Draka Media & Broadcasting Solution

 3 Inspiring partnerships Comprehensive product line Whatever media you’re in, the Draka Media & Broadcast Solution has the cables you need. You’ll find our broad cast cables in use at worldwide events, in recording studios, outside broadcasting and ‘live on stage’.

 4

 5 Product Diversity Service-oriented Triax, video and audio cables made by Draka Communications – extreme space ratio and still optimal trans-mission characteristics.

 6 Transmission quality Screening Factor Multicore camera cables: coaxial elements, power-, audio- and pilot cores. Upon request, our studio cables are available with halogen-free FRNC sheath.

 7 Attenuation at 1.5GHz  (half clock frequency) as per data sheet [dB] 43.2 31.3 33.9 24.9 19.6 16.9 39.6 30.6 24.9 3Gb/s HD 1080P  max. cable length tested TG 700 & WFM 8300  of Tektronix [m] 80 110 100 130 190 230 100 120 150 Calculated application  length acc.  To SMPTE 424M [m] 47 64 59 72 102 119 50 66 80 Draka  Video Cable Types 0.6/2.8 AF 0.8/3.7 AF    0.8L/3.7 Dz 1.0/4.8 AF    1.4/6.6 AF    1.6/7.3 AF      HD PRO 0.6/2.8 AF  HD PRO 0.8/3.7 AF   HD PRO 1.0/4.8 AF

 8 Testing At a glance A 60 cm long piece of cable is exposed to a flamefor 60 seconds. The cable does not ignite. A cable bundle is exposed to a line of flames for 20 minutes in a 4 meter high cabinet. Approxima-tely one meter above the flames the cable bundle must extinguish itself with only a minimal production of smoke. Method IEC 60332-1 Method IEC 60332-3-24

 9 www.draka.com/  communications [email protected]

 10 Choice of material Packing density Standards References Even in video transmission systems  up to 1.5 GHz our video cables ensure a screening value of   100dB at a very low transfer impedance.

 11

 12 Characteristic impedance Transmission quality  Interference transmission resistance  The right cable for every demand Audio cables for   digital and analogue broadcasting and TV-technique offer  an  enjoyment of sound to the audience

 13 AC 10 SS 24/7 nxP AC  =  Audio Cable10  =   tested    frequency range     in MHz SS   =  super screen    (pair screen and      overall screen with        Al-laminated         plastic foil) SP  =  spiraled screen    (pairs in     spiraled wires) S  =  screen    (Al-laminated     plastic foil) 23   =  AWG-value    (conductor      diameter) nxP =  Number of pairs

 14 Compatibility Triax Triflex Typically Triax: Best transmission quality basing on low attenuation and lowest DC-resistance even in large application lengths. Furthermore: minimal weight and long lifespan.

 15 Cable type

 16 Nowadays camera pictures supply top events. Whether the quality is likewise impressive also depends on the used camera cables. Multifunctionally

755-804 75   =   Characteristic impedance   of the coaxiales 5   =  Number of coaxiales8   =  cable construction01   =  FRNC02  =  PVC03  =  PUR04  =  DMC Flex PVC

VAN 113 V  =  VideoA   =  AudioN   =  Power supply1   =  1 x Video1   =  1 x Audiopair3   =  3 x Power element  17

 18 Microphone Cable Speaker Cable Light & Sound
