. 15

Premium range PreLT 5 – Outdoor,  dielectric armoured, double sheath No. of Fibers 12 24 36 48 72 96 144 Design 1x12 2x12 3x12 4x12 6x12 8x12 12x12 Loose Tube / Filler - Ø mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 CSM – Ø mm 2.1 2.1 2.1 2.1 2.6 3.0 3.5 CSM-Oversheathing  -  Ø mm - - - - - 4.2 7.5 Outer Sheath Thickness mm 1.5 1.5 1.5 1.5 1.5 1.5 1.5 Cable Diameter mm 13.5 13.5 13.5 13.5 14.0 16.0 19.0 Cable Weight kg / km 145 145 145 145 160 200 290 Temperature Range Transportation & Storage: - 40 to + 70°C Minimum Bending Radius Installation: - 30 to + 60°C Under Maximum Tension: 20 x Cable-Ø Operation: - 40 to + 70°C Without Tension: 10 x Cable-Ø Configuration Application Test  Test Standard Specified Value Acceptance Criteria Max. Installation Tension  IEC 60794–1-2-E1  3 W [N], min. 5000 N Δα reversible, fiber strain ≤ 0.33% Max. Operation Tension IEC 60794–1–2-E1 1.5 W [N], min. 2500 N no fiber strain,  Δα ≤ 0.05 dB Crush  IEC 60794–1–2-E3 5000 N / 100 mm, max. 15 min Δα ≤ 0.05 dB, no damage Impact IEC 60794–1–2-E4 30 Nm, 3 impacts, R= 300 mm Δα ≤ 0.05 dB after the test Torsion IEC 60794–1–2-E7 100N, +/- 180°, 10 cycles Δα ≤ 0.05 dB, no damage Repeated Bending IEC 60794–1–2-E6 R=20x D, 100 N, 35 cycles no damage Cable Bend IEC 60794–1–2-E11 R=20x D, 4 turns, 3 cycles Δα ≤ 0.05 dB, no damage Temperature Cycling IEC 60794–1–2-F1 -40°C to +70°C Δα ≤ 0.05 dB/km Water Penetration IEC 60794–1–2-F5B sample=3m, water column=1m no water leakage in 24h Main Mechanical and Environmental Characteristics All optical measurements at 1550 nm. Cable Design Acc. to IEC 60794-3-10 Loose Tube Fiber Optic Cable  -  Dielectric Armoured  -  Dry Core  -  Double Sheath Central Strength Member (CSM):  glass fiber reinforced plastic rod (FRP), with plastic oversheathing when needed. Loose Tube: thermoplastic material, containing 12 fibers and filled with a suitable water tightness compound. Filler Elements: thermoplastic rods, where needed. Stranding:  loose tubes (and fillers), SZ stranded around the CSM. Longitudinal Water Tightness:  dry core with water swellable elements. Inner Sheath:  PE, 2 ripcords Peripheral Strength Elements and Non Metallic Armour:  glass yarns. 2 Ripcords:  Underneath sheath. Outer Sheath:  HDPE. 16

No. of Fibers 12 24 36 48 72 96 144 Design 1x12 2x12 3x12 4x12 6x12 8x12 12x12 Loose Tube / Filler - Ø mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 CSM – Ø mm 2.1 2.1 2.1 2.1 2.6 3.0 3.5 CSM-Oversheathing  -  Ø mm - - - - - 4.2 7.5 Outer Sheath Thickness mm 1.5 1.5 1.5 1.5 1.5 1.5 1.5 Cable Diameter mm 11.0 11.0 11.0 11.0 11.5 12.5 16.0 Cable Weight kg / km 110 110 110 110 120 150 230 Temperature Range Transportation & Storage: - 40 to + 70°C Minimum Bending Radius Installation: - 30 to + 60°C Under Maximum Tension: 20 x Cable-Ø Operation: - 40 to + 70°C Without Tension: 10 x Cable-Ø Configuration Application Test  Test Standard Specified Value Acceptance Criteria Max. Installation Tension  IEC 60794–1-2-E1  1.5 W [N], min. 2700 N Δα reversible, fiber strain ≤ 0.33% Max. Operation Tension IEC 60794–1–2-E1 0.5 W [N], min. 900 N no fiber strain,  Δα ≤ 0.05 dB Crush  IEC 60794–1–2-E3 2000 N / 100 mm, max. 15 min Δα ≤ 0.05 dB, no damage Impact IEC 60794–1–2-E4 15 Nm, 3 impacts, R= 300 mm Δα ≤ 0.05 dB after the test Torsion IEC 60794–1–2-E7 100N, +/- 180°, 10 cycles Δα ≤ 0.05 dB, no damage Repeated Bending IEC 60794–1–2-E6 R=20x D, 100 N, 35 cycles no damage Cable Bend IEC 60794–1–2-E11 R=20x D, 4 turns, 3 cycles Δα ≤ 0.05 dB, no damage Temperature Cycling IEC 60794–1–2-F1 -40°C to +70°C Δα ≤ 0.05 dB/km Water Penetration IEC 60794–1–2-F5B sample=3m, water column=1m no water leakage in 24h Main Mechanical and Environmental Characteristics All optical measurements at 1550 nm. Test  Test Standard Specified Value Acceptance Criteria Single Cable Test IEC 60332-1 unburnt cable length  50 mm Smoke Density IEC 61034 transmission of light 60 % Halogen Content IEC 60754-1 halogen content  0.5 % Corrosivity of Smoke Gases IEC 60754-2 pH-value ≥ 4.3 Conductivity of Smoke Gases IEC 60754-2 conductivity  10  µS Fire Performance Premium range PreLT 6 – Indoor / Outdoor, single HFFR sheath Cable Design Acc. to IEC 60794-3-10 Loose Tube Fiber Optic Cable  -  Non Armoured  -  Dry Core  -  Single HFFR Sheath Central Strength Member (CSM):  glass fiber reinforced plastic rod (FRP), with plastic oversheathing when needed. Loose Tube:  thermoplastic material, containing 12 fibers and filled with a suitable water tightness compound. Filler Elements:  thermoplastic rods, where needed. Stranding:  loose tubes (and fillers), SZ stranded around the CSM. Longitudinal Water Tightness:  dry core with water swellable elements. Peripheral Strength Elements:  glass yarns, when needed. 2 Ripcords:  Underneath sheath. Outer Sheath:  HFFR. 17

Premium range PreLT 9 – Indoor, dielectric armoured, single HFFR sheath No. of Fibers 12 24 36 48 72 96 144 Design 1x12 2x12 3x12 4x12 6x12 8x12 12x12 Loose Tube / Filler - Ø mm 2.5 2.5 2.5 2.5 2.5 2.5 2.5 CSM – Ø mm 2.1 2.1 2.1 2.1 2.6 3.0 3.5 CSM-Oversheathing  -  Ø mm - - - - - 4.2 7.5 Outer Sheath Thickness mm 1.5 1.5 1.5 1.5 1.5 1.5 1.5 Cable Diameter mm 11.5 11.5 11.5 11.5 12.0 13.5 17.0 Cable Weight kg / km 130 130 130 130 145 185 270 Temperature Range Transportation & Storage: - 40 to + 70°C Minimum Bending Radius Installation: - 30 to + 60°C Under Maximum Tension: 20 x Cable-Ø Operation: - 40 to + 70°C Without Tension: 10 x Cable-Ø Configuration Application Test  Test Standard Specified Value Acceptance Criteria Max. Installation Tension  IEC 60794–1-2-E1  3 W [N], min. 5000 N Δα reversible, fiber strain ≤ 0.33% Max. Operation Tension IEC 60794–1–2-E1 1.5 W [N], min. 2500 N no fiber strain,  Δα ≤ 0.05 dB Crush  IEC 60794–1–2-E3 4000 N / 100 mm, max. 15 min Δα ≤ 0.05 dB, no damage Impact IEC 60794–1–2-E4 30 Nm, 3 impacts, R= 300 mm Δα ≤ 0.05 dB after the test Torsion IEC 60794–1–2-E7 100N, +/- 180°, 10 cycles Δα ≤ 0.05 dB, no damage Repeated Bending IEC 60794–1–2-E6 R=20x D, 100 N, 35 cycles no damage Cable Bend IEC 60794–1–2-E11 R=20x D, 4 turns, 3 cycles Δα ≤ 0.05 dB, no damage Temperature Cycling IEC 60794–1–2-F1 -40°C to +70°C Δα ≤ 0.05 dB/km Water Penetration IEC 60794–1–2-F5B sample=3m, water column=1m no water leakage in 24h Main Mechanical and Environmental Characteristics All optical measurements at 1550 nm. Cable Design Acc. to IEC 60794-3-10 Loose Tube Fiber Optic Cable  -  Dieletric Armoured  -  Dry Core  -  Single HFFR Sheath Central Strength Member (CSM):  glass fiber reinforced plastic rod (FRP), with plastic oversheathing when needed. Loose Tube:  thermoplastic material, containing 12 fibers and filled with a suitable water tightness compound. Filler Elements:  thermoplastic rods, where needed. Stranding:  loose tubes (and fillers), SZ stranded around the CSM. Longitudinal Water Tightness:  dry core with water swellable elements. Peripheral Strength Elements and Non Metallic Armour:  glass yarns. 2 Ripcords:  Underneath sheath. Outer Sheath:  HFFR. Test  Test Standard Specified Value Acceptance Criteria Single Cable Test IEC 60332-1 unburnt cable length  50 mm Smoke Density IEC 61034 transmission of light 60 % Halogen Content IEC 60754-1 halogen content  0.5 % Corrosivity of Smoke Gases IEC 60754-2 pH-value ≥ 4.3 Conductivity of Smoke Gases IEC 60754-2 conductivity  10  µS Fire Performance 18

Filler Elements Colours All filler elements are uncoloured (natural). Sheath Colour The inner and outer sheath colour is black. Sheath Marking The outer sheath is marked in 1 meter intervals as follows: DRAKA   year of manufacture   number x SMF   length marking in meter Packing Wooden drums with protection. Delivery Lengths Standard delivery lengths are 2 km, 4 km, 6 km with a tolerance of  - 1% / + 3% Fiber Colours No. Colour 1 blue 2 orange 3 green 4 brown 5 grey 6 white 7 red 8 black 9 yellow 10 violet 11 pink 12 turquoise Identification and Packing Buffer Tube Colours  No. Colour 1 blue 2 orange 3 green 4 brown 5 grey 6 white 7 red 8 black 9 yellow 10 violet 11 pink 12 turquoise No. of Fibers 12 24 36 48 72 96 144 Design 1x12 2x12 3x12 4x12 6x12 8x12 12x12 Loose Tube / Filler - Ø mm 2.5 CSM – Ø mm 2.1 2.6 3.0 3.5 CSM-Oversheathing - Ø mm - - 4.2 7.5 Outer Sheath Thickness mm 1.5 Cable Diameter mm 13.5 14.0 16.0 19.0 Cable Weight kg / km 190 205 255 355 Temperature Range Transportation & Storage: - 40 to + 70°C Minimum Bending Radius Installation: - 30 to + 60°C Under Maximum Tension: 20 x Cable-Ø Operation: - 40 to + 70°C Without Tension: 10 x Cable-Ø Configuration Application Test  Test Standard Specified Value Acceptance Criteria Max. Installation Tension  IEC 60794–1-2-E1  3 W [N], min. 5000 N Δα reversible, fiber strain ≤ 0.33% Max. Operation Tension IEC 60794–1–2-E1 1.5 W [N], min. 2500 N no fiber strain,  Δα ≤ 0.05 dB Crush  IEC 60794–1–2-E3 5000 N / 100 mm, max. 15 min Δα ≤ 0.05 dB, no damage Impact IEC 60794–1–2-E4 40 Nm, 3 impacts, R= 300 mm Δα ≤ 0.05 dB after the test Torsion IEC 60794–1–2-E7 100N, +/- 180°, 10 cycles Δα ≤ 0.05 dB, no damage Repeated Bending IEC 60794–1–2-E6 R=20x D, 100 N, 35 cycles no damage Cable Bend IEC 60794–1–2-E11 R=20x D, 4 turns, 3 cycles Δα ≤ 0.05 dB, no damage Temperature Cycling IEC 60794–1–2-F1 -40°C to +70°C Δα ≤ 0.05 dB/km Water Penetration IEC 60794–1–2-F5B sample=3m, water column=1m no water leakage in 24h Main Mechanical and Environmental Characteristics All optical measurements at 1550 nm. Fire Performance Premium range PreLT 10 – Indoor, dielectric armoured, double HFFR sheath Cable Design Acc. to IEC 60794-3-10 Loose Tube Fiber Optic Cable  -  Dielectric Armoured  -  Dry Core  -   Double HFFR Sheath Central Strength Member (CSM):  glass fiber reinforced plastic rod (FRP), with plastic oversheathing when needed. Loose Tube:  thermoplastic material, containing up to 12 fibers and filled with a suitable water tightness compound. Filler Elements:  thermoplastic rods, where needed. Stranding:  loose tubes (and fillers), SZ stranded around the CSM. Longitudinal Water Tightness:  dry core with water swellable elements. Inner Sheath:  HFFR. 2 ripcords. Peripheral Strength Elements and Non Metallic Armour:  glass yarns. 2 Ripcords:  Underneath sheath Outer Sheath: HFFR. Test  Test Standard Specified Value Acceptance Criteria Single Cable Test IEC 60332-1 unburnt cable length  50 mm Smoke Density IEC 61034 transmission of light 60 % Halogen Content IEC 60754-1 halogen content  0.5 % Corrosivity of Smoke Gases IEC 60754-2 pH-value ≥ 4.3 Conductivity of Smoke Gases IEC 60754-2 conductivity  10  µS 19 2  Value Innovation is a way of looking at the world. What we can do to help our customers do more, make more, save more and achieve more? A lot. We help our customers to stay ahead. By combining market insight with technological know-how and building strong, long-lasting relationships, we add value to their business with advanced communication solutions and services that are designed  to last. No matter how complex your challenge, we have a product or solution that will do more than meet your needs. And if for some  reason we don’t, we’ll make it for you.  New applications, breakthrough cables,  custom connectors or complete network  designs – it’s all part of what we call  Value Innovation, and it’s what drives us. Value Innovation
