CONTENTS
COINlight ® Advanced 9.02 LINEARlight-DRAGON ® Slim 9.03 LINEARlight-DRAGON ® board 9.04 LINEARlight-DRAGON ® , complete module 9.05 DRAGONeye ® 9.06 DRAGONpuck ® 9.07 DRAGONtape ® 9.08 DRAGON-X ® 9.09 DRAGON-X ® Plus 9.10 LINEARlight Flex ® SIDELED ® 9.11 LINEARlight Flex ® LF05A 9.12 LINEARlight Flex ® LF05E 9.13 LINEARlight POWER Flex 9.14 LINEARlight 9.15 COINlight ® 9.16 COINlight ® Colormix 9.17 LINEARlight-DRAGON ® Colormix, basic module 9.18 LINEARlight-DRAGON ® Colormix, complete module 9.19 DRAGONchain ® Colormix, basic module 9.20 DRAGONchain ® Colormix, complete module 9.21 LINEARlight Colormix Flex 9.22 LINEARlight Colormix 9.23 BACKlight BL02 9.24 BACKlight Protect BL02 9.25 BACKlight Protect BL04 9.26 DRAGONchain ® 9.27 STREETlight Advanced 9.28 STREETlight Protect 9.29 CONNECTsystem for monochrome 10 mm wide fl ex modules 9.30 CONNECTsystem for monochrome 8 mm wide fl ex modules 9.31 CONNECTsystem for LINEARlight-DRAGON ® 9.32 CONNECTsystem for LINEARlight 9.32 CONNECTsystem for LINEARlight-DRAGON ® Colormix 9.33 CONNECTsystem for LINEARlight Colormix Flex 9.34 CONNECTsystem for LINEARlight Colormix 9.35 Heat sink 9.36 LINEARlight Optics 9.37 DRAGONtape ® Optics 9.37 LINEARlight-DRAGON ® mounting bracket 9.38 Installation aid for BACKlight and BACKlight Protect 9.38 LINEARlight Track 9.39 LED systems
9.02 Productreference Productnumber CA50-051-830-L36 1) 4008321958914 white 3 24 7.5 CA50-051-840-L36 1) 4008321958938 white 3 24 7.5 CA50-051-854-L36 1) 4008321958952 white 3 24 7.5 Productreference CA50-051-830-L36 1) 36 3000 500 27.2 50 20 1 CA50-051-840-L36 1) 36 4000 500 27.2 50 20 1 CA50-051-854-L36 1) 36 5400 500 27.2 50 20 1 1) Modules perfectly matched to 24 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values COINlight ® Advanced 1 COINlight ® Advanced Specifically targeted pools of light can fundamentally change the overall impression of a room.They are used for orientation and for uniform illumination of offices or walkways.The new COINlight ® Advanced module, round high-power spotlights with integrated primary heat sinks, provides unmistakable accent lighting as a recessed unit. Special features Easy to integrate in standard luminaires • Integrated 36° optics • M3 internal thread for simple installation • Fitted with three connecting cables: Red+, Black–, White Dimming • Dimmable by pulse width modulation (PWM) • The modules can only be connected in parallel • Up to 10 CA50 modules can be operated with only one OT 75 unit • Applications Ideal for use in recessed ceiling lights or shop lighting • Perfect for orientation and accent lighting • Optional accessoriesHeat sink, see page 9.36 NEW NEW NEW
9.03 Productreference Productnumber LD06S-W4F-830 1) 4008321953308 white 6 24 7 LD06S-W4F-840 1) 4008321953322 white 6 24 7 Productreference LD06S-W4F-830 1) 120 3000 305 16 16.2 6 1 LD06S-W4F-840 1) 120 4000 305 16 16.2 6 1 1) Modules perfectly matched to 24 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values LINEARlight-DRAGON ® Slim 1 305,0 50,0 16,2 16,2 16,0 LINEARlight-DRAGON ® Slim You don‘t have to be big to be great. The LINEARlight-DRAGON ® Slim LED strip offers high brightness and superior technology in a small unit with six high-flux Golden DRAGON ® Plus LEDs. This slim system will fit anywhere and can provide ideal close-up lighting, for example for displaying merchandise in cabinets or on shelving. Special features Slim LED strip • Highly versatile thanks to robust aluminum housing and accessories • Brackets included for simple flexible mounting • Simple contact with plug system (accessories) • Aluminum housing provides adequate cooling for the LEDs • Up to five modules can be operated in series • Dimmable by pulse width modulation (PWM) • Optimized for use with OPTOTRONIC • ® control gear and controllers for 24 V Applications Display lighting • Shelf/furniture lighting • Small coving • NEW NEW
9.04 Productreference Productnumber LD06B-W4F-830 1) 4008321395757 white 6 24 12 LD06B-W4F-840 1) 4008321395870 white 6 24 12 LD06B-W4F-854 1) 4008321395993 white 6 24 12 Productreference LD06B-W4F-830 1) 170 3000 300 20 8.5 6 1 LD06B-W4F-840 1) 170 4000 300 20 8.5 6 1 LD06B-W4F-854 1) 170 5400 300 20 8.5 6 1 1) Modules perfectly matched to 24 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values LINEARlight-DRAGON ® board 1 LINEARlight-DRAGON ® Any system is only as flexible as its individual elements. LINEARlight-DRAGON ® has taken this principle to heart. The metal core board with six high-flux Golden DRAGON ® Plus LEDs is extremely adaptable in recessed installations, while the flexible system with lens holders and designer heat sinks shows impressive versatility. Special features New LD06B-W4F types with 80-120 % higher luminous flux than predecessor LD06A-W3F types • Mounting holes on the overall module and on the board for attaching with screws, • alternative mounting of the overall module with mounting brackets LD-MBDimmable by pulse width modulation (PWM) • Integrated 30° optics for overall module • Additional optics OP 1x1 for individual boards for different applications (spotlight, wide-area lighting, • wallwashing)Up to six modules can be connected one after the other with mid-feed with only one OT 75 unit • Plug & Play connection (feeder and connector) thanks to the LD-2x CONNECTsystem • Applications Ideal for recessed luminaires • Suitable for wide-area illumination and other general lighting applications • Wallwashing, cove lighting • Optional accessories CONNECTsystem for LINEARlight-DRAGON • ® (see page 9.32) LINEARlight-DRAGON • ® mounting brackets (see page 9.38)
9.05 Productreference Productnumber LD06B-W4F-830-L30 1) 4008321394491 white 6 24 12 LD06B-W4F-840-L30 1) 4008321394613 white 6 24 12 LD06B-W4F-854-L30 1) 4008321395290 white 6 24 12 Productreference LD06B-W4F-830-L30 1) 30 307 36 25.8 6 1 LD06B-W4F-840-L30 1) 30 307 36 25.8 6 1 LD06B-W4F-854-L30 1) 30 307 36 25.8 6 1 1) Modules perfectly matched to 24 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values LINEARlight-DRAGON ® , complete module 1 LINEARlight-DRAGON ® Any system is only as flexible as its individual elements. LINEARlight-DRAGON ® has taken this principle to heart. The metal core board with six high-flux Golden DRAGON ® Plus LEDs is extremely adaptable in recessed installations, while the flexible system with lens holders and designer heat sinks shows impressive versatility. Special features New LD06B-W4F types with 80-120 % higher luminous flux than predecessor LD06A-W3F types • Mounting holes on the overall module and on the board for attaching with screws, • alternative mounting of the overall module with mounting brackets LD-MBDimmable by pulse width modulation (PWM) • Integrated 30° optics for overall module • Additional optics OP 1x1 for individual boards for different applications (spotlight, wide-area lighting, • wallwashing)Up to six modules can be connected one after the other with mid-feed with only one OT 75 unit • Plug & Play connection (feeder and connector) thanks to the LD-2x CONNECTsystem • Applications Ideal for recessed luminaires • Suitable for wide-area illumination and other general lighting applications • Wallwashing, cove lighting • Optional accessories CONNECTsystem for LINEARlight-DRAGON • ® (see page 9.32) LINEARlight-DRAGON • ® mounting brackets (see page 9.38)
9.06 Productreference Productnumber DE1-W3F-830 1) 4008321365361 white 1 0.350 1.2 DE1-W4F-854 1) 4008321364999 white 1 0.350 1.2 Productreference DE1-W3F-830 1) 15 3000 500 33 23 264 1 DE1-W4F-854 1) 15 5400 500 33 23 264 1 1) Modules perfectly matched to 350 mA OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values DRAGONeye ® DRAGONeye ® If something is worth highlighting then attention should be drawn to it and to nothing else. With DRAGONeye ® this is precisely what happens. The compact mini spotlight with a high-flux Golden DRAGON ® LED can be easily integrated in luminaires or used in shop windows, shop interiors and museums to add a little sparkle. Special features Narrow beam angle for use as a spot source • Metal package for optimum heat removal • Integrated M10 x 1.5 thread for simple installation • Type of protection IP65 according to DIN EN 60529 • The modules can only be connected in series • Dimmable by pulse width modulation (PWM) • Integrated 500 mm cable • Applications As a small luminaire head in single LED luminaires • For accent, orientation or route lighting • 1
9.07 Productreference Productnumber DP3-W3F-827 1) 4008321940377 white 3 0.350 3.6 DP3-W4F-854 1) 4008321940551 white 3 0.350 3.6 Productreference DP3-W3F-827 1) 16 2700 200 12.1 35.2 16 1 DP3-W4F-854 1) 16 5400 200 12.1 35.2 16 1 1) Modules perfectly matched to 350 mA OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values DRAGONpuck ® 1 DRAGONpuck ® One of the outstanding properties of light is that applications can be stylishly highlighted with simple means. Particularly bright concentrated light sources are therefore ideal for increasing the powers of attraction. DRAGONpuck ® can do much more than this however: Three bright high-flux Golden DRAGON ® LEDs are used for safe orientation in the dark or for relaxed reading. Special features Very low profile, same diameter as QR-CBC-35 lamps • Narrow beam angle for use as a spot source • M3 screw fixing • Two-core connecting cable (200 mm) with open cable ends • Light source with long life • Dimmable by pulse width modulation (PWM) • Applications Reading lights • Accent lighting • Light source for furniture luminaires • For orientation lights • Spot light source •
9.08 Productreference Productnumber DT6-W3F-827 1) 4008321368461 white 6 0.350 7.2 DT6-W4F-854 1) 4008321365224 white 6 0.350 7.2 Productreference DT6-W3F-827 1) 120 2700 152 25 2.6 25 1 DT6-W4F-854 1) 120 5400 152 25 2.6 25 1 1) Modules perfectly matched to 350 mA OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values DRAGONtape ® 1 DRAGONtape ® Lighting design is now so wide-ranging that almost any vision can be converted into an efficient concept. With six high-flux Golden DRAGON ® LEDs on flexible splittable boards, DRAGONtape ® offers ideal conditions for creating innovative lighting designs in a wide variety of forms. Special features Self-adhesive backing for simple installation • Can be divided into units of 1 to 6 LEDs • Optics which reduce the beam angle from 120° to 10°, 30° or • 14x22º can be used as accessoriesOptics are positioned over the LED and screwed in place • Contact is made by soldering two wires on the selected unit • Dimmable by pulse width modulation (PWM) • Applications Ideal for the development of prototype luminaires and LED solutions • For orientation lights • For shop and furniture lights and small signal lights • Effect lighting and industrial applications • Optional accessories DRAGONtape • ® optics (see page 9.37)
9.09 DRAGON-X ® 3 4 DRAGON-X ® Thanks to its compactness and different optics the DRAGON-X ® module can be easily installed in compact and portable luminaires. Special features Available with different integrated optics 12º (L12), 30º (L30) and 60º (L60) or without optics (120º) • Optimum heat dissipation for instant use • Universal applications • Dimmable by pulse width modulation (PWM) • Applications For portable and compact luminaires • For use in architectural, shop and interior luminaires • Safety lighting and signal lights • 1 2 Productreference Productnumber DX1-W3-733 1) 4008321166319 white 1 0.350 1.2 120 DX1-W3-733-L12 1) 4008321166258 white 1 0.350 1.2 12 DX1-W3-733-L30 1) 4008321166272 white 1 0.350 1.2 30 DX1-W3-733-L60 1) 4008321166296 white 1 0.350 1.2 60 DX1-W3-854 1) 4008321166234 white 1 0.350 1.2 120 DX1-W3-854-L12 1) 4008321166173 white 1 0.350 1.2 12 DX1-W3-854-L30 1) 4008321166197 white 1 0.350 1.2 30 DX1-W3-854-L60 1) 4008321166210 white 1 0.350 1.2 60 DX1-W3-865 1) 4008321166159 white 1 0.350 1.2 120 DX1-W3-865-L12 1) 4008321166098 white 1 0.350 1.2 12 DX1-W3-865-L30 1) 4008321166111 white 1 0.350 1.2 30 DX1-W3-865-L60 1) 4008321166135 white 1 0.350 1.2 60 Productreference DX1-W3-733 1) 3300 20 23 3.5 200 1 DX1-W3-733-L12 1) 3300 20 23 14.5 200 2 DX1-W3-733-L30 1) 3300 20 23 11 200 3 DX1-W3-733-L60 1) 3300 20 23 8.2 200 4 DX1-W3-854 1) 5400 20 23 3.5 200 1 DX1-W3-854-L12 1) 5400 20 23 14.5 200 2 DX1-W3-854-L30 1) 5400 20 23 11 200 3 DX1-W3-854-L60 1) 5400 20 23 8.2 200 4 DX1-W3-865 1) 6500 20 23 3.5 200 1 DX1-W3-865-L12 1) 6500 20 23 14.5 200 2 DX1-W3-865-L30 1) 6500 20 23 11 200 3 DX1-W3-865-L60 1) 6500 20 23 8.2 200 4 1) Modules perfectly matched to 350 mA OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values
9.10 DRAGON-X ® Plus Productreference DX01-W4F-830 1) 170 3000 4.5 21.4 60 DX01-W4F-854 1) 170 5400 4.5 21.4 60 1) Modules perfectly matched to 350 mA OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values 1 DRAGON-X ® Plus The compact DRAGON-X ® Plus module is a big hit when it comes to creating sensationally bright scenarios. The new high-flux Golden DRAGON ® Plus-LED opens up a new dimension in light. Thanks to the new profile the hexagonal module requires less space, giving luminaire designers extra freedom. Special features Beam angle 170° • Optimum heat dissipation for instant use • Universal applications • Dimmable by pulse width modulation (PWM) • Applications For portable and compact luminaires • For use in architectural, shop and interior luminaires • Safety lighting and signal lamps • Productreference Productnumber DX01-W4F-830 1) 4008321960023 white 1 0.350 1.2 DX01-W4F-854 1) 4008321960047 white 1 0.350 1.2 NEW NEW
9.11 Productreference Productnumber LM11A-W3-847 1) 4008321187161 white 300 10 30 120 LM11A-W3-854 1) 4008321187185 white 300 10 30 120 LM11A-W3-865 1) 4008321187208 white 300 10 30 120 LM11A-A 1) 4008321086952 red 300 10 15 120 LM11A-Y1 1) 4050300946016 yellow 300 10 22.5 120 LM11A-T 1) 4008321086990 green 300 10 30 120 LM11A-B 1) 4008321086976 blue 300 10 30 120 Productreference LM11A-W3-847 1) - 4700 4200 10.4 4.5 56 8 1 LM11A-W3-854 1) - 5400 4200 10.4 4.5 56 8 1 LM11A-W3-865 1) - 6500 4200 10.4 4.5 56 8 1 LM11A-A 1) 615 - 4200 10.4 4.5 56 8 1 LM11A-Y1 1) 587 - 4200 10.4 4.5 56 8 1 LM11A-T 1) 528 - 4200 10.4 4.5 56 8 1 LM11A-B 1) 470 - 4200 10.4 4.5 56 8 1 1) Modules perfectly matched to 10 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values LINEARlight Flex SIDELED ® 1 LINEARlight Flex ® SIDELED ® LINEARlight Flex ® SIDELED ® extends the range of LED systems from OSRAM suitable for illuminated signage. The side emitting version of LINEARlight Flex ® offers indirect lighting that gives lettering an eye-catching corona effect. Special features Flexible splittable LED tape with 300 LEDs per reel • Total length 4.2 m • The self-adhesive backing makes installation in metallic lettering easier • The module can be split at specially marked points so that individual lengths can be used • Light emission parallel to the mounting surface and small mounting height mean this module can be used • in very tight spacesFully compatible with OPTOTRONIC • ® -10-V-control gear Applications Marker lights for walkways and outlines (e.g. escape routes, edges and steps) • Signage (corona effect) • Accent lighting for columns • Optional accessories: CONNECTsystem for monochrome 10 mm wide flex modules (see page 9.30) •
9.12 Productreference Productnumber LF05A-W3F-830 4008321955371 white 24 72 120 - LF05A-W3F-840 4008321955364 white 24 72 120 - LF05A-B3 4008321955388 blue 24 72 120 470 Productreference LF05A-W3F-830 3000 9900 8 2.5 100 8 1 LF05A-W3F-840 4000 9900 8 2.5 100 8 1 LF05A-B3 - 9900 8 2.5 100 8 1 LINEARlight Flex ® LF05A LINEARlight Flex ® Lighting systems are a permanent feature of modern architecture as they skillfully enhance the appearanceof external structures of all sizes. LED modules on flexible boards are the number one choice for creating three-dimensional forms and contours with strip lighting. Special features NEW: LF05A with smaller dimensions and additional cutting options thanks to the use of • the LF-2TERM end capLow height for low-profile surface/enclosed mounting • Simplified connection with the optional CONNECTsystem • Low thermal output • Flexible 3-D mounting possible • Flexible board with double-sided adhesive tape for simple mounting • Can be divided into the smallest unit or multiples thereof without affecting the function of the remainder of • the boardDimmable by pulse width modulation (PWM) • Applications Injection of light in displays and low-profile light guides • Information signs, advertising or display cabinet lighting • Backlighting of complex contours • For decorative applications: LF05A • For small coves and decorative applications • Optional accessories CONNECTsystem for monochrome 8 mm wide flex modules (see page 9.31) • LINEARlight Track (see page 9.39) • 1 NEW NEW NEW
9.13 Productreference Productnumber LF05E-W2F-830 4008321955401 white 24 24.5 120 - LF05E-W2F-840 4008321955395 white 24 24.5 120 - LF05E-R1 4008321955418 red 36 36 120 625 LF05E-Y1 4008321955432 yellow 36 36 120 587 LF05E-T2 4008321955449 green 24 24.5 120 525 LF05E-B2 4008321955425 blue 24 24.5 120 470 Productreference LF05E-W2F-830 3000 6000 8 2.5 150 8 1 LF05E-W2F-840 4000 6000 8 2.5 150 8 1 LF05E-R1 - 6000 8 2.5 150 8 1 LF05E-Y1 - 6000 8 2.5 150 8 1 LF05E-T2 - 6000 8 2.5 150 8 1 LF05E-B2 - 6000 8 2.5 150 8 1 LINEARlight Flex ® LF05E 1 LINEARlight Flex ® Lighting systems are a permanent feature of modern architecture as they skillfully enhance the appearanceof external structures of all sizes. LED modules on flexible boards are the number one choice for creating three-dimensional forms and contours with strip lighting. Special features NEW: LF05E with smaller dimensions and additional cutting options thanks to the use of • the LF-2TERM end capLow height for low-profile surface/enclosed mounting • Simplified connection with the optional CONNECTsystem • Low thermal output • Flexible 3-D mounting possible • Flexible board with double-sided adhesive tape for simple mounting • Can be divided into the smallest unit or multiples thereof without affecting the function of the remainder of • the boardDimmable by pulse width modulation (PWM) • Applications Injection of light in displays and low-profile light guides • Information signs, advertising or display cabinet lighting • Backlighting of complex contours • For decorative applications: LF05E • Optional accessories CONNECTsystem for monochrome 8 mm wide flex modules (see page 9.31) • LINEARlight Track (see page 9.39) • NEW NEW NEW NEW NEW NEW
9.14 Productreference Productnumber LM10P-W3F-827 1) 4008321940537 white 120 24 72 120 LM10P-W3F-830 1) 4008321350565 white 120 24 72 120 LM10P-W3F-840 1) 4008321350886 white 120 24 72 120 LM10P-W3F-854 1) 4008321215482 white 120 24 48 120 LM10P-W4F-854 1) 4008321310798 white 120 24 72 120 Productreference LM10P-W3F-827 1) 2700 2800 10.3 2.5 140 8 1 LM10P-W3F-830 1) 3000 2800 10.3 2.5 140 8 1 LM10P-W3F-840 1) 4000 2800 10.3 2.5 140 8 1 LM10P-W3F-854 1) 5400 2800 10.3 2.5 140 8 1 LM10P-W4F-854 1) 5400 2800 10.3 2.5 140 8 1 1) Modules perfectly matched to 24 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values LINEARlight POWER Flex 1 LINEARlight POWER FlexThe brightest flexible LED modules in our range can be used to create stunning accent lighting. Their breathtaking light pierces the darkest night. LINEARligh POWER Flex modules show their strengths in areas where architectural structures are to be emphasized and enhanced with optical effects. Powerful light and flexibility combined in an extremely compact form. Special features Can be divided into units of six LEDs or multiples thereof with no loss of function for the parts • Can be connected to the front of the module or at the division points • Optional CONNECTsystem for simple connection • Flexible board with self-adhesive backing • Dimmable by pulse width modulation (PWM) • Small height for low-profile lighting solutions • NEW: Successor generation available from summer 2010 with improved product characteristics • Applications Ideal for lighting counters, arches or handrails and also for edge lighting • For illuminating or backlighting transparent or light-dispersing materials • Optional accessories CONNECTsystem for monochrome 10 mm wide flex modules (see page 9.30) • LINEARlight Track (see page 9.39) •
9.15 Productreference Productnumber LM01A-W3F-827 1) 4008321372390 white 32 10 4 120 LM01A-W3F-840 1) 4008321343413 white 32 10 4 120 LM01A-W3F-854 1) 4008321387950 white 32 10 4 120 LM01A-A1 1) 4050300887128 red 32 10 4 120 LM01A-S1 1) 4050300888002 super red 32 10 4 120 LM01A-O1 1) 4050300888040 orange 32 10 4 120 LM01A-Y1 1) 4008321015969 yellow 32 10 4 120 LM01A-T2 1) 4050300887845 green 32 10 4 120 LM01A-B2 1) 4008321313652 blue 32 10 4 120 Productreference LM01A-W3F-827 1) - 2700 448 10 4 56 10 1 LM01A-W3F-840 1) - 4000 448 10 4 56 10 1 LM01A-W3F-854 1) - 5400 448 10 4 56 10 1 LM01A-A1 1) 617 - 448 10 4 56 10 1 LM01A-S1 1) 633 - 448 10 4 56 10 1 LM01A-O1 1) 606 - 448 10 4 56 10 1 LM01A-Y1 1) 587 - 448 10 4 56 10 1 LM01A-T2 1) 525 - 448 10 4 56 10 1 LM01A-B2 1) 470 - 448 10 4 56 10 1 1) Modules perfectly matched to 10 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values LINEARlight 1 LINEARlightA straight line is the shortest distance between two points. That does not sound especially creative. But with LINEARlight this “shortest distance” becomes a brilliant design element. Optional accessories such as optics and the LINEARlight Track system open up even more design options. This module is suitable for universal use, and not without reason. Special features Low height for low-profile surface/enclosed mounting • Can be extended at will up to three modules, colors can be combined • Dimmable by pulse width modulation (PWM) • Module can be divided into small units without affecting the function of the remainder of the board • Applications Injection of light in low-profile light guides and displays • Linear structures in display cabinets and furniture • Marker lights for walkways and outlines (e.g. escape routes, edges and steps) • Optional accessories CONNECTsystem for LINEARlight (see page 9.32) • LINEARlight optics, tailored to the smallest unit of the LINEARlight module (see page 9.37) • LINEARlight Track (see page 9.39) •
9.16 Productreference Productnumber CM01E-W3-854 1) 4008321397041 white 9 24 Productreference CM01E-W3-854 1) 1.2 120 8.5 33 25 1 1) Modules perfectly matched to 24 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads| All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values COINlight ® 1 COINlight ® Point light sources are ideal for general and orientation lighting. As these applications often call for small low-profile recessed luminaires, the light sources used in them have to be designed accordingly. Thanks to their compact dimensions and ease of installation, COINlight ® modules are perfect for round luminaires. Special features Low height for low-profile enclosed fittings • Connected with screw terminals • Dimmable by pulse width modulation (PWM) • Applications Recessed floor, wall and ceiling luminaires • Light source for marker luminaires (e.g. marking walkways and paths) •
9.17 Productreference Productnumber CL05A-RGB 1) 4008321208262 RGB 5 24 1.2 Productreference CL05A-RGB 1) 120 625/525/467 4 33 25 1 1) Modules perfectly matched to 24 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values COINlight ® Colormix 1 COINlight ® Colormix COINlight ® Colormix has an extremely small height so it is ideal for accurate accent lighting in very low-profile recessed luminaires for installation in walls, floors or ceilings. Its color effect is impressive not just as an interior design element but also for route lighting and marker lighting. Special features Compact round RGB module with five MULTILED • ® units Connection possible by soldering wires on the surface and from underneath • Mounting with self-adhesive backing or with M3 screws • Dimmable by pulse width modulation (PWM) • Applications Suitable for backlighting, for recessed luminaires and for recessed floor lights • Dynamic color applications, accent lighting in furniture, counters or display cabinets •
9.18 Productreference Productnumber LD18A-RGB 1) 4008321248572 RGB 18 24 23 Productreference LD18A-RGB 1) 120 616/531/468 600 20 7 6 1 1) Modules perfectly matched to 24 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values LINEARlight-DRAGON ® Colormix, basic module 1 LINEARlight-DRAGON ® Colormix The high-performance basic LINEARlight-DRAGON ® Colormix module offers intense color effects. 18 powerful Golden DRAGON ® LEDs on a narrow low-profile metal core board provide dynamic color for installation in luminaires or in coving. Special features LD-4PIN feeder included • The board can also be connected by soldering cables • Up to two modules can be connected one after the other • Dimmable by pulse width modulation (PWM) • Applications Intensive color effects for special moods • Board for luminaire installation and medium to large coving • Grazing light or wallwash effects also possible with OP1x1 optics • Optional accessories CONNECTsystem for LINEARlight-DRAGON • ® Colormix (see page 9.33)
9.19 Productreference Productnumber LD18A-RGB-14x22 1) 4008321251787 RGB 18 24 23 Productreference LD18A-RGB-14x22 1) 14 x22 616/531/468 607 35.9 25.8 6 1 1) Modules perfectly matched to 24 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values LINEARlight-DRAGON ® Colormix, complete module 1 LINEARlight-DRAGON ® Colormix The high-performance overall LINEARlight-DRAGON ® Colormix module offers intense color effects. 18 powerful Golden DRAGON ® LEDs in a designer casing with optimum thermal properties provide wall- wash effects even in the smallest of spaces thanks to the asymmetrical optics. Special features LD-4PIN feeder included • The board can also be connected by soldering cables • Up to two modules can be connected one after the other • Dimmable by pulse width modulation (PWM) • Overall module LD18A-14x22 with aluminum casing and 14x22º beam angle for wallwash effects • Applications Intensive color effects for special moods • Overall system ideal for wallwash effects indoors, even in small rooms or stairwells • Optional accessories CONNECTsystem for LINEARlight-DRAGON • ® Colormix (see page 9.33) LINEARlight-DRAGON • ® mounting brackets (see page 9.38)
9.20 Productreference Productnumber DC24A-RGB 1) 4008321251831 RGB 24 24 23 135 Productreference DC24A-RGB 1) 625/525/467 3000 39 5.6 500 6 1 1) Modules perfectly matched to 24 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values DRAGONchain ® Colormix, basic module 1 DRAGONchain ® Colormix basic and overall module Large lettering and light boxes produce their full color and signal effects only if they are uniformlyilluminated. DRAGONchain ® Colormix is a versatile LED chain comprising six metal core boards each with four high-flux Golden DRAGON ® Argus LEDs which emit their powerful light to the side. This means the light colors are ideally mixed and large surfaces are uniformly illuminated. Special features Coated for outdoor use (IPX5) • Simple connection with open cable ends • Up to two modules can be operated on an OT EASY 60 • Dimmable by pulse width modulation (PWM) • Fixed mounting with M4 screws • The mid-point spacing of the boards of 50 cm enables an area of 1 m² to be backlit uniformly • with one chain, with a light box depth of around 20 cm and medium transmissivity of the diffuserWith a minimum spacing of 10 cm between the top of the module and the appropriate diffuser an area of • approximately 0.5 m² can be uniformly backlit with one chainThe heat sink (see page 9.21) integrated in the package makes applications easier • The robust ribbon cables between boards can be bent • Applications Dynamic colored backlighting over large areas/light boxes • Floor mounting, mood lighting • Wellness, exhibition and shop lighting •
9.21 Productreference Productnumber DC24A-RGB-H 1) 4008321254658 RGB 24 24 23 135 Productreference DC24A-RGB-H 1) 625/525/467 3000 64 24 500 6 1 1) Modules perfectly matched to 24 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values DRAGONchain ® Colormix, complete module 1 DRAGONchain ® Colormix basic and overall module Large lettering and light boxes produce their full color and signal effects only if they are uniformlyilluminated. DRAGONchain ® Colormix is a versatile LED chain comprising six metal core boards each with four high-flux Golden DRAGON ® Argus LEDs which emit their powerful light to the side. This means the light colors are ideally mixed and large surfaces are uniformly illuminated. Special features Coated for outdoor use (IPX5) • Simple connection with open cable ends • Up to two modules can be operated on an OT EASY 60 • Dimmable by pulse width modulation (PWM) • Fixed mounting with M4 screws • The mid-point spacing of the boards of 50 cm enables an area of 1 m² to be backlit uniformly • with one chain, with a light box depth of around 20 cm and medium transmissivity of the diffuserWith a minimum spacing of 10 cm between the top of the module and the appropriate diffuser an area of • approximately 0.5 m² can be uniformly backlit with one chainThe heat sink integrated in the package makes applications easier • The robust ribbon cables between boards can be bent • Applications Dynamic colored backlighting over large areas/light boxes • Floor mounting, mood lighting • Wellness, exhibition and shop lighting •
9.22 Productreference Productnumber LM10L-RGB-B7 1) 4008321008824 RGB 200 24 55.2 120 LM10L-RGB2-B7 1) 4008321285317 RGB 200 24 41 120 LM10L-RGB2-B6 1) 4008321288714 RGB 200 24 41 120 Productreference LM10L-RGB-B7 1) 617/525/467 4000 11.5 2.2 200 8 1 LM10L-RGB2-B7 1) 625/525/467 4000 11.5 2.2 200 8 1 LM10L-RGB2-B6 1) 625/525/465 4000 11.5 2.2 200 8 1 1) Modules perfectly matched to 24 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values LINEARlight Colormix Flex 1 LINEARlight Colormix FlexSweeping contours, smooth color transitions, dynamic lighting scenes. These are all possible only with LED modules that are flexible enough to flow with the surfaces on which they are mounted. LINEARlight Colormix Flex has been developed to provide dynamic colored accent lighting for rooms. Special features Can be divided into units of 10 LEDs or multiples thereof with no loss of function for the parts • Homogeneous color changing with 3 chips in one package • Toolless connection with the optional CONNECTsystem • Dimmable by pulse width modulation (PWM) • NEW: Successor generation available from summer 2010 with improved product characteristics • Applications For lighting solutions with changing colors in linear structures and free forms • For injecting light into transparent and dispersing materials • Effect lighting in architecture • Dynamic effects in public zones • Optional accessories CONNECTsystem for LINEARlight Colormix Flex (see page 9.34) • LINEARlight Track (see page 9.39) •
9.23 Productreference Productnumber LM01M-RGB-B7 1) 4050300820873 RGB 30 24 8.3 120 Productreference LM01M-RGB-B7 1) 617/525/467 2) 450 11.5 3.5 150 10 1 1) Modules perfectly matched to 24 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values2) Red; Green; Blue LINEARlight Colormix 1 LINEARlight ColormixShop interiors attract our attention with magical color-changing light and have a stimulating effect on our purchasing behavior. Lighting effects can be used to make it appear as though shelving and counters are floating in the air. LINEARlight Colormix also shows how versatile it is when used to illuminate furniture and decorative interiors. Special features Low thermal output • Rigid module, can be divided into small units without affecting the function of the remainder of the board • Toolless connection with the optional CONNECTsystem with connector and feeder • Dimmable by pulse width modulation (PWM) • Applications For lighting solutions with changing colors in linear structures • For injecting light into transparent and dispersing materials • Effect lighting in architecture • Dynamic light as an architectural effect in public zones • Optional accessories• CONNECTsystem for LINEARlight Colormix (see page 9.35)• LINEARlight Track (see page 9.39)
9.24 Productreference Productnumber BL02L-W4F-765 1) 4008321372277 white 240 10 44 BL02S-A1 1) 4008321083715 red 240 10 38 BL02S-A2 1) 4008321174932 red 240 10 38 Productreference BL02L-W4F-765 1) 120 - 6500 14400 2) 4 120 5 BL02S-A1 1) 120 617 - 9600 3) 4 80 5 BL02S-A2 1) 120 617 - 9600 3) 4 80 5 1) Modules perfectly matched to 10 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values2) 2x7.2 m = 14.4 m3) 2x4.8 m = 9.6 m BACKlight BL02 BACKlight BL02Advances in lighting technology have meant that demands relating to the uniform illumination of complex signage shapes have grown enormously. Narrow and flat lettering and close letter spacing represent major challenges. In these cases, the long BACKlight LED chains provide optimum backlighting. Special features New type W4F with twice the brightness • A reel comprises 2 LEDs chains consisting of 60 boards • with 2 LEDs each or 30 boards with 4 LEDs eachThe flexible cables enable the luminance to be individually adjusted • Installation “from the reel” and simple connection to the control gear reduces • installation costs considerablyThe small height and wide beam angle enable extremely low-profile lettering • to be created with uniform illuminationSplit points between the individual boards make it easier to prepare the boards • and mount them in letteringThe boards are coated at the factory to protect them against moisture and condensate • The boards are installed with screws or self-adhesive installation aid BL-T • Dimmable by pulse width modulation (PWM) • Applications Signage • Ideal for mounting in small lettering • Backlighting of complex contours • Optional accessories Mounting aid for BACKlight and BACKlight Protect (BL-T) (see page 9.38) • 1
9.25 Productreference Productnumber BL02LP-W3F-830 1) 4008321375537 white 240 10 44 BL02LP-W4F-765 1) 4008321375414 white 240 10 44 BL02LP-R2-HE 1) 4008321403575 red 240 10 22 BL02LP-O2-HE 1) 4008321403599 orange 240 10 22 BL02LP-T2-HE 1) 4008321403551 green 240 10 22 BL02LP-B2-HE 1) 4008321403537 blue 240 10 22 Productreference BL02LP-W3F-830 1) 120 - 3000 14400 2) 120 5 1 BL02LP-W4F-765 1) 120 - 6500 14400 2) 120 5 1 BL02LP-R2-HE 1) 120 625 - 14400 2) 120 5 1 BL02LP-O2-HE 1) 120 603 - 14400 2) 120 5 1 BL02LP-T2-HE 1) 120 522 - 14400 2) 120 5 1 BL02LP-B2-HE 1) 120 467 - 14400 2) 120 5 1 1) Modules perfectly matched to 10 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values2) 2x7.2 m = 14.4 m BACKlight Protect BL02 1 BACKlight Protect BL02Anything that spends all its life on the front of a building has to withstand so much water, dust and dirt. BACKlight Protect modules are setting new standards in moisture resistance and robustness. With their new special encapsulation, impressive output, sharp light beams and long life these lighting systems have become firmly established in the signage industry. Special features New type W4F with twice the brightness • NEW: Special encapsulation of the LED carriers for maximum robustness for installation and operation • NEW: IP66 protection for permanent outdoor use in lettering and light boxes • A reel comprises 2 LEDs chains consisting of 60 boards each with 2 LEDs (BL02LP) or • 30 boards each with 4 LEDs (BL04LP)The flexible cables enable the luminance to be individually adjusted • Installation “from the reel” and simple connection to the control gear reduces installation costs • considerablyThe small height and wide beam angle enable extremely low-profile lettering to be created with • uniform illuminationSplit points between the individual boards make it easier to prepare the boards and mount them in • letteringThe boards are installed with screws or self-adhesive installation aid • Dimmable by pulse width modulation (PWM) • Applications Signage • Backlighting of complex contours • Ideal as efficient light sources for small to medium size lettering • Optional accessories Mounting aid for BACKlight and BACKlight Protect (BL-TP) (see page 9.38) •
9.26 Productreference Productnumber BL04LP-W4F-765 1) 4008321375650 white 240 10 44 Productreference BL04LP-W4F-765 1) 120 6500 7200 2) 120 5 1 1) Modules perfectly matched to 10 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values2) 2x3.6 m = 7.2 m BACKlight Protect BL04 1 BACKlight Protect BL04Anything that spends all its life on the front of a building has to withstand so much water, dust and dirt. BACKlight Protect modules are setting new standards in moisture resistance and robustness. With their new special encapsulation, impressive output, sharp light beams and long life these lighting systems have become firmly established in the signage industry. Special features New type W4F with twice the brightness • NEW: Special encapsulation of the LED carriers for maximum robustness for installation and operation • NEW: IP66 protection for permanent outdoor use in lettering and light boxes • A reel comprises 2 LED chains consisting of 60 boards each with 2 LEDs (BL02LP) or • 30 boards each with 4 LEDs (BL04LP)The flexible cables enable the luminance to be individually adjusted • Installation “from the reel” and simple connection to the control gear reduces installation costs • considerablyThe small height and wide beam angle enable extremely low-profile lettering to be created with • uniform illuminationSplit points between the individual boards make it easier to prepare the boards and mount • them in letteringThe boards are installed with screws or self-adhesive installation aid • Dimmable by pulse width modulation (PWM) • Applications Signage • Backlighting of complex contours • Ideal as efficient light sources for small to medium size lettering • Optional accessories Mounting aid for BACKlight and BACKlight Protect (BL-TP) (see page 9.38) •
9.27 Productreference Productnumber DC02C-W4F-765 1) 4008321410757 white 36 24 36 DC02C-W4F-830 1) 4008321410962 white 36 24 36 Productreference DC02C-W4F-765 1) 170 6500 5400 20 200 6 1 DC02C-W4F-830 1) 170 3000 5400 20 300 6 1 1) Modules perfectly matched to 24 V OSRAM OPTOTRONIC ® electronic control gear | For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values DRAGONchain ® 1 DRAGONchain ® Modern LED systems have clear advantages over neon tubes or fluorescent lamps even for illuminating oversize lettering. Reduced maintenance costs and longer life enhance the efficiency of LED systems. And thanks to its small dimensions DRAGONchain ® can efficiently illuminate even deep and complex structures right into the furthest corners. Special features A module comprises an LED chain consisting of 18 metal core boards each with • 2 OSRAM Golden DRAGONPlus ® LEDs Outstanding luminous efficacy of 80 lm/W • The flexible cables enable the luminance to be individually adjusted • Installation and simple connection to the control gear reduce installation costs considerably • The small height and wide beam angle ensure uniform illumination of the backlit structures • Dimmable by pulse width modulation (PWM) • Split points between the module sections make it easier to prepare the boards and mount • them in letteringThe boards are coated at the factory to protect them against moisture and condensate • Applications Ideal for mounting in large deep lettering or light boxes • Signage and corporate lighting • Backlighting of complex and deep structures • NEW NEW
9.28 STREETlight Advanced STREETlight AdvancedThe advantages of LED technology make the STREETlight Advanced module the modern, individual and sustainable solution for street lighting. The special optical concept of this LED module, constiting of LED, lens and reflector, offers exceptional optical efficiency and a street illumination that is uniform, sharply defi-ned and compliant with the relevant street lighting standards. STREETlight Advanced modules can be re-placed without the need for tools, which makes maintenance quick and easy. Upgrades to more efficient generations of LEDs without changing the system interfaces are now possible for the first time in a modular concept. The long life of the module holder and LED lamp element and the constant dimensions underline the sustainability of this technology. Special features Optimum illumination of the street and sidewalks with no scattered light, in compliance with • relevant standards and anti-glare regulationsIntegrated lens/reflector system with an 80°x140° viewing angle • Very high efficiency for short payback times • Individual luminaire design thanks to compact, standardized module dimensions • Fast replacement of the lamp element thanks to snap-in design; no tools required • Integration of the Lamp socket in luminaire housing by means of M4 screws • Extremely long life • Available in 2 color temperatures • Up to 2 modules can be operated on one OPTOTRONIC • ® OT 75 E and OT 65 3DIM E Applications Technical street lighting • Decorative outdoor lighting • 1 2 3 Productreference Productnumber SLA1-L-145-760-L80x140 1) 4008321958853 24 30 80 x140 6000 SLA1-L-110-830-L80x140 1) 4008321958877 24 30 80 x140 3000 SLA1-SL-145-760-L80x140 1) 4008321960061 24 30 80 x140 6000 SLA1-SL-110-830-L80x140 1) 4008321960085 24 30 80 x140 3000 SLA1 socket 1) 4008321958891 - - - - Productreference SLA1-L-145-760-L80x140 1) - 93.6 72 44.8 20 1 SLA1-L-110-830-L80x140 1) - 93.6 72 44.8 20 1 SLA1-SL-145-760-L80x140 1) 1.5/20 98 72 50.8 20 2 SLA1-SL-110-830-L80x140 1) 1.5/20 98 72 50.8 20 2 SLA1 socket 1) 1.5/20 96.7 72 20.3 20 3 1) For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values NEW NEW NEW NEW NEW
9.29 Productreference Productnumber SLP1-W4F-830-L75x130 1) 4008321964724 white 15 24 23 75 x130 SLP1-W4F-840-L75x130 1) 4008321964731 white 15 24 23 75 x130 SLP1-W4F-854-L75x130 1) 4008321964748 white 15 24 23 75 x130 SLP1-W4F-765-L75x130 1) 4008321964755 white 15 24 23 75 x130 STREETlight Protect 1 STREETlight ProtectThe STREETlight Protect module is ideal for fast realisation of energy-efficient street luminaire and offers attractive payback times. Type of protection IP 66 sets new standards of resistance to moisture and dirt for outdoor applications. The necessary cooling is achieved by the integrated heat sink. Due to the symmetrical radiation characteristic the module can be positioned at the side of the street or in the center for illumination in accordance with the standards. Special features Optimum Illumination of the street without scattered light, in compliance with relevant standards and anti- • glare regulationsIntegrated lens/reflector system with 75°x130° viewing angle • Individual luminaire design with highly integrated modules for short time-to-market • Long life and simplified luminaire design thanks to integrated heat sink • Type of protection IP66 to IEC 60529 • Three 600 mm connecting cables with spade lug terminal • Simple replacement of STREETlight Protect by means of M3 screws • Available in four different color temperatures • Up to 3 modules can be operated on one OPTOTRONIC • ® OT 75 E and OT 65 3DIM E Applications Technical street lighting • Decorative outdoor lighting • Productreference SLP1-W4F-830-L75x130 1) 3000 600 249.5 70 73.7 4 1 SLP1-W4F-840-L75x130 1) 4000 600 249.5 70 73.7 4 1 SLP1-W4F-854-L75x130 1) 5400 600 249.5 70 73.7 4 1 SLP1-W4F-765-L75x130 1) 6500 600 249.5 70 73.7 4 1 1) For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads | All the technical parameters apply to the entire module. In view of the complex manufacturing process for light emitting diodes, the typical values given above for the technical LED parameters are merely statistical values that do not necessarily correspond to the actual technical parameters of an individual product; individual products may vary from the typical values NEW NEW NEW NEW
9.30 Productreference Productnumber LM-2PIN FLEX 4008321916211 25 2.1 0.14/26 500 LM-CONN-150 FLEX 4008321931375 25 2.1 0.057/30 150 LM-CONN-10 FLEX 4008321916259 25 2.1 0.057/30 10 Productreference LM-2PIN FLEX 100 1 LM-CONN-150 FLEX 100 2 LM-CONN-10 FLEX 200 3 CONNECTsystem for monochrome 10 mm wide flex modules 1 2 16,5 1 5 0 176,2 3 CONNECTsystemThe CONNECTsystem provides simple connection of LED modules with feeders and cable connectors. Tight spaces, extensive applications and complex structures are no problem at all. Special features Simple installation, no tools or soldering required • Reduced installation time • Low profile • Extremely vibration-proof • Permissible operating temperature perfectly matched to the module • Can be connected to the front of the module or at the division points • Shock and vibration-proof according to IEC 60068-2-6 and IEC 60068-2-27 • For use only in indoor applications or appropriately IP67 protected luminaires •
9.31 CONNECTsystem for monochrome 8 mm wide flex modules CONNECTsystemThe CONNECTsystem provides simple connection of LED modules with feeders and cable connectors. Tight spaces, extensive applications and complex structures are no problem at all. Special features Simple installation, no tools or soldering required • Reduced installation time • Low profile • Extremely vibration-proof • Permissible operating temperature perfectly matched to the module • Can be connected to the front of the module or at the division points • Shock and vibration-proof according to IEC 60068-2-6 and IEC 60068-2-27 • For use only in indoor applications or appropriately IP67 protected luminaires • Terminating connector LF-2TERM enables partial units of LINEARlight Flex • ® to be operated 1 2 3 4 Productreference Productnumber LM-2PIN 1) 4008321955326 25 3 0.14/26 500 LM-CONN-10 1) 4008321955333 25 3 0.057/30 10 LM-CONN-150 1) 4008321955340 25 3 0.057/30 150 LM-2TERM 1) 4008321955357 - - - - Productreference LM-2PIN 1) 4008321955326 100 1 LM-CONN-10 1) 4008321955333 200 2 LM-CONN-150 1) 4008321955340 100 3 LM-2TERM 1) 4008321955357 200 4 1) For current photometric data and important safety, installation and application information see www.osram.com/led-systems-downloads NEW NEW NEW NEW
9.32 Productreference Productnumber LM-2PIN 4008321908629 11 2 0.31/22 550 500 1 LM-2CONN 4008321908643 11 2 - - 500 2 LM-2CONN-50 4008321908667 11 2 0.31/22 48 500 3 CONNECTsystem for LINEARlight 1 6,10 13,60 5,00 500,00 2 4,65 11,20 6,10 3 48,00 CONNECTsystemThe CONNECTsystem provides simple connection of LED modules with feeders and cable connectors. Tight spaces, extensive applications and complex structures are no problem at all. Special features Simple installation, no tools or soldering required • Reduced installation time • Low profile • Extremely vibration-proof • Permissible operating temperature perfectly matched to the module • Can be connected to the front of the module or at the division points • Shock and vibration-proof according to IEC 60068-2-6 and IEC 60068-2-27 • For use only in indoor applications or appropriately IP67 protected luminaires • Productreference Productnumber LD-2CONN-100 4008321182883 100 2 0.13//26 100 500 1 LD-2CONN-40 4008321182869 100 2 0.13//26 40 500 2 LD-2PIN 4008321182845 100 2 0.2/24 500 500 3 CONNECTsystem for LINEARlight-DRAGON ® 1 1 0 0 2 4 0 3 1,50 5 0 0 1 0
9.33 Productreference Productnumber LM-4PIN 4008321931337 25 3 LD-4CONN-100 4008321931351 25 3 Productreference LM-4PIN 0.14/26 500 500 1 LD-4CONN-100 0.14/26 100 1000 2 CONNECTsystem for LINEARlight-DRAGON ® Colormix 1 10,16 500 3,5 9,2 6,83 10,16 3,5 9,2 3 1,94 6,83 2 3,5 9,2 3,5 9,2 6,83 6,83 10,16 10,16 CONNECTsystemThe CONNECTsystem provides simple connection of LED modules with feeders and cable connectors. Tight spaces, extensive applications and complex structures are no problem at all. Special features Simple installation, no tools or soldering required • Reduced installation time • Low profile • Extremely vibration-proof • Permissible operating temperature perfectly matched to the module • Can be connected to the front of the module or at the division points • Shock and vibration-proof according to IEC 60068-2-6 and IEC 60068-2-27 • For use only in indoor applications or appropriately IP67 protected luminaires • 100 3 1,94
9.34 Productreference Productnumber LM-4PIN FLEX 4008321916235 25 2.1 LM-CONN-10 FLEX 4008321916259 25 2.1 LM-CONN-150 FLEX 4008321931375 25 2.1 Productreference LM-4PIN FLEX 0.14/26 500 100 1 LM-CONN-10 FLEX 0.057/30 10 200 2 LM-CONN-150 FLEX 0.057/30 150 100 3 CONNECTsystem for LINEARlight Colormix Flex 1 2 3 16,5 1 5 0 176,2 CONNECTsystemThe CONNECTsystem provides simple connection of LED modules with feeders and cable connectors. Tight spaces, extensive applications and complex structures are no problem at all. Special features Simple installation, no tools or soldering required • Reduced installation time • Low profile • Extremely vibration-proof • Permissible operating temperature perfectly matched to the module • Can be connected to the front of the module or at the division points • Shock and vibration-proof according to IEC 60068-2-6 and IEC 60068-2-27 • For use only in indoor applications or appropriately IP67 protected luminaires •
9.35 Productreference Productnumber LM-4PIN 4008321908681 25 3 LM-4CONN-45 4008321116277 25 3 Productreference LM-4PIN 0.31/22 500 500 1 LM-4CONN-45 0.31/22 45 1000 2 CONNECTsystem for LINEARlight Colormix 1 8 ,9 5 12,5 0,45 1 1 ,0 0,45 7,3 50 6 ,2 2 7,3 6 ,2 7,3 45 CONNECTsystemThe CONNECTsystem provides simple connection of LED modules with feeders and cable connectors. Tight spaces, extensive applications and complex structures are no problem at all. Special features Simple installation, no tools or soldering required • Reduced installation time • Low profile • Extremely vibration-proof • Permissible operating temperature perfectly matched to the module • Can be connected to the front of the module or at the division points • Shock and vibration-proof according to IEC 60068-2-6 and IEC 60068-2-27 • For use only in indoor applications or appropriately IP67 protected luminaires •
9.36 Productreference Productnumber COHS-50 4008321299246 20 1 Heat sink 1 Heat sinkThe easy-to-install heat sink for COINlight ® Advanced provides optimum cooling for the module and prolongs its life.
9.37 Productreference Productnumber OP4x1 4008321908704 20 /white 26 80 1 LINEARlight Optics 1 Productreference Productnumber OP1x1-30 4008321909770 30 150 1 OP1x1-10 4008321909893 10 150 1 OP1x1-14x22 4008321909787 14 x22 150 1 DRAGONtape ® Optics 1 25 22 15,5 3216 25 9 3,2 LINEARlight OpticsLINEARlight Optics is an add-on optical element for LINEARlight LED modules that reduces the beam anglefrom 120° to 20° (white 26°). DRAGONtape ® Optics The optics reduce the beam angle from 120° depending on the light color. Whereas OP1x1-10 andOP1x1-30 distribute the light symmetrically, the distribution is asymmetrical with OP1x1-14x22.The optics can also be used for the LINEARlight-DRAGON ® single-board module. Special features High optical efficiency •
9.38 Productreference Productnumber LD-MB 4008321225672 300 1 LINEARlight-DRAGON ® mounting bracket 1 Productreference Productnumber BL-T 4008321161284 300 1 BL-TP 4008321301277 300 2 Installation aid for BACKlight and BACKlight Protect 1 2 LINEARlight-DRAGON ® Mounting bracket The movable brackets provide a degree of flexibility in the hole spacings for mounting LINEARlight-DRAGON ® and LINEARlight-DRAGON ® Colormix. Installation aid for BACKlight and BACKlight ProtectTo make installation quicker and simpler OSRAM offers a practical installation aid withself-adhesive backing as an accessory for BACKlight (BL-T) and for BACKlight Protect (BL-TP).
9.39 Productreference Productnumber LT-H047-S 4008321256805 464 1) 35.5 1) 37.5 1) 10 1 LT-H143-S 4008321256829 1424 1) 35.5 1) 37.5 1) 6 1 LT-H047-P 4008321239563 464 1) 35.5 1) 26.5 1) 10 1 LT-H143-P 4008321239587 1424 1) 35.5 1) 26.5 1) 6 1 1) Without end cap LINEARlight Track 1 LINEARlight TrackLINEARlight Track, the universal lightweight aluminum track system for flexible or rigid OSRAM LINEARlight LED modules. Special features Lightweight universal aluminum track system for flexible or rigid OSRAM LINEARlight LED modules • Two versions: Prismatic version for indirect lighting and diffused version for direct and uniform lighting • Simple assembly and installation of the LED modules, either individually or as strip lighting • Tracks available in two different lengths, can be shortened to any length • Optimum cooling of the LED modules for long life and maximum reliability • The PMMA covers have been optimized for the various applications and protect the LED modules • against dirt at the same timeComplete with mounting brackets and coupling elements •
