Totally Integrated Power – SENTRON 3VM Molded Case Circuit Breakers siemens.com/lowvoltage CatalogLV 31 Edition2015 PI_3VM_LV31_2015_umschlag_en.indd   1 PI_3VM_LV31_2015_umschlag_en.indd   1 28.04.2015   17:50:00 28.04.2015   17:50:00 © Siemens AG 2015

Siemens LV 31 · 2015 Related catalogs Contents Low-Voltage Power Distribution and LV 10 Electrical Installation Technology   SENTRON  •  SIVACON  •  ALPHA Protection, Switching, Measuring and Monitoring Devices, Switchboards and Distribution SystemsE86060-K8280-A101-A2-7600 Components for Industrial Control LV 16 Panels according to UL Standards SIRIUS  •  SENTRON  •  ALPHA E86060-K1816-A101-A3-7600 3VM Molded Case Circuit Breakers LV 31 SENTRON E86060-K1831-A101-A1-7600 ALPHA FIX LV 52 Terminal Blocks E86060-K1852-A101-A2-7600 Air circuit breakers  •  Molded case circuit breakers  •  Miniature circuit  breakers  •  Residual current protective devices / AFDDs  •  Fuse systems  •   Overvoltage protection devices  •  Switch disconnectors  •  Switching  devices  •  Transformers, power supply units and socket outlets  •  Busbar  systems  •  Measuring devices and power monitoring  •  Monitoring devices  •  Software  •  Switchboards  •  Busbar trunking systems  •  System cubicles,  system lighting and system air-conditioning  •  Distribution boards  •   Molded-plastic distribution systems  •  8WH2 spring-loaded terminals Circuit breakers  •  Air circuit breakers/Molded case switches  •   Molded case circuit breakers  •  Miniature circuit breakers  •  Fuse  systems  •  Switch disconnectors  •  Switching devices  •  Socket  outlets  •  Busbar systems  •  Measuring devices and power moni- toring  •  Molded-plastic distribution systems  •  Terminal blocks 3VM molded case circuit breakers up to 250 A, TM, 400 V, up to 55 kA •  Accessories and spare parts iPo plug-in terminals  •  iPo installation terminals  •   Spring-loaded terminals  •  Combination plug-in terminals  •   Insulation displacement terminals  •  Screw terminals  •   Accessories for terminal blocks Online Industry Mall   Information and Ordering Platformin the Internet: www.siemens.com/industrymall   Catalog PDF Internet: www.siemens.com/lowvoltage/infomaterial   Trademarks All product designations may be registered trademarks or product names of Siemens AG or other supplying companies. Third parties using these trademarks or product names for their own purposes may infringe upon the rights of the trademark owners. Further information about low-voltage power distribu-tion and electrical installation is available on the Internet at: www.siemens.com/lowvoltage Technical Support Expert advice on technical questions with a wide range of demand-optimized services for all our products and systems. www.siemens.com/lowvoltage/contact 3VM_U2_en.fm  Seite 1  Mittwoch, 6. Mai 2015  5:19 17 © Siemens AG 2015

Introduction 1 3VM Molded Case Circuit Breakers  up to 250 A, TM, 400 V, up to 55 kA 2 Accessories and Spare Parts 3 Appendix 4 3VM Molded Case Circuit Breakers Totally Integrated Power – SENTRON Catalog LV 31 · 2015 Refer to the Industry Mall for current updates of this catalog: www.siemens.com/industrymall © Siemens AG 2015 The products and systems listed in this cata-log are developed and manufactured using a certified quality management system in ac cordance with EN ISO 9001:2008. © Siemens AG 2015

2 Siemens LV 31 · 2015 Your economic solution The 3VM molded case circuit breaker is ideally suited to basic applications in infrastructure requiring a reliable and economic solution. In addition to a selection of basic units, the compact product portfolio also encompasses the essential accessory components that perfectly cover your central requirements. Rely on proven Siemens quality, and benefit at the same time from an excellent price-performance ratio. The 3VM molded case circuit breaker offers the following advantages:  • Compact portfolio for all basic applications • Superior cost effectiveness – the right performance at the  right price • Global and comprehensive Service & Support – at any time,  whatever your location • Reliable quality and punctual delivery – thanks to the global  standards of Siemens © Siemens AG 2015

3 Siemens LV 31 · 2015 Wide range of accessories for flexible use The 3VM molded case circuit breakers from the portfolio of SENTRON protection, switching, measuring and monitoring devices ensure the reliable protection of people and property as integral components of efficient power distribution systems. With the help of essential accessory components, they can be adapted flexibly, quickly and simply to central customer requirements.  1 2 3 4 5 6 7 1 2 3 4 5 6 7 Knowledge Manager Internal accessories Locking and interlocking Manual operators Residual current device (RCD) Plug-in technology, DIN rail adapter Connection technology I201_1920 4 © Siemens AG 2015

4 Siemens LV 31 · 2015 Notes © Siemens AG 2015

Siemens LV 31 · 2015 1 1 1 For further technical product information: Siemens Industry Online Support: www.siemens.com/lowvoltage/product-support  . → Entry type: Application exampleCertificateCharacteristicDownloadFAQManualProduct noteSoftware archiveTechnical data 3VM Molded Case Circuit Breakers 1/2 General data 1/2 – Overview 1/6 – Design 1/14 – Application Introduction © Siemens AG 2015

1/2 Siemens LV 31 · 2015 1 Introduction3VM Molded Case Circuit Breakers General data ■ Overview         Sizes The 3VM molded case circuit breakers are an integral compo-nent of our cost-effective power distribution system, and they are used to protect personnel and property assets. The new 3VM molded case circuit breakers set standards in the modularity of their internal and external accessories. The modu-larity of the accessory components across all sizes, and their speed of installation save time and cut costs. The new molded case circuit breakers are available in 3 and 4-pole versions (100 A, 160 A, 250 A) as well as in 1 and 2-pole versions (160 A). The circuit breakers are available with rated operational currents ranging from 16 A to 250 A and rated voltages up to 500 V, depending on the series and size. 3VM molded case circuit breakers The new 3VM molded case circuit breakers reliably perform all the tasks required for line protection. Features The key features of the 3VM series are: • Compact design • Depending on size: 1-pole to 4-pole versions • Depending on size: breaking capacities of  16 kA … 55 kA at 415 V, 3 or 4-pole breakers and 36 kA at 240 V,1-pole breakers • Fixed-mounted, plug-in version • Thermal-magnetic trip units • AC/DC applications • No derating up to +50 °C • Modular and easy-to-fit internal accessories with diverse  functions • Universal platform of accessories across all sizes Compact dimensions Thanks to a mounting depth of 70 mm and a cover size of 45 mm, the 3VM molded case circuit breakers of sizes 100 A, 160 A and 250 A are predestined for protecting cables and lines in the plant area, especially for the electrical installation area. For these applications, there is also a wide range of accessories available such as adapters for installation on standard mounting rails, as well as residual current devices (RCD110 and RCD210) that can be side-mounted. Thermal-magnetic trip unit A thermal-magnetic principle trip unit is the basic trip unit for providing overload and short-circuit protection. This has been developed for implementing economical, cost-efficient installa-tions. It is suitable for use in three-phase networks, AC networks, 400 Hz applications, and with DC currents. © Siemens AG 2015

1/3 Siemens LV 31 · 2015 1 Introduction 3VM Molded Case Circuit Breakers General data ✓ Available -- Not available Type 3VM10 3VM11 3VM11 3VM11 3VM12 Number of poles 3, 4 1 2 3, 4 3, 4 3VM molded case circuit breakers for line protection, standard applications             Electrical characteristics according to IEC 60947-2 Size 100 A 160 A 160 A 160 A 250 A Rated operational current I n at 50 °C ambient temperature A 16 … 100 16 … 160 16 … 160 16 … 160 200 ... 250 Rated operational voltage U e  AC 50/60 Hz V 500 415 415 500 500 Rated operational voltage U e  DC 50/60 Hz V 500 125 250 500 500 Rated insulation voltage U i V 690 500 500 690 690 Rated impulse withstand voltage U imp kV 8 8 8 8 8 Use in IT networks ✓ ✓ ✓ ✓ ✓ Frequency Hz 0 ... 400 0 ... 400 0 ... 400 0 ... 400 0 ... 400 Breaking capacity Extremely low breaking capacity B Breaking capacity I cu  / I cs rms value according to IEC 60947-2 220 - 240 V AC / 50/60 Hz kA 25 / 12 -- -- -- -- 380 - 415 V AC / 50/60 Hz kA 16 / 8 -- -- -- -- 440 V AC / 50/60 Hz kA 8 / 4 -- -- -- -- 500 V AC / 50/60 Hz kA 5 / 2.5 -- -- -- -- Low breaking capacity N Breaking capacity I cu  / I cs rms value according to IEC 60947-2 220 - 240 V AC / 50/60 Hz kA 36 / 18 25 / 18 36 / 27 36 / 27 -- 380 - 415 V AC / 50/60 Hz kA 25 / 12 5 / 3 25 / 18 25 / 18 -- 440 V AC / 50/60 Hz kA 16 / 8 -- -- 16 / 12 -- 500 V AC / 50/60 Hz kA 5 / 2.5 -- -- 7 / 5 -- Standard breaking capacity S Breaking capacity I cu  / I cs rms value according to IEC 60947-2 220 - 240 V AC / 50/60 Hz kA 55 / 18 36 / 27 55 / 41 55 / 41 55 / 41 380 - 415 V AC / 50/60 Hz kA 36 / 12 6 / 4 36 / 27 36 / 27 36 / 27 440 V AC / 50/60 Hz kA 20 / 8 -- -- 25 /18 25 /18 500 V AC / 50/60 Hz kA 7 / 2.5 -- -- 7 / 5 10 / 7 Medium breaking capacity M Breaking capacity I cu  / I cs rms value according to IEC 60947-2 220 - 240 V AC / 50/60 Hz kA -- -- -- 85 / 63 85 / 63 380 - 415 V AC / 50/60 Hz kA -- -- -- 55 / 41 55 / 41 440 V AC / 50/60 Hz kA -- -- -- 36 / 27 36 / 27 500 V AC / 50/60 Hz kA -- -- -- 10 / 5 15 / 10 Breaking capacity DC 125 V DC / 50/60 Hz kA -- 25 -- -- -- 250 V DC / 50/60 Hz kA -- -- 55 -- -- 500 V DC / 50/60 Hz kA 55 -- -- 85 85 B N S M © Siemens AG 2015

1/4 Siemens LV 31 · 2015 1 Introduction3VM Molded Case Circuit Breakers General data ✓ Available -- Not available Type 3VM10 3VM11 3VM11 3VM11 3VM12 3VM molded case circuit breakers for line protection, standard applications           Service life (make-break operations) Mechanical 10000 12000 12000 12000 12000 Electrical 380 ... 415 V 2000 6000 6000 6000 6000 Trip units FTFM TM210 ✓ ✓ ✓ ✓ ✓ ATFM TM220 -- -- -- ✓ ✓ 3VM molded case circuit breakers for protecting starter combinations (standards and specifications IEC 60947-4) Rated operational current I n at 50 °C ambient temperature A -- -- -- 32 … 125 160, 200 Service life (make-break operations) Mechanical -- -- -- 12000 12000 Electrical 380 ... 415 V -- -- -- 6000 6000 Trip units AM TM120M -- -- -- ✓ ✓ Switch disconnectors Electrical characteristics according to IEC 60947-3 Number of poles -- -- -- 3, 4 3.4 Rated operational current I n at 50 °C ambient temperature A -- -- -- 63, 100, 125, 160 250 Rated operational voltage U e  AC 50/60 Hz V -- -- -- 500 500 Rated operational voltage U e  DC V -- -- -- 500 500 Rated short-circuit making capacity I cm  with upstream circuit breaker kA -- -- -- 55 kA at 415 V On request Permissible rated short-time current I cw ±1s kA -- -- -- 2 On request Dimensions ABCD mmmmmmmm 76.2 (3p)/101.6 (4p)1307088 25.413070 88 50.81307088 76.2 (3p)/101.6 (4p) 1307088 105 (3p)/140 (4p)1587088 Weight 1-pole  Lug  terminal kg -- 0.35 -- -- -- 2-pole Lug  terminal kg -- -- 0.60 -- -- 3-pole Lug  terminal kg 0.90 -- -- 0.90 1.8 4-pole Lug  terminal kg 1.15 -- -- 1.15 2.3 General information Standards and specifications IEC 60947-2 IEC 60947-2 IEC 60947-2 IEC 60947-2 IEC 60947-2 Utilization category according to IEC 60947-2 A A A A A Power and infeed direction Top and bottom Top and bottom Top and bottom Top and bottom Top and bottom Standard connection system Lug terminal Lug terminal Lug terminal Lug terminal Lug terminal Isolating features according to IEC 60947 ✓ ✓ ✓ ✓ ✓ NSE0_01 159 D C A B © Siemens AG 2015

1/5 Siemens LV 31 · 2015 1 Introduction 3VM Molded Case Circuit Breakers General data Molded case circuit breakers and accessories in the system The new 3VM molded case circuit breakers come with a tailor-made portfolio of internal and external accessories which can be installed flexibly in any size of circuit breaker (depending on the type of accessory). The table below shows the molded case circuit breakers in or on which the accessories can be installed, and the sizes covered by the same accessory component:  Accessories Molded case circuit breakers 3VM 100 160 250 Auxiliary switches and alarm switches Auxiliary releases Connection technology Plug-in technology Front mounted rotary operator Door mounted rotary operator Locking technology: padlock Residual current device, mounted on the side (4-pole) Masking frame DIN rail adapter 1 2 3 4 5 6 7 1 2 3 4 5 6 7 Knowledge Manager Internal accessories Locking and interlocking Manual operators Residual current device (RCD) Plug-in technology, DIN rail adapter Connection technology I201_1920 4 © Siemens AG 2015

1/6 Siemens LV 31 · 2015 1 Introduction3VM Molded Case Circuit Breakers General data ■ Design    Integrated system The 3VM molded case circuit breakers set new standards, not only regarding technical features and functional scope, but design ergonomics too. When it comes to operation, functionality and installation, the new 3VM series is a fully integrated system. This principle is embodied in the basic units and in all internal and external accessories. The benefits offered by the internal and external accessories available for the 3VM molded case circuit breakers are: • Standardized methods of operation • Standardized functionality • Standardized installation procedures • Standardized accessories across all sizes 100 A ... 250 A  (e.g. auxiliary switches, auxiliary releases, etc.) The right circuit breaker for all installation conditions The new series of molded case circuit breakers can be equipped with additional components enabling them to be installed as fully functional switches in any location, a feature which affords maximum flexibility to system planners. The following components can be used to suit the installation location: • Handle • Front mounted rotary operator • Door mounted rotary operator When the 3VM molded case circuit breaker is in the OFF posi-tion, it reliably disconnects all current paths of the circuit in accordance with IEC 60947-2 and IEC 60204-1. The main switch functionality is not diminished by installation of the following accessories: • Manual operator • Residual current device Installation variants 3VM molded case circuit breakers are available in the following installation variants: All versions offer the full range of functions, e.g. they can be equipped with every kind of accessory. For maintenance purposes, the plug-in design also provides the option of quickly replacing the breaker, or establishing visible electrical isolation in the main circuit. 1 2 3 2 1 Fixed-mounted Plug-in technology DIN rail adapter 3 I20 1 _ 1 9 2 4 4 © Siemens AG 2015

1/7 Siemens LV 31 · 2015 1 Introduction 3VM Molded Case Circuit Breakers General data Ergonomic design of circuit breakers, control levers and control elements Clear status indication The possible switching positions of manual rotary operators are listed below: • ON  –  Red  marking • TRIP – Yellow marking • OFF – Green marking The handle clearly engages in one of these positions depending on the status of the molded case circuit breaker. The switching positions are color-coded so that you can identify the status of the circuit breaker at a glance. Broad range of accessories The internal accessories (e.g. alarm and auxiliary switches, auxiliary releases, etc.) all belong to one family and can be installed on any size of circuit breaker. The accessories are designed for quick and easy installation. The components are coded by color and design to ensure that they are always installed at the correct position in the circuit breaker. Connection technology A large selection of connection systems is available for the new series of 3VM molded case circuit breakers. The supported cable cross-sections are based on the size of the molded case circuit breaker and the cable terminals used. The terminals are fitted either internally or externally to the molded case circuit breaker. The connection system is easy to integrate in the new series of 3VM molded case circuit breakers. With it you can implement various front and rear main conductor connections for the molded case circuit breakers in both types of installation (fixed-mounted and plug-in). I20 1 _ 1 8 9 9 5 1 2 3 4 5 6 7 8 Box terminal Circular conductor terminal Circular conductor terminal, large Lug terminal Circular conductor terminal for 2 cables Front connection bars extended Front connection bars broadened Rear terminal flat 1 2 3 4 5 6 7 8 I20 1_ 192 20 © Siemens AG 2015

1/8 Siemens LV 31 · 2015 1 Introduction3VM Molded Case Circuit Breakers General data Technical details Circuit breaker identification Each 3VM molded case circuit breaker has labels displaying all the important technical information, enabling unique identifica-tion: Breaker labeling Front: Labeling Knowledge Manager By reading out the QR code using a smartphone and the "Siemens Industry Online Support" app, it is possible to view key product information via the Internet at any time.  Siemens provides the app free of charge. 2 3 4 1 Connection information label Label inserts (in accessories compartment) Key electrical data Internal accessories labels 2 1 3 4 I201_19371 3 2 1 4 6 7 9 10 5 8 Circuit breaker designation Approvals Knowledge Manager Production date Rated current Product version ETU type Article number Size and breaking capacity class Rating plate 7 6 8 9 10 1 2 3 4 5 I201_19370 © Siemens AG 2015

1/9 Siemens LV 31 · 2015 1 Introduction 3VM Molded Case Circuit Breakers General data Breaking capacity The rated ultimate short-circuit breaking capacity I cu  is the  maximum value of the short-circuit current which the protective device is capable of disconnecting in accordance with regula-tions. Up to this value, the protective device is also allowed to be used in a network. The new 3VM molded case circuit breakers are available with various breaking capacity classes according to size and rated operational current range. • Breaking capacity of the 3VM series, 2 to 4-pole at 415 V AC • Breaking capacity class of the 3VM series, 1-pole at 240 V AC Breaking capacity Class /  I cu Size 3VM 100 A 3 and 4-pole 3VM 160 A  2-pole 3VM 160 A  3 and 4-pole 3VM 250 A  3 and 4-pole B 16 kA ✓ -- -- -- N 25 kA ✓ ✓ ✓ -- S 36 kA ✓ ✓ ✓ ✓ M 55 kA -- -- ✓ ✓ Breaking capacity Class /  I cu Size 3VM 160 A  1-pole N 25 kA ✓ S 36 kA ✓ © Siemens AG 2015

1/10 Siemens LV 31 · 2015 1 Introduction3VM Molded Case Circuit Breakers General data Standards and guidelines The standards fulfilled by the 3VM molded case circuit breakers include: • IEC / EN 60947-1 • IEC / EN 60947-2 • IEC / EN 60947-2, Appendix B, H and M • IEC / EN 60947-3 • IEC / EN 60947-6-1 Electromagnetic compatibility The 3VM molded case circuit breakers meet the requirements of the following standards: • CISPR11, Class A and Class B • IEC / EN 60947-1, Appendix S • IEC / EN 60947-2, Appendix B, F, J and N The 3VM molded case circuit breakers are adequately resistant to the following factors: • Electrostatic charge • Electrostatic discharge • Electromagnetic waves, e.g. from transmission systems,  mobile phones, radio telephone sets and radar systems • Overvoltage, e.g. caused by lightning • Voltage surges Certificates You can find information on the available certification (CE, CCC, FM, marine approvals) on the Internet ( www.siemens.com/lowvoltage/product-support ). In the Entry List you can use the certificate type (general product approval, explosion protection, test certificates, shipbuilding, etc.) as a filter criterion. Ambient conditions • Pollution degree: Operation of the 3VM molded case circuit breakers is approved in accordance with IEC / EN 60947-1 and IEC / EN 60664-1 for pollution degree 3. • Ambient temperature: - The 3VM molded case circuit breakers are used at ambient  temperatures from -25 °C to +70 °C. At temperatures above +50 °C there are reductions in the rated operational current (derating). - The permissible storage temperature in original Siemens  packaging lies between -25 °C and +80 °C. • Special climatic requirements: The 3VM molded case circuit breakers can also be used in severe operating conditions. Severe conditions for storage, transport and stationary use:The molded case circuit breakers have passed the relevant special tests according to IEC / EN 60947-1, Appendix Q for use in Class E.This class covers the areas MC3 + CC2 + SC1:- Ambient temperature- Humidity- Vibration environment- Shock environment These ambient conditions can be referred to as "Open deck, damp and cold atmosphere without salt spray" or "Difficult, non-marine conditions".The following standards-related criteria are complied with: - IEC / EN 60068-2-2 "Bd" and IEC / EN 60068-2-1 "Ab": Temperature range: -25 °C … +70 °C - IEC / EN 60068-2-30 "Db": Humid heat up to 55 °C and air humidity up to 95 % - IEC / EN 60068-2-6 "Fc" Vibration test - IEC / EN 60068-2-27 "Ea" Shock resistance test Between the tests of compliance with the standards and at the end of the tests, the usability of the devices is assured with the "Verification of operation characteristics". • Vibration resistance and shock resistance: - 3VM molded case circuit breakers are insensitive to vibra- tions and meet the requirements relating to mechanical and electromechanical vibration strength according to IEC / EN 60068 and the specifications of the shipbuilding societies. - The circuit breakers resist impacts without tripping of up to  10 g and are tested to withstand their operating conditions without damage, with shock impact according to IEC / EN 60068-2-27 "Ea" with 150 m/s²/11 ms. • Installation altitudes: - When the 3VM molded case circuit breakers are used at up  to 2000 m above sea level, the rated data will not change. - An installation altitude above 2000 m can lead to higher tem- peratures at the switching devices. The decreased air den-sity can significantly reduce heat dissipation, in turn reduc-ing rated operational voltage, rated uninterrupted current and short-circuit values.  Refer to the table below for the calculation factor for determining the key values: 1) At maximum ambient temperature 50 °C 2) Thermal-magnetic trip units only Permissible mounting positions Positions in which the 3VM molded case circuit breakers are installed Height 2000 m 3000 m 4000 m 5000 m Breaking capacity  I cu  /  I cs 1.00 0.90 0.80 0.70 Operating voltage U max 1.00 0.90 0.80 0.70 Operating current  I max 1) 1.00 0.96 0.92 0.88 Current setting  I r  2) 1.00 1.02 1.04 1.06 2 1 3 4 Vertical wall mounting Ceiling mounting Floor mounting Laterally rotated wall mounting 1 2 3 4 I201_19221 © Siemens AG 2015

1/11 Siemens LV 31 · 2015 1 Introduction 3VM Molded Case Circuit Breakers General data Further mounting positions, and mounting positions with accessories The following table shows the possible variations on the mounting positions, as well as mounting positions with accessories: Degrees of protection 3VM molded case circuit breakers comply with the following degrees of protection as defined by IEC 60529 and IEC 60947-1, Appendix C: A higher degree of protection up to IP65 can be achieved in combination with the following components: • Door mounted rotary operator Environmental protection The 3VM molded case circuit breakers meet the specifications of the European Environment Guideline 2002/95/EC RoHS (Restriction of the use of certain hazardous substances in elec-trical and electronic equipment). As little impact on the environ-ment as possible was emphasized in their development and pro-duction. Wall mounting Ceiling mounting Floor mounting verticalupright horizontalright horizontalleft verticalrotated suspended recumbent 3VM molded case circuit breakers Basic circuit breaker (with internal accessories) ✓ ✓ ✓ ✓ ✓ ✓ On DIN rail (with internal accessories) ✓ ✓ ✓ ✓ -- ✓ 3VM molded case circuit breaker (3 and 4-pole) with accessories Connection technology ✓ ✓ ✓ ✓ ✓ ✓ Plug-in technology ✓ ✓ ✓ ✓ -- -- Front mounted rotary operator ✓ ✓ ✓ ✓ ✓ ✓ Door mounted rotary operator ✓ ✓ ✓ ✓ ✓ ✓ Loadside RCD basic type A(RCD110, RCD210) ✓ ✓ ✓ ✓ ✓ ✓ 3-pole on 60 mm busbar system (with internal accessories) ✓ -- -- -- -- -- I201_19222 I201_19223 I201_19224 I201_19225 I201_19226 I201_19227 I201_19228 I201_19229 I201_19230 1 2 3 1 3 2 2 Accessories cover Terminal cover Without Level With Without With Front panel without  termination area Front panel termination area Infeed/load ends 1 2 3 I20 1 _ 1 923 0 -- IP4x IP3x -- IP2x -- IP4x -- -- -- -- -- © Siemens AG 2015

1/12 Siemens LV 31 · 2015 1 Introduction3VM Molded Case Circuit Breakers General data Protection system Description of functions The table below illustrates the applications for which different types of thermal-magnetic trip units can be used: 1) 3VM10 only without N protection3VM11/3VM12 with or without 100% N protection Thermal-magnetic TM 2-series TM120M AM TM210 FTFM TM220 ATFM Protection Starter protection ✓ -- -- Line protection -- ✓ ✓ Version available with 100 A 3-pole -- ✓ -- 4-pole -- ✓ -- 160 A 1-pole ✓ ✓ -- 2-pole -- ✓ -- 3-pole -- ✓ ✓ 4-pole -- ✓ ✓ 250 A 3-pole ✓ ✓ ✓ 4-pole -- ✓ ✓ Available protection parameters I r  adjustable -- -- ✓ I i  adjustable ✓ -- -- I r  fixed -- ✓ -- I i  fixed -- ✓ ✓ I N 1) -- ✓ ✓ Integrated functions Parameterizing Setting and reading the parameters in A -- Setting and reading the parameters in A Ii /A I201_19240 TM210 I201_19253 Ir/A Ir I201_19254 Ii /A Ir/A Ir © Siemens AG 2015

1/13 Siemens LV 31 · 2015 1 Introduction 3VM Molded Case Circuit Breakers General data Characteristic curves To design a low-voltage switchboard installation in accordance with the valid rules, the system planner needs to dimension the protection settings of the molded case circuit breakers. The settings selected for the trip unit of a molded case circuit breaker depend on the type of equipment to be protected. Trip-ping characteristics are represented graphically. In order to sim-plify the coordination of different protection devices, the current is specified as a multiple of the current setting value and the time is specified in seconds. Tripping characteristics L I L I 1 2 Response threshold of the long-time delayed protection, thermal Response threshold of the instantaneous protection Overload range Instantaneous short-circuit protection 1 2 t I202_28919 Low-voltage circuit breaker with TM trip unit © Siemens AG 2015

1/14 Siemens LV 31 · 2015 1 Introduction3VM Molded Case Circuit Breakers General data ■ Application    Detailed information about applications and possible uses Application 3VM Description Line protection ✓ The trip units for line protection are designed to provide overload and short-circuit protection for: • Cables • Lines • Non motorized loads Protection for starter combinations (starter protection) ✓ Starter combinations consist of: molded case circuit breaker + contactor + overload relay.  The molded case circuit breaker handles short-circuit protection and the isolating function. The task of the contactor is the operational switching of the feeder. The overload relay handles overload protection that can be specially matched to the motor. The molded case circuit breaker for the starter combination is therefore equipped with an adjustable and instanta-neous short-circuit release. Residual current protection ✓ Residual current protective devices afford fault protection (formerly referred to as: protection in case of indirect contact) and supplementary protection (formerly referred to as: protection in case of direct contact) in low-voltage systems in the event of the basic insulation failing or live parts being touched. Their task is to prevent or reduce injury to personnel or livestock, or damage to property. Switch disconnectors ✓ Switch disconnectors are deployed: • As main control switches • For on/off switching • For disconnection of loads • As switch disconnectors without overload and short-circuit protection The switch disconnectors correspond to IEC / EN 60947-3. I20 1 _ 1 92 4 5 I20 1 _ 1 9 4 2 9 I201_19369 I20 1 _ 1 9 4 3 0 © Siemens AG 2015

Siemens LV 31 · 2015 2 2 For further technical product information: Siemens Industry Online Support: www.siemens.com/lowvoltage/product-support  . → Entry type: Application exampleCertificateCharacteristicDownloadFAQManualProduct noteSoftware archiveTechnical data 2 2/2 Line protection  2/12 Starter protection 2/13 Switch disconnectors 2/14 Dimensional drawings 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Direct reference to the products in the Industry Mall from the selection and ordering data tables: 3VA2025-5HL36-0AA0  Article No. www.siemens.com/product?  Article No. Paper catalog:To get more product information enter the Web address plus Article No. PDF catalog:Get more product information with just a mouse click. © Siemens AG 2015

2/2 Siemens LV 31 · 2015  You can order this quantity or a multiple thereof. 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Line protection ■ Selection and ordering data                     PU (UNIT, SET, M) = 1 PS /P. unit = 1 UNIT PG = 173 Connection technology Type Rated current  I n Current setting of the inverse-time delayed overload protection "L" I r Operating current of the instanta-neous short-circuit protection "I" I i   DT I cu  up to 25 kA at 240 V,  low breaking capacity N See "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU A A A 1-pole, fixed-mounted, 3VM11, up to 160 A Thermal-magnetic trip unit Line protection, 1-pole, TM210 FTFM  With fixed overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal  3VM11 16 16 320 3VM1196-3ED12-0AA0 20 20 320 3VM1120-3ED12-0AA0 25 25 320 3VM1125-3ED12-0AA0 32 32 320 3VM1132-3ED12-0AA0 40 40 400 3VM1140-3ED12-0AA0 50 50 500 3VM1150-3ED12-0AA0 63 63 630 3VM1163-3ED12-0AA0 80 80 800 3VM1180-3ED12-0AA0 100 100 1000 3VM1110-3ED12-0AA0 125 125 1250 3VM1112-3ED12-0AA0 160 160 1600 3VM1116-3ED12-0AA0 Connection technology Type Rated current  I n Current setting of the inverse-time delayed overload protection "L" I r Operating current of the instanta-neous short-circuit protection "I" I i   DT I cu  up to 25 kA at 415 V,  low breaking capacity N See "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU A A A 2-pole, fixed-mounted, 3VM11, up to 160 A Thermal-magnetic trip unit Line protection, 2-pole, TM210 FTFM  With fixed overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal  3VM11 16 16 320 3VM1196-3ED22-0AA0 20 20 320 3VM1120-3ED22-0AA0 25 25 320 3VM1125-3ED22-0AA0 32 32 320 3VM1132-3ED22-0AA0 40 40 400 3VM1140-3ED22-0AA0 50 50 500 3VM1150-3ED22-0AA0 63 63 630 3VM1163-3ED22-0AA0 80 80 800 3VM1180-3ED22-0AA0 100 100 1000 3VM1110-3ED22-0AA0 125 125 1250 3VM1112-3ED22-0AA0 160 160 1600 3VM1116-3ED22-0AA0 N TM210 I201_19253 N TM210 I201_19253 © Siemens AG 2015

2/3 Siemens LV 31 · 2015  You can order this quantity or a multiple thereof. 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Line protection 1)  Start of delivery scheduled for 4th quarter 2015 PU (UNIT, SET, M) = 1 PS /P. unit = 1 UNIT PG = 173 Rated current I n DT I cu  to 36 kA at 240 V, standard breaking capacity S See "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU A Line protection, 1-pole, TM210 FTFM  With fixed overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal 16 3VM1196-4ED12-0AA0 20 3VM1120-4ED12-0AA0 25 3VM1125-4ED12-0AA0 32 3VM1132-4ED12-0AA0 40 3VM1140-4ED12-0AA0 50 3VM1150-4ED12-0AA0 63 3VM1163-4ED12-0AA0 80 3VM1180-4ED12-0AA0 100 3VM1110-4ED12-0AA0 125 3VM1112-4ED12-0AA0 160 3VM1116-4ED12-0AA0 Rated current I n DT I cu  to 36 kA at 415 V,  standard breaking capacity S See "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU A Line protection, 2-pole, TM210 FTFM  With fixed overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal 16 3VM1196-4ED22-0AA0 20 3VM1120-4ED22-0AA0 25 3VM1125-4ED22-0AA0 32 3VM1132-4ED22-0AA0 40 3VM1140-4ED22-0AA0 50 3VM1150-4ED22-0AA0 63 3VM1163-4ED22-0AA0 80 3VM1180-4ED22-0AA0 100 1) 3VM1110-4ED22-0AA0 125 1) 3VM1112-4ED22-0AA0 160 1) 3VM1116-4ED22-0AA0 S S © Siemens AG 2015

2/4 Siemens LV 31 · 2015 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Line protection  You can order this quantity or a multiple thereof. PU (UNIT, SET, M) = 1 PS /P. unit = 1 UNIT PG = 173 Connection technology Type Rated current I n Current setting of the inverse-time delayed overload protection "L" I r Operating current of the instanta-neous short-circuit protection "I" I i DT I cu  up to 16 kA at 415 V,  very low breaking capacity B See "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU A A A 3-pole, fixed-mounted, 3VM10, up to 100 A Thermal-magnetic trip unit Line protection, TM210 FTFM  With fixed overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal  3VM10 16 16 320 3VM1096-2ED32-0AA0 20 20 320 3VM1020-2ED32-0AA0 25 25 320 3VM1025-2ED32-0AA0 32 32 320 3VM1032-2ED32-0AA0 40 40 400 3VM1040-2ED32-0AA0 50 50 500 3VM1050-2ED32-0AA0 63 63 630 3VM1063-2ED32-0AA0 80 80 800 3VM1080-2ED32-0AA0 100 100 1000 3VM1010-2ED32-0AA0 B TM210 I201_19253 Connection technology Type Rated current I n Current setting of the inverse-time delayed overload protection "L" I r Operating current of the instanta-neous short-circuit protection "I" I i DT I cu  up to 25 kA at 415 V,  low breaking capacity N See "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU A A A 3-pole, fixed-mounted, 3VM11/3VM12, up to 250 A Thermal-magnetic trip unit Line protection, TM210 FTFM  With fixed overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal  3VM11 16 16 320 3VM1196-3ED32-0AA0 20 20 320 3VM1120-3ED32-0AA0 25 25 320 3VM1125-3ED32-0AA0 32 32 320 3VM1132-3ED32-0AA0 40 40 400 3VM1140-3ED32-0AA0 50 50 500 3VM1150-3ED32-0AA0 63 63 630 3VM1163-3ED32-0AA0 80 80 800 3VM1180-3ED32-0AA0 100 100 1000 3VM1110-3ED32-0AA0 125 125 1250 3VM1112-3ED32-0AA0 160 160 1600 3VM1116-3ED32-0AA0 3VM12 200 200 2000 -- 250 250 2500 -- Line protection, TM220 ATFM  With adjustable overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal  3VM11 16 11 ... 16 320 3VM1196-3EE32-0AA0 20 14 ... 20 320 3VM1120-3EE32-0AA0 25 18 ... 25 320 3VM1125-3EE32-0AA0 32 22 ... 32 320 3VM1132-3EE32-0AA0 40 28 ... 40 400 3VM1140-3EE32-0AA0 50 35 ... 50 500 3VM1150-3EE32-0AA0 63 44 ... 63 630 3VM1163-3EE32-0AA0 80 56 ... 80 800 3VM1180-3EE32-0AA0 100 70 ... 100 1000 3VM1110-3EE32-0AA0 125 88 ... 125 1250 3VM1112-3EE32-0AA0 160 112 ... 160 1600 3VM1116-3EE32-0AA0 3VM12 200 140 ... 200 2000 -- 250 175 ... 250 2500 -- N TM210 I201_19253 Ir/A Ir I201_19254 r © Siemens AG 2015

2/5 Siemens LV 31 · 2015  You can order this quantity or a multiple thereof. 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Line protection PU (UNIT, SET, M) = 1 PS /P. unit = 1 UNIT PG = 173 Rated current I n DT I cu  up to 25 kA at 415 V,  low breaking capacity N See "Overview", p. 1/3 DT I cu  to 36 kA at 415 V,  standard breaking capacity S See "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU Article No. www.siemens.com/product? Article No. Basic price per PU A Line protection, TM210 FTFM With fixed overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal 16 3VM1096-3ED32-0AA0 3VM1096-4ED32-0AA0 20 3VM1020-3ED32-0AA0 3VM1020-4ED32-0AA0 25 3VM1025-3ED32-0AA0 3VM1025-4ED32-0AA0 32 3VM1032-3ED32-0AA0 3VM1032-4ED32-0AA0 40 3VM1040-3ED32-0AA0 3VM1040-4ED32-0AA0 50 3VM1050-3ED32-0AA0 3VM1050-4ED32-0AA0 63 3VM1063-3ED32-0AA0 3VM1063-4ED32-0AA0 80 3VM1080-3ED32-0AA0 3VM1080-4ED32-0AA0 100 3VM1010-3ED32-0AA0 3VM1010-4ED32-0AA0 N S Rated current I n DT I cu  to 36 kA at 415 V,  standard breaking capacity S See "Overview", p. 1/3 DT I cu  up to 55 kA at 415 V,  medium breaking capacity MSee "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU Article No. www.siemens.com/product? Article No. Basic price per PU A Line protection, TM210 FTFM  With fixed overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal 16 3VM1196-4ED32-0AA0 3VM1196-5ED32-0AA0 20 3VM1120-4ED32-0AA0 3VM1120-5ED32-0AA0 25 3VM1125-4ED32-0AA0 3VM1125-5ED32-0AA0 32 3VM1132-4ED32-0AA0 3VM1132-5ED32-0AA0 40 3VM1140-4ED32-0AA0 3VM1140-5ED32-0AA0 50 3VM1150-4ED32-0AA0 3VM1150-5ED32-0AA0 63 3VM1163-4ED32-0AA0 3VM1163-5ED32-0AA0 80 3VM1180-4ED32-0AA0 3VM1180-5ED32-0AA0 100 3VM1110-4ED32-0AA0 3VM1110-5ED32-0AA0 125 3VM1112-4ED32-0AA0 3VM1112-5ED32-0AA0 160 3VM1116-4ED32-0AA0 3VM1116-5ED32-0AA0 200 3VM1220-4ED32-0AA0 3VM1220-5ED32-0AA0 250 3VM1225-4ED32-0AA0 3VM1225-5ED32-0AA0 Line protection, TM220 ATFM  With adjustable overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal 16 3VM1196-4EE32-0AA0 3VM1196-5EE32-0AA0 20 3VM1120-4EE32-0AA0 3VM1120-5EE32-0AA0 25 3VM1125-4EE32-0AA0 3VM1125-5EE32-0AA0 32 3VM1132-4EE32-0AA0 3VM1132-5EE32-0AA0 40 3VM1140-4EE32-0AA0 3VM1140-5EE32-0AA0 50 3VM1150-4EE32-0AA0 3VM1150-5EE32-0AA0 63 3VM1163-4EE32-0AA0 3VM1163-5EE32-0AA0 80 3VM1180-4EE32-0AA0 3VM1180-5EE32-0AA0 100 3VM1110-4EE32-0AA0 3VM1110-5EE32-0AA0 125 3VM1112-4EE32-0AA0 3VM1112-5EE32-0AA0 160 3VM1116-4EE32-0AA0 3VM1116-5EE32-0AA0 200 3VM1220-4EE32-0AA0 3VM1220-5EE32-0AA0 250 3VM1225-4EE32-0AA0 3VM1225-5EE32-0AA0 S M © Siemens AG 2015

2/6 Siemens LV 31 · 2015 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Line protection  You can order this quantity or a multiple thereof. PU (UNIT, SET, M) = 1 PS /P. unit = 1 UNIT PG = 173 Connection technology Type Rated currentI n Current setting of the inverse-time delayed overload protection "L" I r Operating current of the instanta-neous short-circuit protection "I" I i DT I cu  up to 16 kA at 415 V,  very low breaking capacity B See "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU A A A 4-pole, fixed-mounted, 3VM10, up to 100 A Thermal-magnetic trip unit Line protection, TM210 FTFM, without neutral conductor protection With fixed overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal  3VM10 16 16 320 3VM1096-2ED42-0AA0 20 20 320 3VM1020-2ED42-0AA0 25 25 320 3VM1025-2ED42-0AA0 32 32 320 3VM1032-2ED42-0AA0 40 40 400 3VM1040-2ED42-0AA0 50 50 500 3VM1050-2ED42-0AA0 63 63 630 3VM1063-2ED42-0AA0 80 80 800 3VM1080-2ED42-0AA0 100 100 1000 3VM1010-2ED42-0AA0 B TM210 I201_19253 Connection technology Type Rated current I n Current setting of the inverse-time delayed overload protection "L" I r Operating current of the instanta-neous short-circuit protection "I" I i DT I cu  up to 25 kA at 415 V,  low breaking capacity N See "Overview", p. 1/3  Article No. www.siemens.com/product? Article No. Basic price per PU A A A 4-pole, fixed-mounted, 3VM11/3VM12, up to 250 A Thermal-magnetic trip unit Line protection, TM210 FTFM, without neutral conductor protection  With fixed overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal  3VM11 16 16 320 3VM1196-3ED42-0AA0 20 20 320 3VM1120-3ED42-0AA0 25 25 320 3VM1125-3ED42-0AA0 32 32 320 3VM1132-3ED42-0AA0 40 40 400 3VM1140-3ED42-0AA0 50 50 500 3VM1150-3ED42-0AA0 63 63 630 3VM1163-3ED42-0AA0 80 80 800 3VM1180-3ED42-0AA0 100 100 1000 3VM1110-3ED42-0AA0 125 125 1250 3VM1112-3ED42-0AA0 160 160 1600 3VM1116-3ED42-0AA0 3VM12 200 200 2000 -- 250 250 2500 -- N TM210 I201_19253 © Siemens AG 2015

2/7 Siemens LV 31 · 2015  You can order this quantity or a multiple thereof. 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Line protection PU (UNIT, SET, M) = 1 PS /P. unit = 1 UNIT PG = 173 Rated current I n DT I cu  up to 25 kA at 415 V,  low breaking capacity N See "Overview", p. 1/3 DT I cu  to 36 kA at 415 V,  standard breaking capacity S See "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU Article No. www.siemens.com/product? Article No. Basic price per PU A Line protection, TM210 FTFM, without neutral conductor protection  With fixed overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal 16 3VM1096-3ED42-0AA0 3VM1096-4ED42-0AA0 20 3VM1020-3ED42-0AA0 3VM1020-4ED42-0AA0 25 3VM1025-3ED42-0AA0 3VM1025-4ED42-0AA0 32 3VM1032-3ED42-0AA0 3VM1032-4ED42-0AA0 40 3VM1040-3ED42-0AA0 3VM1040-4ED42-0AA0 50 3VM1050-3ED42-0AA0 3VM1050-4ED42-0AA0 63 3VM1063-3ED42-0AA0 3VM1063-4ED42-0AA0 80 3VM1080-3ED42-0AA0 3VM1080-4ED42-0AA0 100 3VM1010-3ED42-0AA0 3VM1010-4ED42-0AA0 N S Rated current I n DT I cu  to 36 kA at 415 V,  standard breaking capacity S See "Overview", p. 1/3 DT I cu  up to 55 kA at 415 V,  medium breaking capacity M See "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU Article No. www.siemens.com/product? Article No. Basic price per PU A Line protection, TM210 FTFM, without neutral conductor protection  With fixed overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal 16 3VM1196-4ED42-0AA0 3VM1196-5ED42-0AA0 20 3VM1120-4ED42-0AA0 3VM1120-5ED42-0AA0 25 3VM1125-4ED42-0AA0 3VM1125-5ED42-0AA0 32 3VM1132-4ED42-0AA0 3VM1132-5ED42-0AA0 40 3VM1140-4ED42-0AA0 3VM1140-5ED42-0AA0 50 3VM1150-4ED42-0AA0 3VM1150-5ED42-0AA0 63 3VM1163-4ED42-0AA0 3VM1163-5ED42-0AA0 80 3VM1180-4ED42-0AA0 3VM1180-5ED42-0AA0 100 3VM1110-4ED42-0AA0 3VM1110-5ED42-0AA0 125 3VM1112-4ED42-0AA0 3VM1112-5ED42-0AA0 160 3VM1116-4ED42-0AA0 3VM1116-5ED42-0AA0 200 3VM1220-4ED42-0AA0 3VM1220-5ED42-0AA0 250 3VM1225-4ED42-0AA0 3VM1225-5ED42-0AA0 S M © Siemens AG 2015

2/8 Siemens LV 31 · 2015 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Line protection  You can order this quantity or a multiple thereof. PU (UNIT, SET, M) = 1 PS /P. unit = 1 UNIT PG = 173 Connection technology Type Rated current I n Current setting of the inverse-time delayed overload protection "L" I r Operating current of the instanta-neous short-circuit protection "I" I i DT I cu  up to 25 kA at 415 V,  low breaking capacity N See "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU A A A 4-pole, fixed-mounted, 3VM11/3VM12, up to 250 A Thermal-magnetic trip unit Line protection, TM210 FTFM, 100 % neutral conductor protection  With fixed overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal  3VM11 16 16 320 3VM1196-3GD42-0AA0 20 20 320 3VM1120-3GD42-0AA0 25 25 320 3VM1125-3GD42-0AA0 32 32 320 3VM1132-3GD42-0AA0 40 40 400 3VM1140-3GD42-0AA0 50 50 500 3VM1150-3GD42-0AA0 63 63 630 3VM1163-3GD42-0AA0 80 80 800 3VM1180-3GD42-0AA0 100 100 1000 3VM1110-3GD42-0AA0 125 125 1250 3VM1112-3GD42-0AA0 160 160 1600 3VM1116-3GD42-0AA0 3VM12 200 200 2000 -- 250 250 2500 -- Line protection, TM220 ATFM, without neutral conductor protection  With adjustable overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal  3VM11 16 11 ... 16 320 3VM1196-3EE42-0AA0 20 14 ... 20 320 3VM1120-3EE42-0AA0 25 18 ... 25 320 3VM1125-3EE42-0AA0 32 22 ... 32 320 3VM1132-3EE42-0AA0 40 28 ... 40 400 3VM1140-3EE42-0AA0 50 35 ... 50 500 3VM1150-3EE42-0AA0 63 44 ... 63 630 3VM1163-3EE42-0AA0 80 56 ... 80 800 3VM1180-3EE42-0AA0 100 70 ... 100 1000 3VM1110-3EE42-0AA0 125 88 ... 125 1250 3VM1112-3EE42-0AA0 160 112 ... 160 1600 3VM1116-3EE42-0AA0 3VM12 200 140 ... 200 2000 -- 250 175 ... 200 2500 -- N TM210 I201_19253 Ir/A Ir I201_19254 r © Siemens AG 2015

2/9 Siemens LV 31 · 2015  You can order this quantity or a multiple thereof. 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Line protection PU (UNIT, SET, M) = 1 PS /P. unit = 1 UNIT PG = 173 Rated current I n DT I cu  to 36 kA at 415 V,  standard breaking capacity S See "Overview", p. 1/3 DT I cu  up to 55 kA at 415 V,  medium breaking capacity M See "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU Article No. www.siemens.com/product? Article No. Basic price per PU A Line protection, TM210 FTFM, 100 % neutral conductor protection  With fixed overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal 16 3VM1196-4GD42-0AA0 3VM1196-5GD42-0AA0 20 3VM1120-4GD42-0AA0 3VM1120-5GD42-0AA0 25 3VM1125-4GD42-0AA0 3VM1125-5GD42-0AA0 32 3VM1132-4GD42-0AA0 3VM1132-5GD42-0AA0 40 3VM1140-4GD42-0AA0 3VM1140-5GD42-0AA0 50 3VM1150-4GD42-0AA0 3VM1150-5GD42-0AA0 63 3VM1163-4GD42-0AA0 3VM1163-5GD42-0AA0 80 3VM1180-4GD42-0AA0 3VM1180-5GD42-0AA0 100 3VM1110-4GD42-0AA0 3VM1110-5GD42-0AA0 125 3VM1112-4GD42-0AA0 3VM1112-5GD42-0AA0 160 3VM1116-4GD42-0AA0 3VM1116-5GD42-0AA0 200 3VM1220-4GD42-0AA0 3VM1220-5GD42-0AA0 250 3VM1225-4GD42-0AA0 3VM1225-5GD42-0AA0 Line protection, TM220 ATFM, without neutral conductor protection  With adjustable overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal 16 3VM1196-4EE42-0AA0 3VM1196-5EE42-0AA0 20 3VM1120-4EE42-0AA0 3VM1120-5EE42-0AA0 25 3VM1125-4EE42-0AA0 3VM1125-5EE42-0AA0 32 3VM1132-4EE42-0AA0 3VM1132-5EE42-0AA0 40 3VM1140-4EE42-0AA0 3VM1140-5EE42-0AA0 50 3VM1150-4EE42-0AA0 3VM1150-5EE42-0AA0 63 3VM1163-4EE42-0AA0 3VM1163-5EE42-0AA0 80 3VM1180-4EE42-0AA0 3VM1180-5EE42-0AA0 100 3VM1110-4EE42-0AA0 3VM1110-5EE42-0AA0 125 3VM1112-4EE42-0AA0 3VM1112-5EE42-0AA0 160 3VM1116-4EE42-0AA0 3VM1116-5EE42-0AA0 200 3VM1220-4EE42-0AA0 3VM1220-5EE42-0AA0 250 3VM1225-4EE42-0AA0 3VM1225-5EE42-0AA0 S M © Siemens AG 2015

2/10 Siemens LV 31 · 2015 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Line protection  You can order this quantity or a multiple thereof. PU (UNIT, SET, M) = 1 PS /P. unit = 1 UNIT PG = 173 Connection technology Type Rated current I n Current setting of the inverse-time delayed overload protection "L" I r Operating current of the instanta-neous short-circuit protection "I" I i DT I cu  up to 25 kA at 415 V,  low breaking capacity N See "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU A A A 4-pole, fixed-mounted, 3VM11/3VM12, up to 250 A Thermal-magnetic trip unit Line protection, TM220 ATFM, 100 % neutral conductor protection  With adjustable overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal  3VM11 16 11 ... 16 320 3VM1196-3GE42-0AA0 20 14 ... 20 320 3VM1120-3GE42-0AA0 25 18 ... 25 320 3VM1125-3GE42-0AA0 32 22 ... 32 320 3VM1132-3GE42-0AA0 40 28 ... 40 400 3VM1140-3GE42-0AA0 50 35 ... 50 500 3VM1150-3GE42-0AA0 63 44 ... 63 630 3VM1163-3GE42-0AA0 80 56 ... 80 800 3VM1180-3GE42-0AA0 100 70 ... 100 1000 3VM1110-3GE42-0AA0 125 88 ... 125 1250 3VM1112-3GE42-0AA0 160 112 ... 160 1600 3VM1116-3GE42-0AA0 3VM12 200 140 ... 200 2000 -- 250 175 ... 200 2500 -- N Ir/A Ir I201_19254 r © Siemens AG 2015

2/11 Siemens LV 31 · 2015  You can order this quantity or a multiple thereof. 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Line protection PU (UNIT, SET, M) = 1 PS /P. unit = 1 UNIT PG = 173 Rated current I n DT I cu  to 36 kA at 415 V,  standard breaking capacity S See "Overview", p. 1/3 DT I cu  up to 55 kA at 415 V,  medium breaking capacity M See "Overview", p. 1/3 Article No. www.siemens.com/product? Article No. Basic price per PU Article No. www.siemens.com/product? Article No. Basic price per PU A Line protection, TM220 ATFM, 100 % neutral conductor protection  With adjustable overload protection I r  and fixed short-circuit protection I i   Connection with lug terminal 16 3VM1196-4GE42-0AA0 3VM1196-5GE42-0AA0 20 3VM1120-4GE42-0AA0 3VM1120-5GE42-0AA0 25 3VM1125-4GE42-0AA0 3VM1125-5GE42-0AA0 32 3VM1132-4GE42-0AA0 3VM1132-5GE42-0AA0 40 3VM1140-4GE42-0AA0 3VM1140-5GE42-0AA0 50 3VM1150-4GE42-0AA0 3VM1150-5GE42-0AA0 63 3VM1163-4GE42-0AA0 3VM1163-5GE42-0AA0 80 3VM1180-4GE42-0AA0 3VM1180-5GE42-0AA0 100 3VM1110-4GE42-0AA0 3VM1110-5GE42-0AA0 125 3VM1112-4GE42-0AA0 3VM1112-5GE42-0AA0 160 3VM1116-4GE42-0AA0 3VM1116-5GE42-0AA0 200 3VM1220-4GE42-0AA0 3VM1220-5GE42-0AA0 250 3VM1225-4GE42-0AA0 3VM1225-5GE42-0AA0 S M © Siemens AG 2015

2/12 Siemens LV 31 · 2015 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Starter protection  You can order this quantity or a multiple thereof. PU (UNIT, SET, M) = 1 PS /P. unit = 1 UNIT PG = 173 Connection technology Type Rated current I n Current setting of the inverse-time delayed overload protection "L" I r Operating current of the instanta-neous short-circuit protection "I" I i DT I cu  up to 55 kA at 415 V,  medium breaking capacity M Article No. www.siemens.com/product? Article No. Basic price per PU A A A 3-pole, fixed-mounted, 3VM11/3VM12, up to 200 A Magnetic trip unit        Starter protection, TM120M AM  With adjustable short-circuit protection I i   Connection with lug terminal  3VM11 32 -- 220 ... 510 3VM1132-5MH32-0AA0 40 -- 280 ... 640 3VM1140-5MH32-0AA0 50 -- 350 ... 800 3VM1150-5MH32-0AA0 63 -- 440 ... 1010 3VM1163-5MH32-0AA0 80 -- 560 ... 1280 3VM1180-5MH32-0AA0 100 -- 700 ... 1600 3VM1110-5MH32-0AA0 125 -- 875 ... 2000 3VM1112-5MH32-0AA0 3VM12 160 -- 1280 ... 2560 3VM1216-5MH32-0AA0 200 -- 1400 ... 2800 3VM1220-5MH32-0AA0 M Ii /A I201_19240 i © Siemens AG 2015

2/13 Siemens LV 31 · 2015 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Switch disconnectors  You can order this quantity or a multiple thereof. ■ Selection and ordering data            1) Start of delivery scheduled for 3rd quarter 2015 PU (UNIT, SET, M) = 1 PS /P. unit = 1 UNIT PG = 173 Connection technology Type Rated current I n Current setting of the inverse-time delayed overload protection "L" I r Operating current of the instanta-neous short-circuit protection "I"I i DT Article No. www.siemens.com/product? Article No. Basic price per PU A A A 3-pole, fixed-mounted, 3VM11/3VM12, up to 250 A Without trip unit Switch disconnector without SD100 trip unit  Connection with lug terminal  3VM11 63 -- -- 3VM1163-1AA32-0AA0 100 -- -- 3VM1110-1AA32-0AA0 125 -- -- 3VM1112-1AA32-0AA0 160 -- -- 3VM1116-1AA32-0AA0 3VM12 250 -- -- 1) 3VM1225-1AA32-0AA0 4-pole, fixed-mounted, 3VM11/3VM12, up to 250 A Without trip unit Switch disconnector without SD100 trip unit  Connection with lug terminal  3VM11 63 -- -- 3VM1163-1AA42-0AA0 100 -- -- 3VM1110-1AA42-0AA0 125 -- -- 3VM1112-1AA42-0AA0 160 -- -- 3VM1116-1AA42-0AA0 3VM12 250 -- -- 1) 3VM1225-1AA42-0AA0 © Siemens AG 2015

2/14 Siemens LV 31 · 2015 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Dimensional drawings ■ Overview       3VM11, 1-pole 3VM11, 2-pole 12.7 25.4 130 107.8 1 1.1 11 .1 13 20 20 70 75.8 86 45 70 17.5 95 17.5 17.7 17.7 12.7 25.4 57.25 1 14.5 7.75 Ø 4.2 I201_19255 12.7 50.8 130 107.8 25.4 11 .1 11 .1 13 20 20 70 75.8 86 45 70 17.5 95 17.5 17.7 17.7 12.7 25.4 57.25 1 14.5 7.75 Ø 4.2 I201_19256 © Siemens AG 2015

2/15 Siemens LV 31 · 2015 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Dimensional drawings ■ Overview          3VM10 and 3VM11, 3-pole 3VM10 and 3VM11, 4-pole 38.1 76.2 130 107.8 25.4 25.4 11 .1 11 .1 13 20 20 70 75.8 86 45 70 17.5 95 17.5 17.7 17.7 12.7 25.4 57.25 1 14.5 7.75 Ø 4.2 I20 1 _ 1 9257 38.1 101.6 130 107.8 25.4 25.4 25.4 11 .1 11 .1 13 20 20 70 75.8 86 45 70 17.5 95 17.5 17.7 17.7 12.7 25.4 50.8 57.25 1 14.5 7.75 Ø 4.2 I20 1 _ 1 925 8 © Siemens AG 2015

2/16 Siemens LV 31 · 2015 2 3VM Molded Case Circuit Breakers up to 250 A, TM, 400 V, up to 55 kA Dimensional drawings ■ Overview          3VM12, 3-pole 3VM12, 4-pole 52.5 105 158 134 35 35 12 12 20 18 18 70 75.8 90 45 75 22 1 14 22 20 20 17.5 35 61.75 123.5 17.25 Ø 4.2 I20 1 _ 1 925 9 52.5 140 158 134 35 35 35 12 12 20 18 18 70 75.8 90 45 75 22 1 14 22 20 20 17.5 35 70 61.75 123.5 17.25 Ø 4.7 I201_19260 © Siemens AG 2015

Siemens LV 31 · 2015 3 3 For further technical product information: Siemens Industry Online Support: www.siemens.com/lowvoltage/product-support  . → Entry type: Application exampleCertificateCharacteristicDownloadFAQManualProduct noteSoftware archiveTechnical data 3 3/2 Internal accessories 3/6 Manual operators 3/8 Connection technology 3/20 Plug-in technology 3/26 Residual current devices 3/28 Locking technology 3/29 Other Accessories and Spare Parts  Direct reference to the products in the Industry Mall from the selection and ordering data tables: 3VA2025-5HL36-0AA0  Article No. www.siemens.com/product?  Article No. Paper catalog:To get more product information enter the Web address plus Article No. PDF catalog:Get more product information with just a mouse click. © Siemens AG 2015

3/2 Siemens LV 31 · 2015 3 Accessories and Spare Parts Internal accessories ■ Overview        Auxiliary switches All auxiliary and alarm switches for the 3VM molded case circuit breakers and switch disconnectors belong to an integrated range of accessories. The auxiliary switches can be simply snapped into place and connected up in the accessories compartment provided on the front face of the unit to the left and right of the handle. The purpose of the auxiliary switches AUX is to signal the posi-tion of the main contacts of the molded case circuit breaker. The contacts of the auxiliary switches open and close simultaneously with the main contacts of the molded case circuit breaker. Trip alarm switches TAS signal every circuit breaker tripping operation, regardless of the cause of the trip. The trip alarm switches are actuated whenever the molded case circuit breaker switches to the TRIP position. Special electronic-compatible variants are available for applica-tions which require the auxiliary switch signals to be linked to automation systems. Auxiliary releases Auxiliary releases allow remote electrical tripping of the circuit breaker. They can be used to monitor control or main circuits in order to implement a protective system against accidental restart following a power failure, for example. Undervoltage releases trip the 3VM molded case circuit breaker in the event that the rated voltage of a monitored circuit drops below a minimum permissible limit or fails altogether. Shunt trips can be used to trip the 3VM molded case circuit breaker remotely. ■ Benefits • The internal accessories are extremely easy to install. No tools  are required because they are simply snapped into place in the accessories compartments to the left and right of the handle. • The accessories are connected by screw terminals for  auxiliary conductors with a cross-section of up to 2.5 mm 2 .  The terminals are mounted on the front of the unit for easy access. • All auxiliary and alarm switches are designed as changeover  contacts and therefore provide a high degree of flexibility for planning and installation purposes. • Symbols engraved in the lid of the accessories compartment  indicate the possible mounting positions of the internal accessories. © Siemens AG 2015

3/3 Siemens LV 31 · 2015 3 Accessories and Spare Parts Internal accessories ■ Design 1)  Included in the scope of supply for side mounted RCDs Internal accessories Optional equipment Auxiliary switch Type Alarm switch Trip alarm switch Type Auxiliary release Type Auxiliary switch Shunt trip left Residual current release Undervoltage release 3VM 160 A 2-pole 3VM 100/160 A 3-pole 3VM 250 A 3-pole Slot-No: 23 22 21 23 22 21 11 12 13 23 24 22 21 11 12 13 14 x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x x AUX_HQ AUX_HQ_el TAS_HQ TAS_HQ_el STL RCR  1) UVR 160 A 160 A 250 A I201_19232 1)  Included in the scope of supply for side mounted RCDs Internal accessories Optional equipment Auxiliary switch Alarm switch Alarm switch Auxiliary release Type Type Type Auxiliary switch Shunt trip left Residual current release Undervoltage release 3VM 160 A 4-pole 3VM 100/160 A 4-pole 3VM 250 A 4-pole Slot-No: 23 22 21 11 12 13 x x x x x x x x x x x x x x x x x x x x x x AUX_HQ AUX_HQ_el TAS_HQ TAS_HQ_el STL RCR  1) UVR 100 A 23 22 21 11 12 13 x x x x x x x x x x x x x x x x x x x x x x x 160 A I201_19233 I201_19233 23 24 22 21 11 12 13 14 x x x x x x x x x x x x x x x x x x x x x x x x x x x 250 A © Siemens AG 2015

3/4 Siemens LV 31 · 2015 3 Accessories and Spare Parts Internal accessories ■ Technical specifications Auxiliary switches and alarm switches HQ Auxiliary switches and alarm switches HQ_electronic AUX TAS AUX TAS Width mm 7 7 Conductor cross-sections Solid, stranded and finely stranded, with end sleeve Screw connection (per contact)  1 x (0.5 - 1.5) 1 x (0.5 - 1.5) 1 x (AWG20 - AWG16) 1 x (AWG20 - AWG16) Finely stranded with insulated end sleeve Screw connection (per contact)  1 x (0.5 - 1.0) 1 x (0.5 - 1.0) 1 x (AWG20 - AWG16) 1 x (AWG20 - AWG16) Tightening torque (connection cables) Nm 0.4  +0.1 0.4  +0.1 Stripped length mm 15 15 Rated operating voltage U e V AC 50 Hz 240 24 V DC 250 24 Conventional free-air thermal current I th  = I e A 6 0.3 Rated operational current AC-12 12 V A 6 0.3 24 V A 6 0.3 48 V A 6 -- 125 V A 6 -- 220/240 V A 6 -- 380/440 V A -- -- 600 V A -- -- AC-15 12 V A 3 0.3 24 V A 3 0.3 48 V A 3 -- 125 V A 3 -- 220/240 V A 3 -- 380/440 V A -- -- 600 V A -- -- DC-12 12 V A 6 0.1 24 V A 4 0.1 48 V A 2 -- 110 V A 0.5 -- 250 V A 0.25 -- DC-13 12 V A 1 0.07 24 V A 0.8 0.07 48 V A 0.4 -- 110 V A 0.2 -- 250 V A 0.1 -- Minimum load At 24 V DC mA 70 0.5 At 5 V DC mA -- 1 L © Siemens AG 2015

3/5 Siemens LV 31 · 2015  You can order this quantity or a multiple thereof. 3 Accessories and Spare Parts Internal accessories ■ Selection and ordering data                     Version DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG Auxiliary switches and alarm switches    3VM9988-0AA12  Auxiliary switch AUX Type/switching capacity/size Electronic-compatible HQ/compact size/1 slot -- 3VM9988-0AA12 1 1 unit 173 HQ_el/compact size/1 slot ✓ 3VM9988-0AA13 1 1 unit 173 3VM9988-0AB12  Trip alarm switch TAS Type/switching capacity/size Electronic-compatible HQ/compact size/1 slot -- 3VM9988-0AB12 1 1 unit 173 HQ_el/compact size/1 slot ✓ 3VM9988-0AB13 1 1 unit 173 Undervoltage releases 3VM9908-0BB15 Undervoltage release UVR 50/60 Hz V AC V DC -- 12 3VM9908-0BB10 1 1 unit 173 -- 24 3VM9908-0BB11 1 1 unit 173 -- 48 3VM9908-0BB12 1 1 unit 173 -- 60 3VM9908-0BB13 1 1 unit 173 -- 125 ... 127 3VM9908-0BB14 1 1 unit 173 -- 220 ... 230 3VM9908-0BB15 1 1 unit 173 -- 250 3VM9908-0BB16 1 1 unit 173 24 -- 3VM9908-0BB20 1 1 unit 173 48 -- 3VM9908-0BB21 1 1 unit 173 60 -- 3VM9908-0BB22 1 1 unit 173 110 -- 3VM9908-0BB23 1 1 unit 173 120 ... 127 -- 3VM9908-0BB24 1 1 unit 173 208 ... 230 -- 3VM9908-0BB25 1 1 unit 173 380 ... 400 -- 3VM9908-0BB26 1 1 unit 173 440 ... 480 -- 3VM9908-0BB27 1 1 unit 173 Shunt trip left 3VM99 08-0BL33 Shunt trip left STL 50/60 Hz V AC V DC -- 12 3VM9908-0BL10 1 1 unit 173 24 24 ... 30 3VM9908-0BL30 1 1 unit 173 48 ... 60  48 ... 60 3VM9908-0BL31 1 1 unit 173 110 ... 127  110 ... 127  3VM9908-0BL32 1 1 unit 173 208 ... 277  220 ... 250  3VM9908-0BL33 1 1 unit 173 380 ... 600 -- 3VM9908-0BL20 1 1 unit 173 © Siemens AG 2015

3/6 Siemens LV 31 · 2015 3 Accessories and Spare Parts Manual operators ■ Overview     Manual operators are provided to facilitate manual operation of the 3VM molded case circuit breakers, either directly at the circuit breaker or through the cubicle door. Front mounted rotary operator The front mounted rotary operator is mounted directly on the molded case circuit breaker and is available with or without a door interlocking system. It meets the requirements for degree of protection IP30. The door interlock locks the cubicle door when the molded case circuit breaker is closed, but can be deliberately overridden if necessary. Door mounted rotary operator The door mounted rotary operator enables operation of the molded case circuit breaker from the cubicle door. The door element meets the requirements for degree of protection IP65 and features a door interlocking system and tolerance compensation. 1 3 2 Door element Switching position indicator ON, TRIP, OFF, RESET Shaft 1 2 3 I20 1 _ 1 92 4 6 © Siemens AG 2015

3/7 Siemens LV 31 · 2015 3 Accessories and Spare Parts Manual operators  You can order this quantity or a multiple thereof. ■ Selection and ordering data        Version For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 100 A, 160 A 3VM 250 A Front mounted rotary operators  3VM9217-0EK11 Front mounted rotary operator • Rotary operator• Handle• For  IEC• Degree of protection IP30 Type Color • Standard gray ✓ -- 3VM9117-0EK11 1 1 unit 173 -- ✓ 3VM9217-0EK11 1 1 unit 173 • EMERGENCY-STOP yellow-red ✓ -- 3VM9117-0EK15 1 1 unit 173 -- ✓ 3VM9217-0EK15 1 1 unit 173 • Standard,  with door interlock gray ✓ -- 3VM9117-0EK21 1 1 unit 173 -- ✓ 3VM9217-0EK21 1 1 unit 173 • EMERGENCY-STOP,  with door interlock yellow-red ✓ -- 3VM9117-0EK25 1 1 unit 173 -- ✓ 3VM9217-0EK25 1 1 unit 173 Door mounted rotary operator  3VM9217-0FK21 Door mounted rotary operator  • Rotary operator• Shaft 300 mm• Mounting tolerance compensation• Handle with masking plate 75 x 75 mm• Degree of protection IP65 Type Color • Standard gray ✓ -- 3VM9117-0FK21 1 1 unit 173 -- ✓ 3VM9217-0FK21 1 1 unit 173 • EMERGENCY-STOP yellow-red ✓ -- 3VM9117-0FK25 1 1 unit 173 -- ✓ 3VM9217-0FK25 1 1 unit 173 8UD1900-2WB00 Shaft8 mm Variants • 300 mm long 8UD1900-2WA00 1 1 unit 153 • 600 mm long 8UD1900-2WB00 1 1 unit 153 8UD1900-2DA00 Adapter for shaft 8 mm x 8 mm 8UD1900-2DA00 1 1 unit 153 for door mounted rotary operator 3VM9217-0GA80 Fixing bracket for shaft  ✓ ✓ 3VM9217-0GA80 1 1 unit 173 Handles Handles 8UD1721-0AB11 • With masking plate Type Color Tolerance compensa-tion • Standard gray without ✓ ✓ 8UD1721-0AB11 1 1 unit 153 with ✓ ✓ 8UD1721-0AB21 1 1 unit 153 • EMERGENCY-STOP yellow-red without ✓ ✓ 8UD1721-0AB15 1 1 unit 153 with ✓ ✓ 8UD1721-0AB25 1 1 unit 153 © Siemens AG 2015

3/8 Siemens LV 31 · 2015 3 Accessories and Spare Parts Connection technology ■ Overview       The proper functioning and in particular the safety of electrical installations does not just depend on the quality and design of the components, but also on the method of installation. The following aspects of electrical installations are of crucial im-portance for the implementation of a safe, properly functioning connection to the 3VM molded case circuit breakers: • Installation, e.g. connection to cables or busbars • Dimensioning of the cables and busbars • Installation medium, e.g. rigid or flexible The following catalog pages provide all the information needed to ensure that a 3VM molded case circuit breaker is safely connected. Connection technology for the 3VM molded case circuit breaker The connection technology of the 3VM molded case circuit breakers is designed to support uncomplicated and convenient commissioning of the 3VM molded case circuit breakers and to meet all installation requirements. To meet this objective, an extensive portfolio of connection components is available. Front terminals The portfolio of connection components for the molded case cir-cuit breakers includes a large selection of front cable and bus-bar terminals. Connection technology available from/installed at the factory All 3VM molded case circuit breakers are available as standard with a lug terminal (clip-in nut and clamping screw) at the infeed and load ends. ✓ Available Insulated busbars and cables with cable lugs can be connected directly to the lug terminal. Furthermore, all connection bar extensions are assembled at the molded case circuit breaker using the lug terminal:  • Front connection bars extended (phase barriers included in  scope of supply) • Front connection bars broadened (phase barriers included in  scope of supply) The implementation of insulation measures (phase barriers or terminal covers) is recommended. With some accessory components, insulation measures are essential (and these are included in the scope of supply of the relevant component). Rear terminal flat Lug terminal Front connection bars extended Front connection bars broadened Circular conductor terminal, 2 cables Circular conductor terminal, 2 cables, with auxiliary conductor terminal Circular conductor terminal, large Circular conductor terminal, large  with auxiliary conductor terminal  Circular conductor terminal Circular conductor  terminal with auxiliary  conductor terminal  Box terminal I201_19249 Connection technology Illustration 3VM 100 160 250 Lug terminal ✓ ✓ ✓ © Siemens AG 2015

3/9 Siemens LV 31 · 2015 3 Accessories and Spare Parts Connection technology In addition to the factory-mounted connection technology included in the scope of the supply of the breaker, the following front connection components are available as accessories: ✓ Available -- Not available The circular conductor terminals, large and circular conductor terminals, 2cables are delivered as standard with extended terminal covers. Cable medium Front terminals     Illustration Solid, stranded and finely stranded cables Cable lugs Busbars Flexible busbars Box terminal ✓Cu cable -- -- ✓ Circular conductor terminal of aluminum ✓Cu/Al cable -- -- -- Circular conductor terminal of aluminum with auxiliary conductor terminal ✓Cu/Al cable -- -- -- Circular conductor terminal of aluminum, large (extended terminal cover included in scope of supply) ✓Cu/Al cable -- -- -- Circular conductor terminal of aluminum, large with auxiliary conductor terminal (extended terminal cover included in scope of supply) ✓Cu/Al cable -- -- -- Circular conductor terminal of aluminum, 2 cables (extended terminal cover included in scope of supply) ✓Cu/Al cable -- -- -- Circular conductor terminal of aluminum, 2 cables with auxiliary conductor terminal (extended terminal cover included in scope of supply) ✓Cu/Al cable -- -- -- Lug terminal -- ✓ ✓ ✓ Front connection bars extended (phase barriers included in scope of supply) -- ✓ ✓ ✓ Front connection bars broadened (phase barriers included in scope of supply) -- ✓ ✓ ✓ © Siemens AG 2015

3/10 Siemens LV 31 · 2015 3 Accessories and Spare Parts Connection technology Rear terminals The following connection components are available for imple-menting a rear terminal: ✓ Available -- Not available The rear terminal flat can be mounted at an angle in increments of 45°: Insulated busbars and cables with cable lugs can be connected to the right-angled lug terminal. A box terminal can be mounted to allow direct connection of a cable to the right-angled lug terminal. General note about connection technology All connection components are available in the following sets: • Set with 3 units • Set with 4 units The rear terminal is an exception as it can also be ordered individually (1 unit). All connection systems offered for the molded case circuit breaker can be used unmodified in the plug-in technology (plug-in socket) applications. Cable medium Rear terminals Illustration Solid, stranded and finely stranded cables Cable lugs Busbars Flexible busbars Rear terminal flat -- ✓ ✓ ✓ 0° 45° 90° I201_18818 © Siemens AG 2015

3/11 Siemens LV 31 · 2015 3 Accessories and Spare Parts Connection technology Conductor cross-sections Connection technology Cable medium Cables and busbars Dimensions 3VM 100 A/160 A 250 A Box terminal Solid cable Cu cable mm 2 1.5 ... 16 6 ... 16 Stranded cable Cu cable mm 2 1.5 ... 70 6 ... 12050 ... 185 Finely stranded cable Cu cable mm 2 1.5 ... 50 10 ... 9595 ... 150 Finely stranded with insulated end sleeve Cu cable mm 2 1.5 ... 50 6 ... 9550 ... 150 Flexible copper busbar Flexible busbar mm x mm 2x ..6x [13 x 0.5] ... 2x ..9x [9 x 0.8] 2x ..6x [13 x 0.5] ... 2x ..6x [15.5 x 0.8] ... 2x ..6x [20 x 1] Circular conductor terminal Solid cable Cu/Al cable mm 2 2.5/4 ... 16 -- Stranded cable Cu/Al cable mm 2 1.5/4 ... 50 35 ... 185 Finely stranded cable Cu cable mm 2 1.5 ... 35 35 ... 150 Finely stranded with insulated end sleeve Cu cable mm 2 1.5 ... 35 35 ... 150 Circular conductor terminal, large Solid cable -- -- Stranded cable Cu/Al cable mm 2 25 ... 150 50 ... 240 Finely stranded cable Cu cable mm 2 25 ... 120 50 ... 185 Finely stranded with insulated end sleeve Cu cable mm 2 25 ... 95 50 ... 185 Circular conductor terminal for 2 cables Solid cable mm 2 -- -- Stranded cable Cu/Al cable mm 2 -- 25 ... 150 Finely stranded cable Cu cable mm 2 -- 25 ... 150 Finely stranded with insulated end sleeve Cu cable mm 2 -- 25 ... 70 Busbar connection Direct (width x height) Busbar mm x mm 17 x 6.5 25 x 8 Front connection bars extended Busbar mm x mm 22 x 8 32 x 10 Front connection bars broadened Busbar mm x mm 30 x 8 35 x 10 © Siemens AG 2015

3/12 Siemens LV 31 · 2015 3 Accessories and Spare Parts Connection technology Further connection accessories   Insulation / auxiliary conductor connections The connection accessories portfolio includes an extensive selection of insulating components (phase barriers, terminal covers, etc.). Auxiliary conductor connections for box terminals and busbars are also available. Terminal covers Terminal covers are insulating and sealable insulation accesso-ries which protect against accidental contact with main current paths. When mounted on the circuit breaker, terminal covers at the front provide degree of protection IP4x and when correctly installed at the infeed and load ends of the breaker, degree of protection IP2x. All terminal covers have a recess on the inside face which can be drilled out if necessary so that safe isolation can be afforded by commercially available voltage detectors. • Short terminal covers are normally installed for all types of  front termination which do not exceed the geometric dimen-sions of the molded case circuit breaker (the termination area) (e.g. box terminal, lug terminal, etc.). • Extended terminal covers are required when bar extensions or  external terminals (i.e. terminals which exceed the dimensions of the termination area of the molded case circuit breaker) are installed. The extended terminal cover consists of two parts, an insulating plate and the top half of the terminal cover. Both parts are attached by screws and thus afford the degrees of protection specified above. • Broad terminal covers are required when broadened connec- tion bars are installed. The extended terminal cover consists of two parts, a broadened insulating plate and the top half of the terminal cover. Both parts are attached by screws and thus afford the degrees of protection specified above. Insulating plates The purpose of insulating plates is to insulate the main terminals of the molded case circuit breaker from the mounting plate (cubicle). • Insulating plate: in combination with bar extensions,  for example • Insulating plate broadened: in combination with broadened  connection bars, for example Auxiliary conductor terminals All circular conductor terminals can be ordered with or without auxiliary conductor terminal ( see page 3/9, Front terminals ). The  following accessories are available to allow the implementation of an auxiliary conductor terminal in combination with a box terminal or busbar connection: • Auxiliary conductor terminal for box terminal: This terminal is  fastened by screws in the box terminal with the cable. • Auxiliary conductor terminal for busbars: This terminal is  attached by screws directly to the busbar. All auxiliary conductor terminals are rated for a maximum load of 6 A. Cables of up to 2.5 mm² can be connected. ■ Benefits • High degree of flexibility • Cables and busbars can be connected quickly and easily to  the 3VM molded case circuit breaker • Extensive selection of connection accessories Auxiliary conductor terminalfor busbars Auxiliary conductor terminal for box terminal Terminal cover Extended terminal cover Broadened terminal cover Insulating plate Broadened insulating plate Phase barriers I201_19250 © Siemens AG 2015

3/13 Siemens LV 31 · 2015 3 Accessories and Spare Parts Connection technology  You can order this quantity or a multiple thereof. ■ Selection and ordering data           Version Minimum mm² for stranded cable Maximum mm² for stranded cable For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 100 A160 A 3VM 250 A Box terminals 3VM9253-0JA12 Box terminal• Connection of Cu cable• Included in scope of  supply:3 single terminals 1.5 mm² 70 mm²  ✓ -- 3VM9153-0JA11 1 1 unit 173 6 mm² 120 mm² -- ✓ 3VM9253-0JA11 1 1 unit 173 50 mm² 185 mm² -- ✓ 3VM9253-0JA12 1 1 unit 173 3VM9254-0JA12 Box terminal• Connection of Cu cable• Included in scope of  supply:4 single terminals 1.5 mm²  70 mm²  ✓ -- 3VM9154-0JA11 1 1 unit 173 6 mm² 120 mm² -- ✓ 3VM9254-0JA11 1 1 unit 173 50 mm² 185 mm² -- ✓ 3VM9254-0JA12 1 1 unit 173 Circular conductor terminals 3VM9113-0JB11 Circular conductor terminal• Connection of Cu/Al cable• Included in scope of  supply:3 single terminals 1.5 mm² 50 mm² ✓ -- 3VM9113-0JB11 1 1 unit 173 35 mm² 185 mm² -- ✓ 3VM9253-0JB12 1 1 unit 173 3VM9114-0JB11 Circular conductor terminal• Connection of Cu/Al cable• Included in scope of  supply:4 single terminals 1.5 mm² 50 mm² ✓ -- 3VM9114-0JB11 1 1 unit 173 35 mm² 185 mm² -- ✓ 3VM9254-0JB12 1 1 unit 173 3VM9113-0JG11 Circular conductor terminal with auxiliary conductor terminal• Connection of Cu/Al cable• Included in scope of  supply:3 single terminals 16 mm² 50 mm² ✓ -- 3VM9113-0JG11 1 1 unit 173 35 mm² 185 mm² -- ✓ 3VM9253-0JG12 1 1 unit 173 3VM9114-0JG11 Circular conductor terminal with auxiliary conductor terminal• Connection of Cu/Al cable• Included in scope of  supply:4 single terminals 16 mm² 50 mm² ✓ -- 3VM9114-0JG11 1 1 unit 173 35 mm² 185 mm² -- ✓ 3VM9254-0JG12 1 1 unit 173 3VM9112-0JJ12 Circular conductor terminal, large• Connection of Cu/Al cable• Included in scope of  supply: 2 single terminals and 1 ex-tended terminal cover 25 mm² 150 mm² ✓ Only for 160 A -- 3VM9112-0JJ12 1 1 unit 173 3VM9113-0JJ12 Circular conductor terminal, large• Connection of Cu/Al cable• Included in scope of  supply: 3 single terminals and 1 extended terminal cover 25 mm² 150 mm² ✓ -- 3VM9113-0JJ12 1 1 unit 173 50 mm² 240 mm² -- ✓ 3VM9213-0JJ13 1 1 unit 173 © Siemens AG 2015

3/14 Siemens LV 31 · 2015 3 Accessories and Spare Parts Connection technology  You can order this quantity or a multiple thereof. 3VM9114-0JJ12 Circular conductor terminal, large• Connection of Cu/Al cable• Included in scope of  supply: 4 single terminals and 1 extended terminal cover 25 mm² 150 mm² ✓ -- 3VM9114-0JJ12 1 1 unit 173 50 mm² 240 mm² -- ✓ 3VM9214-0JJ13 1 1 unit 173 3VM9112-0JC12 Circular conductor terminal, large, with auxiliary conductor terminal• Connection of Cu/Al cable• Included in scope of  supply: 2 single terminals and 1 extended terminal cover 25 mm² 150 mm² ✓ Only for 160 A -- 3VM9112-0JC12 1 1 unit 173 3VM9113-0JC12 Circular conductor terminal, large, with auxiliary conductor terminal• Connection of Cu/Al cable• Included in scope of  supply:3 single terminals and 1 extended terminal cover 25 mm² 150 mm² ✓ -- 3VM9113-0JC12 1 1 unit 173 50 mm² 240 mm² -- ✓ 3VM9213-0JC13 1 1 unit 173 3VM9114-0JC12 Circular conductor terminal, large, with auxiliary conductor terminal• Connection of Cu/Al cable• Included in scope of  supply:4 single terminals and 1 extended terminal cover 25 mm² 150 mm² ✓ -- 3VM9114-0JC12 1 1 unit 173 50 mm² 240 mm² -- ✓ 3VM9214-0JC13 1 1 unit 173 3VM9213-0JJ22 Circular conductor terminal, 2 cables• Connection of Cu/Al cable• Included in scope of  supply:3 single terminals and 1 extended terminal cover 2 x 25 mm² 2 x 150 mm² -- ✓ 3VM9213-0JJ22  1 1 unit 173 3VM9214-0JJ22 Circular conductor terminal, 2 cables• Connection of Cu/Al cable• Included in scope of  supply:4 single terminals and 1 extended terminal cover 2 x 25 mm² 2 x 150 mm² -- ✓ 3VM9214-0JJ22 1 1 unit 173 Version Minimum mm² for stranded cable Maximum mm² for stranded cable For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 100 A160 A 3VM 250 A © Siemens AG 2015

3/15 Siemens LV 31 · 2015 3 Accessories and Spare Parts Connection technology  You can order this quantity or a multiple thereof. 3VM9213-0JC22 Circular conductor terminal, 2 cables, with auxiliary conductor terminal• Connection of Cu/Al cable• Included in scope of  supply: 3 single terminals and 1 extended terminal cover 2 x 25 mm² 2 x 150 mm² -- ✓ 3VM9213-0JC22 1 1 unit 173 3VM9214-0JC22 Circular conductor terminal, 2 cables, with auxiliary conductor terminal• Connection of Cu/Al cable• Included in scope of  supply: 4 single terminals and 1 extended terminal cover 2 x 25 mm² 2 x 150 mm² -- ✓ 3VM9214-0JC22 1 1 unit 173 Version Minimum mm² for stranded cable Maximum mm² for stranded cable For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 100 A160 A 3VM 250 A © Siemens AG 2015

3/16 Siemens LV 31 · 2015 3 Accessories and Spare Parts Connection technology  You can order this quantity or a multiple thereof. Version Max. terminal width Max. busbar thickness For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 100 A160 A 3VM 250 A Lug terminals 3VM9113-0QA00 Lug terminalIncluded in scope of supply:• 3 single terminals 17 mm 6.5 mm ✓ -- 3VM9113-0QA00 1 1 unit 173 25 mm 8 mm -- ✓ 3VM9213-0QA00 1 1 unit 173 3VM9114-0QA00 Lug terminalIncluded in scope of supply:• 4 single terminals 17 mm 6.5 mm ✓ -- 3VM9114-0QA00 1 1 unit 173 25 mm 8 mm -- ✓ 3VM9214-0QA00 1 1 unit 173 Connection bar extensions 3VM9253-0QB00 Front connection bars extended Included in scope of supply:• 3 single terminals• 2 phase barriers 22 mm 8 mm ✓ -- 3VM9153-0QB00 1 1 unit 173 32 mm 10 mm -- ✓ 3VM9253-0QB00 1 1 unit 173 Included in scope of supply:• 1 single terminal 1-pole version only -- -- ✓ -- 3VM9151-0QB00 1 1 unit 173 3VM9254-0QB00 Front connection bars extendedIncluded in scope of supply:• 4 single terminals• 3 phase barriers 22 mm 8 mm ✓ -- 3VM9154-0QB00 1 1 unit 173 32 mm 10 mm -- ✓ 3VM9254-0QB00 1 1 unit 173 3VM9253-0QC00 Front connection bars broadened Included in scope of supply:• 3 single terminals• 2 phase barriers 30 mm 8 mm ✓ -- 3VM9153-0QC00 1 1 unit 173 35 mm 10 mm -- ✓ 3VM9253-0QC00 1 1 unit 173 Note Distance between pole centers:• At 100/160 A = 35 mm• At 250 A = 45 mm Included in scope of supply:• 2 single terminals• 1 phase barrier 2-pole version only -- -- ✓ -- 3VM9152-0QC00 1 1 unit 173 Note Distance between pole centers:44 .6 mm 3VM9254-0QC00 Front connection bars broadenedIncluded in scope of supply:• 4 single terminals• 3 phase barriers 30 mm 8 mm ✓ -- 3VM9154-0QC00 1 1 unit 173 35 mm 10 mm -- ✓ 3VM9254-0QC00 1 1 unit 173 Note Distance between pole centers:• At 100/160 A = 35 mm• At 250 A = 45 mm © Siemens AG 2015

3/17 Siemens LV 31 · 2015 3 Accessories and Spare Parts Connection technology  You can order this quantity or a multiple thereof. Version For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 160 A 3VM 250 A Rear terminals flat 3VM9213-0QE00 Rear terminal flatIncluded in scope of supply:• 2 short terminals flat• 1 long terminal flat ✓ -- 3VM9113-0QE00 1 1  unit 173 -- ✓ 3VM9213-0QE00 1 1  unit 173 3VM9214-0QE00 Rear terminal flatIncluded in scope of supply:• 2 short terminals flat• 2 long terminals flat ✓ -- 3VM9114-0QE00 1 1  unit 173 -- ✓ 3VM9214-0QE00 1 1  unit 173 3VM9211-0QE10 Rear terminal flatIncluded in scope of supply:• 1 short terminal flat ✓ -- 3VM9111-0QE10 1 1  unit 173 -- ✓ 3VM9211-0QE10 1 1  unit 173 3VM9211-0QE20 Rear terminal flatIncluded in scope of supply:• 1 long terminal flat ✓ -- 3VM9111-0QE20 1 1  unit 173 -- ✓ 3VM9211-0QE20 1 1  unit 173 Phase barriers 3VM9252-0WA00 Phase barriersIncluded in scope of supply:• 2 phase barriers ✓ -- 3VM9152-0WA00 1 1  unit 173 -- ✓ 3VM9252-0WA00 1 1  unit 173 Terminal covers 3VM9111-0WD10 Terminal cover for 1-pole breakers ✓ Only for 160 A -- 3VM9111-0WD10 1 1  unit 173 3VM9111-0WD20 Terminal cover for 2-pole breakers ✓ Only for 160 A -- 3VM9111-0WD20 1 1  unit 173 3VM9211-0WD30 Terminal cover for 3-pole breakers ✓ -- 3VM9111-0WD30 1 1  unit 173 -- ✓ 3VM9211-0WD30 1 1  unit 173 3VM9211-0WD40 Terminal cover for 4-pole breakers ✓ -- 3VM9111-0WD40 1 1  unit 173 -- ✓ 3VM9211-0WD40 1 1  unit 173 © Siemens AG 2015

3/18 Siemens LV 31 · 2015 3 Accessories and Spare Parts Connection technology  You can order this quantity or a multiple thereof. 3VM9111-0WF20 Extended terminal cover, 2-pole ✓ Only for 160 A -- 3VM9111-0WF20 1 1  unit 173 3VM9211-0WF30 Extended terminal cover for 3-pole breakers ✓ -- 3VM9111-0WF30 1 1  unit 173 -- ✓ 3VM9211-0WF30 1 1  unit 173 3VM9211-0WF40 Extended terminal cover for 4-pole breakers ✓ -- 3VM9111-0WF40 1 1  unit 173 -- ✓ 3VM9211-0WF40 1 1  unit 173 3VM9211-0WG30 Broadened terminal cover for 3-pole breakers ✓ -- 3VM9111-0WG30 1 1  unit 173 -- ✓ 3VM9211-0WG30 1 1  unit 173 3VM9211-0WG40 Broadened terminal cover for 4-pole breakers ✓ -- 3VM9111-0WG40 1 1  unit 173 -- ✓ 3VM9211-0WG40 1 1  unit 173 Insulating plates 3VM9111-0WJ20 Insulating plate, 2-pole ✓ Only for 160 A -- 3VM9111-0WJ20 1 1  unit 173 3VM9211-0WJ30 Insulating plate, 3-pole ✓ -- 3VM9111-0WJ30 1 1  unit 173 -- ✓ 3VM9211-0WJ30 1 1  unit 173 Version For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 160 A 3VM 250 A © Siemens AG 2015

3/19 Siemens LV 31 · 2015 3 Accessories and Spare Parts Connection technology  You can order this quantity or a multiple thereof. 3VM9211-0WJ40 Insulating plate, 4-pole ✓ -- 3VM9111-0WJ40 1 1  unit 173 -- ✓ 3VM9211-0WJ40 1 1  unit 173 3VM9211-0WK30 Insulating plate broadened, 3-pole ✓ -- 3VM9111-0WK30 1 1  unit 173 -- ✓ 3VM9211-0WK30 1 1  unit 173 3VM9211-0WK40 Insulating plate broadened, 4-pole ✓ -- 3VM9111-0WK40 1 1  unit 173 -- ✓ 3VM9211-0WK40 1 1  unit 173 DC insulating plate 3VM9113-0SG10 DC insulating plate for 3VM Variants • For fixed-mounted molded case circuit  breakers - 3-pole ✓ -- 3VM9113-0SG10 1 10 units 173 - 4-pole ✓ -- 3VM9114-0SG10 1 10 units 173 Side plate 3VM9112-0SG20 Side plate for 3VM Version • For fixed-mounted molded case circuit  breakers - 2-pole ✓ -- 3VM9112-0SG20 1 5  units 173 Auxiliary conductor terminals 3VM9200-0WB00 Auxiliary conductor terminal for box terminal ✓ -- 3VM9110-0WB00 1 10 units 173 -- ✓ 3VM9200-0WB00 1 10 units 173 3VM9200-0WC00 Auxiliary conductor terminal for busbar ✓ -- 3VM9110-0WC00 1 10 units 173 -- ✓ 3VM9200-0WC00 1 10 units 173 Version For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 160 A 3VM 250 A © Siemens AG 2015

3/20 Siemens LV 31 · 2015 3 Accessories and Spare Parts Plug-in technology ■ Overview        Using plug-in technology, the 3VM molded case circuit breakers can be installed/removed or replaced quickly and safely. In this case, the cables or busbars of the main current paths are connected to the connectors of the plug-in sockets.  The termination areas of the sockets for these versions are designed in the same way as those of the molded case circuit breakers but, due to the different requirements for creepages and clearances, have slightly different dimensions.  This means the available connection technology is also available for the plug-in socket in the same way. Connections with insulating measures have their own article numbers and are listed below. Plug-in technology is a low-cost but also space-saving solution that enables fast replacement of the breaker. The main current paths are connected to the connectors of the plug-in socket. The molded case circuit breaker is equipped with plug-in contacts on the rear. When the circuit breaker is plugged into the socket, the plug-in contacts slide into the socket-side tulip contacts and connect the main current paths with the circuit breaker. In addition, auxiliary circuit connectors can be used to connect the auxiliary and control signals from the internal accessories of the molded case circuit breaker to the outside. The plug-in unit can be supplied as a complete kit or as a conversion kit for breakers including screw-fastened terminal covers. I20 1 _ 1 9 2 4 7 © Siemens AG 2015

3/21 Siemens LV 31 · 2015 3 Accessories and Spare Parts Plug-in technology  You can order this quantity or a multiple thereof. ■ Selection and ordering data           Version For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 160 A 3VM 250 A Plug-in socket  Plug-in unit, complete kit Comprising: • Plug-in socket• Conversion kit• Mounting screw kit Variants 3VM9113-0KP00 • 3-pole ✓ -- 3VM9113-0KP00 1 1 unit 173 -- ✓ 3VM9213-0KP00 1 1 unit 173 3VM9114-0KP00 • 4-pole ✓ -- 3VM9114-0KP00 1 1 unit 173 -- ✓ 3VM9214-0KP00 1 1 unit 173 Plug-in unit, conversion kitComprising: • Screw-fastened terminal covers for molded  case circuit breakers • Plug-in contacts• Cable cage• Autotrip plunger Variants 3VM9113-0KP10 • 3-pole ✓ -- 3VM9113-0KP10 1 1 unit 173 -- ✓ 3VM9213-0KP10 1 1 unit 173 3VM9114-0KP10 • 4-pole ✓ -- 3VM9114-0KP10 1 1 unit 173 -- ✓ 3VM9214-0KP10 1 1 unit 173 © Siemens AG 2015

3/22 Siemens LV 31 · 2015 3 Accessories and Spare Parts Plug-in technology  You can order this quantity or a multiple thereof. Auxiliary circuit connector 3VM9987-0KP80 Auxiliary circuit connector For all plug-in units 3VM9987-0KP80 1 1 unit 173 Cable cage 3VM9117-0KB02 Cable cage for plug-in unit 3/4-pole (spare part)Cable duct for routing of the required cables from the internal accessories on the back of the circuit breaker  ✓ -- 3VM9117-0KB02 1 1 unit 173 -- ✓ 3VM9217-0KB02 1 1 unit 173 Terminal covers  Terminal cover for plug-in unit (spare part)• To provide circuit breaker touch protection • For mounting on the molded case circuit  breaker Variants 3VM9113-0KB01 • 3-pole ✓ -- 3VM9113-0KB01 1 1 unit 173 -- ✓ 3VM9213-0KB01 1 1 unit 173 3VM9114-0KB01 • 4-pole ✓ -- 3VM9114-0KB01 1 1 unit 173 -- ✓ 3VM9214-0KB01 1 1 unit 173 Terminal cover for plug-in socket• For touch protection in the termination area of  the plug-in socket • For mounting on the plug-in socket Variants 3VM9113-0KB03 • 3-pole ✓ -- 3VM9113-0KB03 1 1 unit 173 -- ✓ 3VM9213-0KB03 1 1 unit 173 3VM9114-0KB03 • 4-pole ✓ -- 3VM9114-0KB03 1 1 unit 173 -- ✓ 3VM9214-0KB03 1 1 unit 173 Version For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 160 A 3VM 250 A © Siemens AG 2015

3/23 Siemens LV 31 · 2015 3 Accessories and Spare Parts Plug-in technology  You can order this quantity or a multiple thereof. Terminal cover extended for plug-in socket• For touch protection in the termination area of  the plug-in socket • For mounting on the plug-in socket Variants 3VM9113-0KB04 • 3-pole ✓ -- 3VM9113-0KB04 1 1 unit 173 -- ✓ 3VM9213-0KB04 1 1 unit 173 3VM9114-0KB04 • 4-pole ✓ -- 3VM9114-0KB04 1 1 unit 173 -- ✓ 3VM9214-0KB04 1 1 unit 173 Terminal cover broadened for plug-in socket• For touch protection in the termination area of  the plug-in socket • For mounting on the plug-in socket Variants 3VM9113-0KB05 • 3-pole ✓ -- 3VM9113-0KB05 1 1 unit 173 -- ✓ 3VM9213-0KB05 1 1 unit 173 3VM9114-0KB05 • 4-pole ✓ -- 3VM9114-0KB05 1 1 unit 173 -- ✓ 3VM9214-0KB05 1 1 unit 173 Version For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 160 A 3VM 250 A © Siemens AG 2015

3/24 Siemens LV 31 · 2015 3 Accessories and Spare Parts Plug-in technology  You can order this quantity or a multiple thereof. Version Minimum mm² for stranded cable Maximum mm² for stranded cable For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 160 A 3VM 250 A Circular conductor terminals 3VM9153-0JC12 Circular conductor terminal, large, with auxiliary conductor terminalIncluded in scope of supply:3 single terminals and 1 extended terminal cover 25 mm²  150 mm²  ✓ -- 3VM9153-0JC12 1 1 unit 173 50 mm²  240 mm²  -- ✓ 3VM9253-0JC13 1 1 unit 173 3VM9154-0JC12 Circular conductor terminal, large, with auxiliary conductor terminalIncluded in scope of supply:4 single terminals and 1 extended terminal cover 25 mm²  150 mm²  ✓ -- 3VM9154-0JC12 1 1 unit 173 50 mm²  240 mm²  -- ✓ 3VM9254-0JC13 1 1 unit 173 3VM9253-0JC22 Circular conductor terminal, 2 cables, with auxiliary conductor terminalIncluded in scope of supply: 3 single terminals and 1 extended terminal cover 2 x 25 mm²  2 x 150 mm²  -- ✓ 3VM9253-0JC22 1 1 unit 173 3VM9254-0JC22 Circular conductor terminal, 2 cables, with auxiliary conductor terminalIncluded in scope of supply: 4 single terminals and 1 extended terminal cover 2 x 25 mm²  2 x 150 mm²  -- ✓ 3VM9254-0JC22 1 1 unit 173 © Siemens AG 2015

3/25 Siemens LV 31 · 2015 3 Accessories and Spare Parts Plug-in technology  You can order this quantity or a multiple thereof. Version DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG For molded case circuit breakers/rated current 3VM 160 A 3VM 250 A Auxiliary conductor terminals for plug-in design 3VM9200-0WB00 Auxiliary conductor terminal for box terminal ✓ -- 3VM9110-0WB00 1 10 units 173 -- ✓ 3VM9200-0WB00 1 10 units 173 3VM9200-0WC00 Auxiliary conductor terminal for busbar  ✓ -- 3VM9110-0WC00 1 10 units 173 -- ✓ 3VM9200-0WC00 1 10 units 173 © Siemens AG 2015

3/26 Siemens LV 31 · 2015 3 Accessories and Spare Parts Residual current devices ■ Overview        Residual current devices can be used to prevent or reduce hazardous residual currents that could cause injury to personnel and livestock, and damage to property. These are available as accessory components for the 3VM series up to the largest circuit breaker size. All residual current devices detect both purely sinusoidal AC residual currents as well as pulsating DC residual currents (type A), and the combination of molded case circuit breakers or switch disconnectors with mounted residual current devices complies with IEC 60947-2 Annex B. The residual current devices are characterized by the following features: • Compact design • 45 mm cover size • LEDs for signaling "ready" state and pre-alarms • Tripped signal at device and via electrical contacts • Deliberate acknowledgment following a trip via a reset push- button on the residual current device The RCD110 and RCD210 units are specially designed for the infrastructure market. This is reflected in the design: they have a compact L-shaped design, the operator controls and displays are in a 45 mm cover size, DIN rail mounting is possible, and the combination of breaker and residual current device has a depth of 70 mm and thus fits optimally into a distribution board.  The residual current devices are mounted on the left side of the breaker. Through-hole technology enables direct connection of the cable to the box terminal. There is no need for time-consum-ing wiring of the breaker-residual current device combination. In the event of a residual current, the breaker is tripped by an RCR (residual current release) built into the left accessories compart-ment of the breaker and is included in the scope of delivery. However, this RCR can also be used by means of a floating con-tact as a shunt trip independently of the residual current device. On the residual current devices of the 2-series (RCD210) tripping can be delayed by up to three seconds so that in the event of a fault, only the branch containing the fault is switched off by means of appropriate selective grading of the series-switched residual current devices. The RCD110 is an instanta-neous version, in other words, it trips immediately. Both versions can be supplied as 4-pole versions. RCD210 © Siemens AG 2015

3/27 Siemens LV 31 · 2015 3 Accessories and Spare Parts Residual current devices  You can order this quantity or a multiple thereof. ■ Selection and ordering data           Version For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price  per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 160 A 3VM 250 A Side mounted residual current devices RCD for 3VM Type A (pulse current sensitive) • Mounted on the side (left)• Trip element (RCR) included in the scope of delivery• Can be mounted on molded case circuit breakers and  switch disconnectors with box terminal • U e  = 127 - 480 V AC, 50/60 Hz Note 1 set of box terminals must be ordered additionally if the molded case circuit breaker has no box terminals as connections. 3VM9114-0RS10 RCD110• 4-pole• Rated residual response current, adjustable: I }n  = 0.03 - 0.05 - 0.1 - 0.3 - 0.5 - 1 - 3 - 5 A;  default: 30 mA • Delay time, permanently set:  }t = instantaneous (INS) ✓ -- 3VM9114-0RS10 1 1  unit 173 3VM9114-0RS20 RCD210• 4-pole• Rated residual response current, adjustable: I }n  = 0.03 - 0.05 - 0.1 - 0.3 - 0.5 - 1 - 3 - 5 A;  default: 30 mA • Delay time, adjustable:  }t = instantaneous (INS) - 0.06 - 0.15 - 0.3 - 0.5 - 1 - 2 - 3 s; default: instantaneous (INS) Variants • 4-pole ✓ -- 3VM9114-0RS20 1 1  unit 173 -- ✓ 3VM9214-0RS20 1 1  unit 173 © Siemens AG 2015

3/28 Siemens LV 31 · 2015 3 Accessories and Spare Parts Locking technology  You can order this quantity or a multiple thereof. ■ Overview       The padlock devices make it possible to lock the 3VM molded case circuit breaker in either the OFF or the ON operating posi-tion. Once the molded case circuit breaker is locked in position, it cannot be operated again. Locking technology Padlock device for the handle A padlock device mounted and latched on the handle allows the 3VM molded case circuit breaker to be locked in the ON or the OFF position.  In this position, up to 3 padlocks with diameters ranging from 4.5 mm to 8.5 mm can be fitted in order to prevent the handle from being moved. ■ Selection and ordering data           I20 1 _ 1 9 2 4 8 Version For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 100 A160 A 3VM 250 A Accessories for locking and interlocking 3VM9188-0LB10 Locking devices for toggle levers ✓ ✓ 3VM9188-0LB10 1 1 unit 173 © Siemens AG 2015

3/29 Siemens LV 31 · 2015 3 Accessories and Spare Parts Other  You can order this quantity or a multiple thereof. ■ Selection and ordering data       Version For molded case circuit breakers/rated current DT Article No. www.siemens.com/product? Article No. Price per PU PU (UNIT, SET, M) PS / P. unit PG 3VM 100 A 3VM  160 A 3VM  250 A Adapter for DIN rails for 3VM molded case circuit breakers  3VM9187-0SH10 Adapter for DIN rails for 3VM molded case circuit breakers  Variants • 1-pole -- ✓ -- 3VM9181-0SH10 1 1  unit 173 • 2-pole -- ✓ -- 3VM9182-0SH10 1 1  unit 173 • 3 and 4-pole ✓ ✓ -- 3VM9187-0SH10 1 1  unit 173 • 4-pole in conjunction with RCD110 or RCD210 -- ✓ ✓ 3VM9187-0SH20 1 1  unit 173 Adapter for 60 mm busbar system (8US)  8US1213-4AP03 Adapter for 60mm busbar system (8US) Variants • 3-pole ✓ -- -- 8US1213-4AU01 1 1  unit 143 -- ✓ -- 8US1213-4AP03 1 1  unit 143 Mounting screw kit 3VM9111-0SS10 Mounting screw kit Variants • For fixed-mounted molded case circuit breakers - 1-pole -- ✓ -- 3VM9111-0SS10 1 1  unit 173 - 2 and 3-pole (apart from 125 A/160 A with 55 kA) ✓ ✓ ✓ 3VM9116-0SS10 1 1  unit 173 - 3-pole (125 A/160 A with 55 kA) and 4-pole ✓ ✓ ✓ 3VM9114-0SS10 1 1  unit 173 • For plug-in technology ✓ ✓ ✓ 3VM9114-0SS10 1 1  unit 173 Transparent TMTU cover, sealable Transparent TMTU coverFor covering and sealing the trip unit for the TM120M and TM220 ATFM trip unit types Variants • 3 and 4-pole -- ✓ -- 3VM9157-0SA10 1 5 units 173 -- -- ✓ 3VM9257-0SA10 1 5 units 173 © Siemens AG 2015

3/30 Siemens LV 31 · 2015 3 Accessories and Spare Parts Notes     © Siemens AG 2015

Siemens LV 31 · 2015 4 4 4 4/2 Catalog notes 4/3 Ordering notes 4/5 Further documentation 4/10 Quality management 4/11 Standards and approvals 4/13 Siemens contacts 4/14 Service & Support 4/15 Comprehensive support from A to Z 4/16 Article No. index incl. export markings 4/21 Conditions of sale and delivery Appendix © Siemens AG 2015

4/2 Siemens LV 31 · 2015 4 Appendix Catalog notes ■ Overview Trademarks All product designations may be registered trademarks or product names of Siemens AG or supplier companies whose use by third parties for their own purposes may violate the rights of the owner. Amendments Unless stated otherwise on the individual pages of this catalog, we reserve the right to make changes, in particular to the speci-fied values, measurements and weights. Dimensions All dimensions are in mm. Illustrations The illustrations are not binding. Technical data The technical specifications are for general information purpo-ses only. Always heed the operating instructions and notices on individual products during assembly, operation and mainte-nance. Further technical information is available at  www.siemens.com/lowvoltage/product-support • under "Entry type": - Application example- Certificate- Characteristic- Download- FAQ- Manual- Product note- Software archive- Technical data Configurators can be found under www.siemens.com/lowvoltage/configurators Assembly, operation and maintenance Always heed the operating instructions and notices on individual products during assembly, operation and maintenance. Symbols In the table below, you will find all symbols concerning connec-tions that can occur in this catalog. In combination with orange highlighting, these identify special selection criteria.    Connections Screw connection Ring cable lug connection Spring-loaded terminals © Siemens AG 2015

4/3 Siemens LV 31 · 2015 4 Appendix Ordering notes ■ Logistics        General With regard to delivery service, communications and environ-mental protection, our logistics service ensures "quality from the moment of ordering right through to delivery". By designing our infrastructure according to customer requirements and imple-menting electronic order processing, we have successfully optimized our logistics processes. We are proud of our personal consulting service, on-time deliveries and 1-day transport within Germany. To this end, we supply preferred types marked with  }  ex  works. We regard the DIN ISO 9001 certification and consistent quality checks as an integral part of our services. Electronic order processing is fast, cost-efficient and error-free. Please contact us if you want to benefit from these advantages. Packaging, packing units The packaging in which our equipment is dispatched provides protection against dust and mechanical damage during trans-port, thus ensuring that all our products arrive in perfect condi-tion. We select our packaging for maximum environmental compati-bility and reusability (e.g. crumpled paper for protection during transport in packages up to 32 kg) and, in particular, with a view to reducing waste. With our multi-unit and reusable packaging, we offer you specific types of packaging that are both kind to the environment and tai-lored to your requirements: Your advantages at a glance: • Lower ordering costs. • Cost savings through same-material type packaging:  Low/no disposal costs. • Reduced time and cost thanks to short unpacking times. • "Just-in-time" delivery directly to the production line helps re- duce stock: Cost savings through reduction of storage areas. • Fast assembly thanks to supply in sets. • Standard Euro boxes - corresponding to the Euro pallet  modular system - suitable for most conveyor systems. • Active contribution to environmental protection. Unless stated otherwise in the "Selection and ordering data" of this catalog, our products are supplied individually packed. For small parts/accessories, we offer you cost-effective packaging units as standard packs containing more than one item, e.g. 5, 10, 50 or 100 units. It is essential that whole number multiples of these quantities be ordered to ensure satisfactory quality of the products and problem-free order processing. The products are delivered in a neutral carton. The label includes warning notices, the CE marking, and device descriptions in English and German. In addition to the Article No. (MLFB) and the number of items in the packaging, the order number for operating instructions (Instr.-Order-No.) is also specified. They can be obtained from your local Siemens representative (you will find a list at  www.siemens.com/automation/partner ). Most device Article No.'s can be obtained by means of the EAN barcode to simplify ordering and storage logistics. The associated master data, too, is available from your local Siemens representative. © Siemens AG 2015

4/4 Siemens LV 31 · 2015 4 Appendix Ordering notes ■ Overview Ordering special versions When ordering products that differ from the standard versions listed in the catalog, "–Z" must be added to the Article No. indi-cated and the required features must be specified using alpha-numeric order codes or plain text. Ordering very small quantities When very small orders are placed, the costs associated with or-der processing are greater than the order value. We therefore recommend that you combine several small orders. Where this is not possible, we regret that we are obliged to make a small processing charge: for orders with a net goods value of less than  € 250 we charge an € 20 supplement to cover our order pro- cessing and invoicing costs. Explanations of Selection and Ordering Data Delivery time class (DT) Preferred types are device types that can be delivered immediately ex works, i.e. they are dispatched within 24 hours.  If ordered in normal quantities, the products are usually delivered within the specified delivery times, calculated from the date we receive your order.  In exceptional cases, delivery times may vary from those specified.  The delivery times are valid ex works from Siemens AG (products ready for dispatch).  Shipping times depend on the destination and the method of shipping. The standard shipping time for Germany is one day. The specified delivery times are correct at the time of going to print and are subject to constant optimization. Up-to-date information can be found at  www.siemens.com/industrymall . Price units (PU) The price unit defines the number of units, sets or meters to which the specified price and weight apply. PS/P. unit (packaging size/packaging unit) The packaging size/packaging unit defines the number, e.g. of units, sets or meters, contained within outer packaging: • The first digit in the PS/P. unit column (packaging size/packaging unit) indicates the minimum order quantity. You can only order this  specified quantity or a multiple thereof. • The second digit in the PS/P. unit column (packaging size/packaging unit) specifies the number of units contained within the outer  packaging (e.g. in a carton). You must order this quantity or a multiple thereof if you want the items to be delivered in discrete packaging quantities.  Examples: Price group (PG) Each product is allocated to a price group. Weight The defined weight is the net weight in kg and refers to the price unit (PU). Examples Note: The article numbers shown here are examples only. They are not necessarily included in this catalog, nor is it essential that their specifications regarding selection and ordering data be up to date. When ordering, always use the selection and ordering data. DT Meaning } Preferred type A Two working days B One week C Three weeks D Six weeks X On request PS/P. unit Meaning 1 unit You can order one item or a multiple thereof. 5 units Five units are packed in a bag, for example. Because the bags cannot be opened, you can only order a multiple of the quantity contained in the bag: 5, 10, 15, 20 etc. 5/100 units One carton contains (for example) 20 bags, each containing 5 units, i.e. a total of 100 units. If only cartons are available for delivery, you need to order a multiple of the carton quantity: 100, 200, 300, etc. Ordering a quantity of 220 units would result in the following delivery: two cartons, each containing 100 units (= 200 units) and 4 bags, each containing 5 units (= 20 units). 1 set A set comprises a defined number of different parts. DT Article No. Price per PU PU (UNIT, SET, M) PS/ P. unit PG Weightper PU approx. kg } 3NW7013 1 1/12 units 017 0.076 DT: Preferred  type PU: One unit (on which price is based) PS/P. unit: 1 = minimum order quantity / 12 = quantity per  carton PG: 017 Weight per PU 76 g, always given in kg DT Article No. Price per PU PU (UNIT, SET, M) PS/ P. unit PG 8HP2021 1 1 unit 046 PU: One unit (on which price is based) PS/P. unit: 1 = minimum order quantity PG: 046 © Siemens AG 2015

4/5 Siemens LV 31 · 2015 4 Appendix Further documentation ■ Low-voltage power distribution and electrical installation technology on the WWW  We regard product support to be just as important as the products and systems themselves.  Visit our website for a comprehensive offering of support for low-voltage power distribution and electrical installation products, such as: • Overview of the entire product portfolio • Keeping up to date via newsletters, podcasts, blogs and  Twitter • Access to interesting videos on YouTube • Contact with partners around the world • Operating instructions and manuals for direct download and much more - all conveniently and easily accessible. www.siemens.com/lowvoltage ■ Information and Download Center You will find regularly updated information material such as catalogs, customer magazines, brochures and trial versions of software for low-voltage power distribution and electrical instal-lations on the Internet at  www.siemens.com/lowvoltage/infomaterial Here you can order your copy of the available documentation or download it in common file formats (PDF, ZIP). © Siemens AG 2015

4/6 Siemens LV 31 · 2015 4 Appendix Further documentation ■ Industry Mall The Industry Mall – for online information, product selection and ordering: • Detailed information including product data, illustrations,  certificates and CAx data • Simple configuring of systems • Possible to request individualized quotations • Availability check • Online ordering facility • Order tracking/order overview • Fast access to relevant training offers and services You can find the Industry Mall on the Internet at www.siemens.com/industrymall ■ Industry Online Support Comprehensive support – at any time, whatever your location • FAQs, sample applications, information about successor pro- ducts and product news • Prompt assistance with technical queries • Discussions and best practice sharing with other users in the  forum • Provision of high-quality product data for your planning  programs • Faster access to information – with helpful filter and folder  functions in mySupport • Automatic notification service to keep you up to date with the  latest information about topics of interest to you To find the link to Siemens Industry Online Support, go to www.siemens.com/lowvoltage/product-support © Siemens AG 2015

4/7 Siemens LV 31 · 2015 4 Appendix Further documentation ■ Industry Online Support App  Android:  Apple iOS:  Windows:  Main functions at a glance • Scanning of product codes (EAN/QR and data matrix codes)  with direct display of all technical information on the product, including graphic data (CAx data).   • Delivery of product information or entries by e-mail, so that the  information can immediately be processed at the workplace.   • Submission of queries to Technical Support (Support  Requests). With photo function for transmitting detailed information.   • Contents and interfaces available in six languages (German,  English, French, Italian, Spanish and Chinese) – including option of temporary switchover to English.   • Offline cache function for all favorites stored in "mySupport".  These entries can also be retrieved without network reception.   • Import of PDF documents into a library (e.g. iBooks or similar).  • An overview of the main functions can be found at  www.siemens.com/lowvoltage/support-app s Industry Online Support AppANDROID Industry Online Support AppiOS Industry Online Support AppWINDOWS 8 © Siemens AG 2015

4/8 Siemens LV 31 · 2015 4 Appendix Further documentation ■ Product configurator Find the right product faster using intuitive product selection • Complete selection of products and systems based on  technical characteristics or application requirements • Simple, intuitive operation • Option to save the configuration and order lists in a file format  of your choice (txt, pdf, xls, csv) • Direct transfer of the order list into the shopping cart of the  Siemens Industry Mall • Fast access to product data, diagrams, certificates and  CAx data for the selected product and system configuration • Available in multiple languages for use by customers  anywhere in the world The configurators are available online in the Siemens Industry Mall. A product selection process could hardly be made any cle-arer, faster or easier. You can find our configurators at the following website:  www.siemens.com/lowvoltage/configurators © Siemens AG 2015

4/9 Siemens LV 31 · 2015 4 Appendix Further documentation ■ CAx Download Manager The 12 CAx data types are listed below: www.siemens.com/lowvoltage/cax The CAx Download Manager can supply you with all the neces-sary CAx file types for the products of your choice for use in all common CAE and CAD systems. The data contained in the files is continuously updated. The whole process involves only four selection steps and is free of charge. All your selected files are packed into a zip file which you can download for further use. This service will cut the time it takes you to integrate product data into your CAE and CAD system by up to 80 %. Siemens makes available up to 12 file types to support your mechanical (CAD) and electrical (CAE) planning processes for you to download at any time of the day. Time savings of up to 80 % with universal product data for your CAE and CAD systems  • No manual data collection necessary • Universal manufacturer data for all common CAE and CAD  systems • Standardized documentation is simple to generate • Choice of different languages for system commissioning  anywhere in the world ■ My Documentation Manager In "mySupport" you can compile individual documentation for your project by dragging and dropping e.g. Low Voltage Directive 2006/95/EC and EC Machinery Directive 2006/42/EC In accordance with directives , the documentation is part of the plant and requires certification, thus giving the purchaser the right to full plant documentation. To support you in this, a manual configurator has been develo-ped with which you can put together individual and standard-compliant documentation – fully in accordance with the relevant project-specific requirements. You can thus select the chapters relevant to the respective project from the available manuals of the installed Siemens com-ponents. FAQs, certificates, data sheets and your own content can also be incorporated. This means that the documentation is perfectly tailored to your individual needs, making information easier to locate. User-friendly compilation of project-specific documentation • Compile and structure manuals, data sheets, FAQs and  certificates simply by dragging and dropping • Insert personalized content via the Notes function • Further processing possible thanks to selectable export  formats (pdf, xml, rtf) • After generating the documentation, automatic translation into  the desired language is possible • Always up-to-the minute thanks to the Update function You can find "My Documentation Manager" on the Internet at www.siemens.com/lowvoltage/mdm   EPLAN Electric P8 Macros  Data sheets Certificates Product images Characteristic curves Operating instructions Manuals Product master data 3D models Terminal connec-tion diagrams Dimensional drawings Internal circuit diagrams IC01_00265 © Siemens AG 2015

4/10 Siemens LV 31 · 2015 4 Appendix Quality management ■ Overview    The quality management system of our EM LP Business Unit complies with the international standard EN ISO 9001. The products and systems listed in this catalog are developed and manufactured using a certified quality management system in accordance with EN ISO 9001:2008. © Siemens AG 2015

4/11 Siemens LV 31 · 2015 4 Appendix Standards and approvals ■ Overview                Certificates An overview, updated on a daily basis, of our products certified in accordance with CE, UL, CSA, FM, shipping authorizations etc. for products in the areas of low-voltage power distribution, electrical installation technology and industrial controls as well as additional technical documentation can be found on the Internet at www.siemens.com/lowvoltage/certificates In the  Entry list  you can filter the view in order to quickly find  comprehensive information on the following subjects: • Product or search term • Date • Type of certificate (general product approval, test certificates,  shipping approval, ...) • Certificate (confirmations, UL, VDE,...) • Approval office (TÜV, VDE, UL, ...) • Country © Siemens AG 2015

4/12 Siemens LV 31 · 2015 4 Appendix Standards and approvals ■ Approval requirements valid in different countries  Siemens low-voltage switchgear and controlgear are designed, manufactured and tested according to the relevant German standards (DIN and VDE), IEC publications and European stan-dards (EN) as well as CSA and UL standards. The standards assigned to the single devices are stated in the relevant parts of this catalog. In addition to the pertinent VDE, EN and IEC standards, the requirements of the various regulations valid in other countries have also been taken into account in the design of the equip-ment in some cases, in order that the devices can be deployed globally as far as possible. In some countries an approval is required for certain low-voltage switchgear and controlgear components. Depending on the market requirements, these devices have been submitted for approval to the authorized testing institutes. In some cases, CSA for Canada and UL for the USA only approve special versions. Such special versions are listed separately from the standard versions in the relevant parts of this catalog. For this equipment, there are sometimes limits with regard to the maximum permissible voltages, currents and rated outputs or special approvals and, in some cases, special identification may be required. For use on board ship, the specifications of the marine classifi-cation societies must also be observed. In some cases, they require type tests of the components to be approved. www.siemens.com/lowvoltage/certificates If you have any questions concerning UL/CSA approvals, contact Technical Support:  www.siemens.com/lowvoltage/contact © Siemens AG 2015

4/13 Siemens LV 31 · 2015 4 Appendix Siemens contacts ■ Contact partners at Siemens Low-Voltage Power Distribution and Electrical Installation Technology  At Siemens Low-Voltage Power Distribution and Electrical Installation Technology, more than 85 000 people are resolutely pursuing the same goal:  Long-term improvement of your competitive ability.  We are committed to this goal. Thanks to our dedication, we are continually setting new standards. In all industries – worldwide. At your service, locally, around the globe: Partners for consul-ting, sales, training, service, support, spare parts ... on the entire Siemens range of Low-Voltage Power Distribution and Electrical Installation Technology. Your personal contact can be found in our Contact Database at www.siemens.com/lowvoltage/contact You start by selecting a  • competence, • product or branch, • country, • city. © Siemens AG 2015

4/14 Siemens LV 31 · 2015 4 AppendixService & Support Unrivaled complete range of services ■ Online Support  Our comprehensive online infor-mation platform covers every aspect of our Service & Support and is available whenever, wherever. More detailed information is available at www.siemens.com/lowvoltage/product-support ■ Field Service Siemens Field Service offers support with all aspects of main-tenance – so that the availability of your machines and plants is assured whatever the case. More detailed information is available at www.siemens.com/lowvoltage/contact ■ Technical Support The competent consulting service for technical issues with a broad range of customer-oriented services for all our pro-ducts and systems. More detailed information is available at www.siemens.com/lowvoltage/contact ■ Spare Parts Plants and systems in all indust-ries worldwide are expected to meet ever higher levels of avai-lability. We can help you rule out unex-pected stoppages: with a global network and optimum logistics chains. More detailed information is available at  www.siemens.com/lowvoltage/contact ■ Training Extend your lead – with practice-related know-how straight from the manufacturer. More detailed information is available at www.siemens.com/lowvoltage/training ■ Specification textsYou can obtain qualified, free support to help you produce specifications for technically equipping non-residential and industrial buildings at www.siemens.com/specifications © Siemens AG 2015

4/15 Siemens LV 31 · 2015 4 Appendix Comprehensive support from A to Z ■ Overview Product information Website Fast and targeted information on low-voltage power distribution: www.siemens.com/lowvoltage Newsletter Always up to date about our trend-setting products and systems: www.siemens.com/lowvoltage/newsletter Product information/product & system selection Information and Download Center Current catalogs, customer magazines, brochures, demo software and promotion packages: www.siemens.com/lowvoltage/infomaterial Industry Mall Comprehensive information and order platform for the Siemens Industry Basket: www.siemens.com/lowvoltage/mall Product and system engineering SIMARIS software tools Support in planning and configuring the electrical power distribution: www.siemens.com/simaris SIMARIS ConFiguration Basic planning and confi-guration tool Assists in generating offers and configuring products ranging from ALPHA distribution boards to the SIVACON S4 power distribution boards www.siemens.com/scfb Product documentation Siemens Industry Online Support Comprehensive technical information - from planning to configuration and operation: www.siemens.com/lowvoltage/product-support Product configurator Complete selection of products and systems based  on technical characteristics or application require-ments: www.siemens.com/lowvoltage/configurators CAx Download Manager Collation of CAx data types for standard CAE and CAD systems: www.siemens.com/lowvoltage/cax My Documentation Manager Compilation of project-specific documentation: www.siemens.com/lowvoltage/mdm Image database Collection of product photographs and graphics, such as dimensional drawings and internal circuit diagrams: www.siemens.com/lowvoltage/picturedb Product training SITRAIN Portal Comprehensive training program for our products, systems and engineering tools: www.siemens.com/lowvoltage/training Product hotline Technical Support Support in all technical queries about our products: E-mail: [email protected] www.siemens.com/lowvoltage/contact © Siemens AG 2015

4/16 Siemens LV 31 · 2015 4 Appendix Article No. index incl. export markings ■ Overview Article No. Page Weight Export markings kg ECCN AL 3VM1 3VM1010-2ED32-0AA0  2/4, 4/16 0.944 EAR99 N 3VM1010-2ED42-0AA0  2/6 1.300 EAR99 N 3VM1010-3ED32-0AA0  2/5 0.941 EAR99 N 3VM1010-3ED42-0AA0  2/7 1.300 EAR99 N 3VM1010-4ED32-0AA0  2/5 0.940 EAR99 N 3VM1010-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1020-2ED32-0AA0  2/4 1.000 EAR99 N 3VM1020-2ED42-0AA0  2/6 1.300 EAR99 N 3VM1020-3ED32-0AA0  2/5 1.000 EAR99 N 3VM1020-3ED42-0AA0  2/7 1.300 EAR99 N 3VM1020-4ED32-0AA0  2/5 1.000 EAR99 N 3VM1020-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1025-2ED32-0AA0  2/4 1.000 EAR99 N 3VM1025-2ED42-0AA0  2/6 1.300 EAR99 N 3VM1025-3ED32-0AA0  2/5 1.000 EAR99 N 3VM1025-3ED42-0AA0  2/7 1.300 EAR99 N 3VM1025-4ED32-0AA0  2/5 1.000 EAR99 N 3VM1025-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1032-2ED32-0AA0  2/4 0.952 EAR99 N 3VM1032-2ED42-0AA0  2/6 1.300 EAR99 N 3VM1032-3ED32-0AA0  2/5 0.954 EAR99 N 3VM1032-3ED42-0AA0  2/7 1.300 EAR99 N 3VM1032-4ED32-0AA0  2/5 1.000 EAR99 N 3VM1032-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1040-2ED32-0AA0  2/4 0.939 EAR99 N 3VM1040-2ED42-0AA0  2/6 1.300 EAR99 N 3VM1040-3ED32-0AA0  2/5 0.938 EAR99 N 3VM1040-3ED42-0AA0  2/7 1.300 EAR99 N 3VM1040-4ED32-0AA0  2/5 1.000 EAR99 N 3VM1040-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1050-2ED32-0AA0  2/4 1.000 EAR99 N 3VM1050-2ED42-0AA0  2/6 1.300 EAR99 N 3VM1050-3ED32-0AA0  2/5 1.000 EAR99 N 3VM1050-3ED42-0AA0  2/7 1.300 EAR99 N 3VM1050-4ED32-0AA0  2/5 1.000 EAR99 N 3VM1050-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1063-2ED32-0AA0  2/4 0.938 EAR99 N 3VM1063-2ED42-0AA0  2/6 1.300 EAR99 N 3VM1063-3ED32-0AA0  2/5 0.940 EAR99 N 3VM1063-3ED42-0AA0  2/7 1.300 EAR99 N 3VM1063-4ED32-0AA0  2/5 0.941 EAR99 N 3VM1063-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1080-2ED32-0AA0  2/4 0.942 EAR99 N 3VM1080-2ED42-0AA0  2/6 1.300 EAR99 N 3VM1080-3ED32-0AA0  2/5 0.939 EAR99 N 3VM1080-3ED42-0AA0  2/7 1.300 EAR99 N 3VM1080-4ED32-0AA0  2/5 1.000 EAR99 N 3VM1080-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1096-2ED32-0AA0  2/4 1.000 EAR99 N 3VM1096-2ED42-0AA0  2/6 1.300 EAR99 N 3VM1096-3ED32-0AA0  2/5 1.000 EAR99 N 3VM1096-3ED42-0AA0  2/7 1.300 EAR99 N 3VM1096-4ED32-0AA0  2/5 1.000 EAR99 N 3VM1096-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1110-1AA32-0AA0  2/13 1.000 EAR99 N 3VM1110-1AA42-0AA0  2/13 1.000 EAR99 N 3VM1110-3ED12-0AA0  2/2 1.000 EAR99 N 3VM1110-3ED22-0AA0  2/2 1.000 EAR99 N 3VM1110-3ED32-0AA0  2/4 0.788 EAR99 N 3VM1110-3ED42-0AA0  2/6 1.000 EAR99 N 3VM1110-3EE32-0AA0  2/4 0.939 EAR99 N 3VM1110-3EE42-0AA0  2/8 1.000 EAR99 N 3VM1110-3GD42-0AA0  2/8 1.000 EAR99 N 3VM1110-3GE42-0AA0  2/10 1.000 EAR99 N 3VM1110-4ED12-0AA0  2/3 1.000 EAR99 N 3VM1110-4ED22-0AA0  2/3 1.000 EAR99 N 3VM1110-4ED32-0AA0  2/5 0.788 EAR99 N 3VM1110-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1110-4EE32-0AA0  2/5 0.788 EAR99 N 3VM1110-4EE42-0AA0  2/9 1.000 EAR99 N 3VM1110-4GD42-0AA0  2/9 1.000 EAR99 N 3VM1110-4GE42-0AA0  2/11 1.000 EAR99 N 3VM1110-5ED32-0AA0  2/5 0.788 EAR99 N 3VM1110-5ED42-0AA0  2/7 1.000 EAR99 N 3VM1110-5EE32-0AA0  2/5 0.788 EAR99 N 3VM1110-5EE42-0AA0  2/9 1.000 EAR99 N 3VM1110-5GD42-0AA0  2/9 1.000 EAR99 N 3VM1110-5GE42-0AA0  2/11 1.000 EAR99 N 3VM1110-5MH32-0AA0  2/12 1.000 EAR99 N 3VM1112-1AA32-0AA0  2/13 1.000 EAR99 N 3VM1112-1AA42-0AA0  2/13 1.000 EAR99 N 3VM1112-3ED12-0AA0  2/2 1.000 EAR99 N 3VM1112-3ED22-0AA0  2/2 1.000 EAR99 N 3VM1112-3ED32-0AA0  2/4 0.788 EAR99 N 3VM1112-3ED42-0AA0  2/6 1.000 EAR99 N 3VM1112-3EE32-0AA0  2/4 0.978 EAR99 N 3VM1112-3EE42-0AA0  2/8 1.000 EAR99 N 3VM1112-3GD42-0AA0  2/8 1.000 EAR99 N 3VM1112-3GE42-0AA0  2/10 1.000 EAR99 N 3VM1112-4ED12-0AA0  2/3 1.000 EAR99 N 3VM1112-4ED22-0AA0  2/3 1.000 EAR99 N 3VM1112-4ED32-0AA0  2/5 0.788 EAR99 N 3VM1112-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1112-4EE32-0AA0  2/5 0.788 EAR99 N 3VM1112-4EE42-0AA0  2/9 1.000 EAR99 N 3VM1112-4GD42-0AA0  2/9 1.000 EAR99 N 3VM1112-4GE42-0AA0  2/11 1.000 EAR99 N 3VM1112-5ED32-0AA0  2/5 0.788 EAR99 N 3VM1112-5ED42-0AA0  2/7 1.000 EAR99 N 3VM1112-5EE32-0AA0  2/5 0.788 EAR99 N 3VM1112-5EE42-0AA0  2/9 1.000 EAR99 N 3VM1112-5GD42-0AA0  2/9 1.000 EAR99 N 3VM1112-5GE42-0AA0  2/11 1.000 EAR99 N 3VM1112-5MH32-0AA0  2/12 1.000 EAR99 N 3VM1116-1AA32-0AA0  2/13 1.000 EAR99 N 3VM1116-1AA42-0AA0  2/13 1.000 EAR99 N 3VM1116-3ED12-0AA0  2/2 1.000 EAR99 N Article No. Page Weight Export markings kg ECCN AL © Siemens AG 2015

4/17 Siemens LV 31 · 2015 4 Appendix Article No. index incl. export markings 3VM1116-3ED22-0AA0  2/2 1.000 EAR99 N 3VM1116-3ED32-0AA0  2/4 0.788 EAR99 N 3VM1116-3ED42-0AA0  2/6 1.000 EAR99 N 3VM1116-3EE32-0AA0  2/4 0.979 EAR99 N 3VM1116-3EE42-0AA0  2/8 1.000 EAR99 N 3VM1116-3GD42-0AA0  2/8 1.000 EAR99 N 3VM1116-3GE42-0AA0  2/10 1.000 EAR99 N 3VM1116-4ED12-0AA0  2/3 1.000 EAR99 N 3VM1116-4ED22-0AA0  2/3 1.000 EAR99 N 3VM1116-4ED32-0AA0  2/5 0.788 EAR99 N 3VM1116-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1116-4EE32-0AA0  2/5 0.788 EAR99 N 3VM1116-4EE42-0AA0  2/9 1.000 EAR99 N 3VM1116-4GD42-0AA0  2/9 1.000 EAR99 N 3VM1116-4GE42-0AA0  2/11 1.000 EAR99 N 3VM1116-5ED32-0AA0  2/5 0.788 EAR99 N 3VM1116-5ED42-0AA0  2/7 1.000 EAR99 N 3VM1116-5EE32-0AA0  2/5 0.788 EAR99 N 3VM1116-5EE42-0AA0  2/9 1.000 EAR99 N 3VM1116-5GD42-0AA0  2/9 1.000 EAR99 N 3VM1116-5GE42-0AA0  2/11 1.000 EAR99 N 3VM1120-3ED12-0AA0  2/2 1.000 EAR99 N 3VM1120-3ED22-0AA0  2/2 1.000 EAR99 N 3VM1120-3ED32-0AA0  2/4 0.788 EAR99 N 3VM1120-3ED42-0AA0  2/6 1.000 EAR99 N 3VM1120-3EE32-0AA0  2/4 0.788 EAR99 N 3VM1120-3EE42-0AA0  2/8 1.000 EAR99 N 3VM1120-3GD42-0AA0  2/8 1.000 EAR99 N 3VM1120-3GE42-0AA0  2/10 1.000 EAR99 N 3VM1120-4ED12-0AA0  2/3 1.000 EAR99 N 3VM1120-4ED22-0AA0  2/3 1.000 EAR99 N 3VM1120-4ED32-0AA0  2/5 0.788 EAR99 N 3VM1120-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1120-4EE32-0AA0  2/5 0.788 EAR99 N 3VM1120-4EE42-0AA0  2/9 1.000 EAR99 N 3VM1120-4GD42-0AA0  2/9 1.000 EAR99 N 3VM1120-4GE42-0AA0  2/11 1.000 EAR99 N 3VM1120-5ED32-0AA0  2/5 0.788 EAR99 N 3VM1120-5ED42-0AA0  2/7 1.000 EAR99 N 3VM1120-5EE32-0AA0  2/5 0.788 EAR99 N 3VM1120-5EE42-0AA0  2/9 1.000 EAR99 N 3VM1120-5GD42-0AA0  2/9 1.000 EAR99 N 3VM1120-5GE42-0AA0  2/11 1.000 EAR99 N 3VM1125-3ED12-0AA0  2/2 1.000 EAR99 N 3VM1125-3ED22-0AA0  2/2 1.000 EAR99 N 3VM1125-3ED32-0AA0  2/4 0.788 EAR99 N 3VM1125-3ED42-0AA0  2/6 1.000 EAR99 N 3VM1125-3EE32-0AA0  2/4 0.788 EAR99 N 3VM1125-3EE42-0AA0  2/8 1.000 EAR99 N 3VM1125-3GD42-0AA0  2/8 1.000 EAR99 N 3VM1125-3GE42-0AA0  2/10 1.000 EAR99 N 3VM1125-4ED12-0AA0  2/3 1.000 EAR99 N 3VM1125-4ED22-0AA0  2/3 1.000 EAR99 N 3VM1125-4ED32-0AA0  2/5 0.788 EAR99 N 3VM1125-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1125-4EE32-0AA0  2/5 0.788 EAR99 N Article No. Page Weight Export markings kg ECCN AL 3VM1125-4EE42-0AA0  2/9 1.000 EAR99 N 3VM1125-4GD42-0AA0  2/9 1.000 EAR99 N 3VM1125-4GE42-0AA0  2/11 1.000 EAR99 N 3VM1125-5ED32-0AA0  2/5 0.788 EAR99 N 3VM1125-5ED42-0AA0  2/7 1.000 EAR99 N 3VM1125-5EE32-0AA0  2/5 0.788 EAR99 N 3VM1125-5EE42-0AA0  2/9 1.000 EAR99 N 3VM1125-5GD42-0AA0  2/9 1.000 EAR99 N 3VM1125-5GE42-0AA0  2/11 1.000 EAR99 N 3VM1132-3ED12-0AA0  2/2 1.000 EAR99 N 3VM1132-3ED22-0AA0  2/2 1.000 EAR99 N 3VM1132-3ED32-0AA0  2/4 0.788 EAR99 N 3VM1132-3ED42-0AA0  2/6 1.000 EAR99 N 3VM1132-3EE32-0AA0  2/4 0.788 EAR99 N 3VM1132-3EE42-0AA0  2/8 1.000 EAR99 N 3VM1132-3GD42-0AA0  2/8 1.000 EAR99 N 3VM1132-3GE42-0AA0  2/10 1.000 EAR99 N 3VM1132-4ED12-0AA0  2/3 1.000 EAR99 N 3VM1132-4ED22-0AA0  2/3 1.000 EAR99 N 3VM1132-4ED32-0AA0  2/5 0.788 EAR99 N 3VM1132-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1132-4EE32-0AA0  2/5 0.788 EAR99 N 3VM1132-4EE42-0AA0  2/9 1.000 EAR99 N 3VM1132-4GD42-0AA0  2/9 1.000 EAR99 N 3VM1132-4GE42-0AA0  2/11 1.000 EAR99 N 3VM1132-5ED32-0AA0  2/5 0.788 EAR99 N 3VM1132-5ED42-0AA0  2/7 1.000 EAR99 N 3VM1132-5EE32-0AA0  2/5 0.788 EAR99 N 3VM1132-5EE42-0AA0  2/9 1.000 EAR99 N 3VM1132-5GD42-0AA0  2/9 1.000 EAR99 N 3VM1132-5GE42-0AA0  2/11 1.000 EAR99 N 3VM1132-5MH32-0AA0  2/12 1.000 EAR99 N 3VM1140-3ED12-0AA0  2/2 1.000 EAR99 N 3VM1140-3ED22-0AA0  2/2 1.000 EAR99 N 3VM1140-3ED32-0AA0  2/4 0.788 EAR99 N 3VM1140-3ED42-0AA0  2/6 1.000 EAR99 N 3VM1140-3EE32-0AA0  2/4 0.788 EAR99 N 3VM1140-3EE42-0AA0  2/8 1.000 EAR99 N 3VM1140-3GD42-0AA0  2/8 1.000 EAR99 N 3VM1140-3GE42-0AA0  2/10 1.000 EAR99 N 3VM1140-4ED12-0AA0  2/3 1.000 EAR99 N 3VM1140-4ED22-0AA0  2/3 1.000 EAR99 N 3VM1140-4ED32-0AA0  2/5 0.788 EAR99 N 3VM1140-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1140-4EE32-0AA0  2/5 0.788 EAR99 N 3VM1140-4EE42-0AA0  2/9 1.000 EAR99 N 3VM1140-4GD42-0AA0  2/9 1.000 EAR99 N 3VM1140-4GE42-0AA0  2/11 1.000 EAR99 N 3VM1140-5ED32-0AA0  2/5 0.788 EAR99 N 3VM1140-5ED42-0AA0  2/7 1.000 EAR99 N 3VM1140-5EE32-0AA0  2/5 0.788 EAR99 N 3VM1140-5EE42-0AA0  2/9 1.000 EAR99 N 3VM1140-5GD42-0AA0  2/9 1.000 EAR99 N 3VM1140-5GE42-0AA0  2/11 1.000 EAR99 N 3VM1140-5MH32-0AA0  2/12 1.000 EAR99 N 3VM1150-3ED12-0AA0  2/2 1.000 EAR99 N Article No. Page Weight Export markings kg ECCN AL © Siemens AG 2015

4/18 Siemens LV 31 · 2015 4 Appendix Article No. index incl. export markings 3VM1150-3ED22-0AA0  2/2 1.000 EAR99 N 3VM1150-3ED32-0AA0  2/4 0.788 EAR99 N 3VM1150-3ED42-0AA0  2/6 1.000 EAR99 N 3VM1150-3EE32-0AA0  2/4 0.788 EAR99 N 3VM1150-3EE42-0AA0  2/8 1.000 EAR99 N 3VM1150-3GD42-0AA0  2/8 1.000 EAR99 N 3VM1150-3GE42-0AA0  2/10 1.000 EAR99 N 3VM1150-4ED12-0AA0  2/3 1.000 EAR99 N 3VM1150-4ED22-0AA0  2/3 1.000 EAR99 N 3VM1150-4ED32-0AA0  2/5 0.788 EAR99 N 3VM1150-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1150-4EE32-0AA0  2/5 0.788 EAR99 N 3VM1150-4EE42-0AA0  2/9 1.000 EAR99 N 3VM1150-4GD42-0AA0  2/9 1.000 EAR99 N 3VM1150-4GE42-0AA0  2/11 1.000 EAR99 N 3VM1150-5ED32-0AA0  2/5 0.788 EAR99 N 3VM1150-5ED42-0AA0  2/7 1.000 EAR99 N 3VM1150-5EE32-0AA0  2/5 0.788 EAR99 N 3VM1150-5EE42-0AA0  2/9 1.000 EAR99 N 3VM1150-5GD42-0AA0  2/9 1.000 EAR99 N 3VM1150-5GE42-0AA0  2/11 1.000 EAR99 N 3VM1150-5MH32-0AA0  2/12 1.000 EAR99 N 3VM1163-1AA32-0AA0  2/13 1.000 EAR99 N 3VM1163-1AA42-0AA0  2/13 1.000 EAR99 N 3VM1163-3ED12-0AA0  2/2 1.000 EAR99 N 3VM1163-3ED22-0AA0  2/2 1.000 EAR99 N 3VM1163-3ED32-0AA0  2/4 0.788 EAR99 N 3VM1163-3ED42-0AA0  2/6 1.000 EAR99 N 3VM1163-3EE32-0AA0  2/4 0.940 EAR99 N 3VM1163-3EE42-0AA0  2/8 1.000 EAR99 N 3VM1163-3GD42-0AA0  2/8 1.000 EAR99 N 3VM1163-3GE42-0AA0  2/10 1.000 EAR99 N 3VM1163-4ED12-0AA0  2/3 1.000 EAR99 N 3VM1163-4ED22-0AA0  2/3 1.000 EAR99 N 3VM1163-4ED32-0AA0  2/5 0.788 EAR99 N 3VM1163-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1163-4EE32-0AA0  2/5 0.788 EAR99 N 3VM1163-4EE42-0AA0  2/9 1.000 EAR99 N 3VM1163-4GD42-0AA0  2/9 1.000 EAR99 N 3VM1163-4GE42-0AA0  2/11 1.000 EAR99 N 3VM1163-5ED32-0AA0  2/5 0.788 EAR99 N 3VM1163-5ED42-0AA0  2/7 1.000 EAR99 N 3VM1163-5EE32-0AA0  2/5 0.788 EAR99 N 3VM1163-5EE42-0AA0  2/9 1.000 EAR99 N 3VM1163-5GD42-0AA0  2/9 1.000 EAR99 N 3VM1163-5GE42-0AA0  2/11 1.000 EAR99 N 3VM1163-5MH32-0AA0  2/12 1.000 EAR99 N 3VM1180-3ED12-0AA0  2/2 1.000 EAR99 N 3VM1180-3ED22-0AA0  2/2 1.000 EAR99 N 3VM1180-3ED32-0AA0  2/4 0.788 EAR99 N 3VM1180-3ED42-0AA0  2/6 1.000 EAR99 N 3VM1180-3EE32-0AA0  2/4 0.788 EAR99 N 3VM1180-3EE42-0AA0  2/8 1.000 EAR99 N 3VM1180-3GD42-0AA0  2/8 1.000 EAR99 N 3VM1180-3GE42-0AA0  2/10 1.000 EAR99 N 3VM1180-4ED12-0AA0  2/3 1.000 EAR99 N Article No. Page Weight Export markings kg ECCN AL 3VM1180-4ED22-0AA0  2/3 1.000 EAR99 N 3VM1180-4ED32-0AA0  2/5 0.788 EAR99 N 3VM1180-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1180-4EE32-0AA0  2/5 0.788 EAR99 N 3VM1180-4EE42-0AA0  2/9 1.000 EAR99 N 3VM1180-4GD42-0AA0  2/9 1.000 EAR99 N 3VM1180-4GE42-0AA0  2/11 1.000 EAR99 N 3VM1180-5ED32-0AA0  2/5 0.788 EAR99 N 3VM1180-5ED42-0AA0  2/7 1.000 EAR99 N 3VM1180-5EE32-0AA0  2/5 0.788 EAR99 N 3VM1180-5EE42-0AA0  2/9 1.000 EAR99 N 3VM1180-5GD42-0AA0  2/9 1.000 EAR99 N 3VM1180-5GE42-0AA0  2/11 1.000 EAR99 N 3VM1180-5MH32-0AA0  2/12 1.000 EAR99 N 3VM1196-3ED12-0AA0  2/2 1.000 EAR99 N 3VM1196-3ED22-0AA0  2/2 1.000 EAR99 N 3VM1196-3ED32-0AA0  2/4 0.788 EAR99 N 3VM1196-3ED42-0AA0  2/6 1.000 EAR99 N 3VM1196-3EE32-0AA0  2/4 0.788 EAR99 N 3VM1196-3EE42-0AA0  2/8 1.000 EAR99 N 3VM1196-3GD42-0AA0  2/8 1.000 EAR99 N 3VM1196-3GE42-0AA0  2/10 1.000 EAR99 N 3VM1196-4ED12-0AA0  2/3 1.000 EAR99 N 3VM1196-4ED22-0AA0  2/3 1.000 EAR99 N 3VM1196-4ED32-0AA0  2/5 0.788 EAR99 N 3VM1196-4ED42-0AA0  2/7 1.000 EAR99 N 3VM1196-4EE32-0AA0  2/5 0.788 EAR99 N 3VM1196-4EE42-0AA0  2/9 1.000 EAR99 N 3VM1196-4GD42-0AA0  2/9 1.000 EAR99 N 3VM1196-4GE42-0AA0  2/11 1.000 EAR99 N 3VM1196-5ED32-0AA0  2/5 0.788 EAR99 N 3VM1196-5ED42-0AA0  2/7 1.000 EAR99 N 3VM1196-5EE32-0AA0  2/5 0.788 EAR99 N 3VM1196-5EE42-0AA0  2/9 1.000 EAR99 N 3VM1196-5GD42-0AA0  2/9 1.000 EAR99 N 3VM1196-5GE42-0AA0  2/11 1.000 EAR99 N 3VM1216-5MH32-0AA0  2/12 1.800 EAR99 N 3VM1220-4ED32-0AA0  2/5 1.800 EAR99 N 3VM1220-4ED42-0AA0  2/7 2.300 EAR99 N 3VM1220-4EE32-0AA0  2/5 1.800 EAR99 N 3VM1220-4EE42-0AA0  2/9 2.300 EAR99 N 3VM1220-4GD42-0AA0  2/9 2.300 EAR99 N 3VM1220-4GE42-0AA0  2/11 2.300 EAR99 N 3VM1220-5ED32-0AA0  2/5 1.800 EAR99 N 3VM1220-5ED42-0AA0  2/7 2.300 EAR99 N 3VM1220-5EE32-0AA0  2/5 1.800 EAR99 N 3VM1220-5EE42-0AA0  2/9 2.300 EAR99 N 3VM1220-5GD42-0AA0  2/9 2.300 EAR99 N 3VM1220-5GE42-0AA0  2/11 2.300 EAR99 N 3VM1220-5MH32-0AA0  2/12 1.800 EAR99 N 3VM1225-1AA32-0AA0  2/13 1.600 EAR99 N 3VM1225-1AA42-0AA0  2/13 2.100 EAR99 N 3VM1225-4ED32-0AA0  2/5 1.800 EAR99 N 3VM1225-4ED42-0AA0  2/7 2.300 EAR99 N 3VM1225-4EE32-0AA0  2/5 1.800 EAR99 N 3VM1225-4EE42-0AA0  2/9 2.300 EAR99 N Article No. Page Weight Export markings kg ECCN AL © Siemens AG 2015

4/19 Siemens LV 31 · 2015 4 Appendix Article No. index incl. export markings 3VM1225-4GD42-0AA0  2/9 2.300 EAR99 N 3VM1225-4GE42-0AA0  2/11 2.300 EAR99 N 3VM1225-5ED32-0AA0  2/5 1.800 EAR99 N 3VM1225-5ED42-0AA0  2/7 2.300 EAR99 N 3VM1225-5EE32-0AA0  2/5 1.800 EAR99 N 3VM1225-5EE42-0AA0  2/9 2.300 EAR99 N 3VM1225-5GD42-0AA0  2/9 2.300 EAR99 N 3VM1225-5GE42-0AA0  2/11 2.300 EAR99 N 3VM9 3VM9110-0WB00  3/19, 3/25 0.012 EAR99 N 3VM9110-0WC00  3/19, 3/25 0.010 EAR99 N 3VM9111-0QE10  3/17 0.058 EAR99 N 3VM9111-0QE20  3/17 0.096 EAR99 N 3VM9111-0SS10  3/29 0.018 EAR99 N 3VM9111-0WD10  3/17 0.014 EAR99 N 3VM9111-0WD20  3/17 0.016 EAR99 N 3VM9111-0WD30  3/17 0.019 EAR99 N 3VM9111-0WD40  3/17 0.021 EAR99 N 3VM9111-0WF20  3/18 0.072 EAR99 N 3VM9111-0WF30  3/18 0.143 EAR99 N 3VM9111-0WF40  3/18 0.183 EAR99 N 3VM9111-0WG30  3/18 0.182 EAR99 N 3VM9111-0WG40  3/18 0.225 EAR99 N 3VM9111-0WJ20  3/18 0.013 EAR99 N 3VM9111-0WJ30  3/18 0.019 EAR99 N 3VM9111-0WJ40  3/19 0.022 EAR99 N 3VM9111-0WK30  3/19 0.035 EAR99 N 3VM9111-0WK40  3/19 0.044 EAR99 N 3VM9112-0JC12  3/14 0.237 EAR99 N 3VM9112-0JJ12  3/13 0.234 EAR99 N 3VM9112-0SG20  3/19 0.026 EAR99 N 3VM9113-0JB11  3/13 0.047 EAR99 N 3VM9113-0JC12  3/14 0.240 EAR99 N 3VM9113-0JG11  3/13 0.051 EAR99 N 3VM9113-0JJ12  3/13 0.332 EAR99 N 3VM9113-0KB01  3/22 0.032 EAR99 N 3VM9113-0KB03  3/22 0.018 EAR99 N 3VM9113-0KB04  3/23 0.144 EAR99 N 3VM9113-0KB05  3/23 0.182 EAR99 N 3VM9113-0KP00  3/21 0.952 EAR99 N 3VM9113-0KP10  3/21 0.264 EAR99 N 3VM9113-0QA00  3/16 0.047 EAR99 N 3VM9113-0QE00  3/17 0.188 EAR99 N 3VM9113-0SG10  3/19 0.012 EAR99 N 3VM9114-0JB11  3/13 0.059 EAR99 N 3VM9114-0JC12  3/14 0.443 EAR99 N 3VM9114-0JG11  3/13 0.063 EAR99 N 3VM9114-0JJ12  3/14 0.438 EAR99 N 3VM9114-0KB01  3/22 0.036 EAR99 N 3VM9114-0KB03  3/22 0.020 EAR99 N 3VM9114-0KB04  3/23 0.184 EAR99 N 3VM9114-0KB05  3/23 0.230 EAR99 N 3VM9114-0KP00  3/21 1.178 EAR99 N 3VM9114-0KP10  3/21 0.323 EAR99 N 3VM9114-0QA00  3/16 0.058 EAR99 N 3VM9114-0QE00  3/17 0.270 EAR99 N Article No. Page Weight Export markings kg ECCN AL 3VM9114-0RS10  3/27 0.963 EAR99 N 3VM9114-0RS20  3/27 0.953 EAR99 N 3VM9114-0SG10  3/19 0.017 EAR99 N 3VM9114-0SS10  3/29 0.031 EAR99 N 3VM9116-0SS10  3/29 0.017 EAR99 N 3VM9117-0EK11  3/7 0.199 EAR99 N 3VM9117-0EK15  3/7 0.199 EAR99 N 3VM9117-0EK21  3/7 1.000 EAR99 N 3VM9117-0EK25  3/7 1.000 EAR99 N 3VM9117-0FK21  3/7 0.541 EAR99 N 3VM9117-0FK25  3/7 0.543 EAR99 N 3VM9117-0KB02  3/22 0.032 EAR99 N 3VM9151-0QB00 3/16 0.035 EAR99 N 3VM9152-0QC00 3/16 0.050 EAR99 N 3VM9152-0WA00  3/17 0.042 EAR99 N 3VM9153-0JA11  3/13 0.083 EAR99 N 3VM9153-0JC12 3/24 0.337 EAR99 N 3VM9153-0QB00  3/16 0.113 EAR99 N 3VM9153-0QC00  3/16 0.151 EAR99 N 3VM9154-0JA11  3/13 0.106 EAR99 N 3VM9154-0JC12 3/24 0.600 EAR99 N 3VM9154-0QB00  3/16 0.151 EAR99 N 3VM9154-0QC00  3/16 0.200 EAR99 N 3VM9157-0SA10  3/29 0.016 EAR99 N 3VM9181-0SH10  3/29 0.028 N N 3VM9182-0SH10  3/29 0.048 N N 3VM9187-0SH10  3/29 0.066 EAR99 N 3VM9187-0SH20  3/29 0.103 EAR99 N 3VM9188-0LB10  3/28 1.000 EAR99 N 3VM9200-0WB00  3/19, 3/25 0.119 EAR99 N 3VM9200-0WC00  3/19, 3/25 0.105 EAR99 N 3VM9211-0QE10  3/17 0.106 EAR99 N 3VM9211-0QE20  3/17 0.196 EAR99 N 3VM9211-0WD30  3/17 0.010 EAR99 N 3VM9211-0WD40  3/17 0.013 EAR99 N 3VM9211-0WF30  3/18 0.094 EAR99 N 3VM9211-0WF40  3/18 0.121 EAR99 N 3VM9211-0WG30  3/18 0.248 EAR99 N 3VM9211-0WG40  3/18 0.318 EAR99 N 3VM9211-0WJ30  3/18 0.030 EAR99 N 3VM9211-0WJ40  3/19 0.038 EAR99 N 3VM9211-0WK30  3/19 0.060 EAR99 N 3VM9211-0WK40  3/19 0.078 EAR99 N 3VM9213-0JC13  3/14 0.465 EAR99 N 3VM9213-0JC22  3/15 0.529 EAR99 N 3VM9213-0JJ13  3/13 0.454 EAR99 N 3VM9213-0JJ22  3/14 0.523 EAR99 N 3VM9213-0KB01  3/22 0.039 EAR99 N 3VM9213-0KB03  3/22 0.012 EAR99 N 3VM9213-0KB04  3/23 0.104 EAR99 N 3VM9213-0KB05  3/23 0.243 EAR99 N 3VM9213-0KP00  3/21 1.321 EAR99 N 3VM9213-0KP10  3/21 0.504 EAR99 N 3VM9213-0QA00  3/16 0.103 EAR99 N 3VM9213-0QE00  3/17 0.377 EAR99 N 3VM9214-0JC13  3/14 0.616 EAR99 N Article No. Page Weight Export markings kg ECCN AL © Siemens AG 2015

4/20 Siemens LV 31 · 2015 4 Appendix Article No. index incl. export markings A product's export markings are updated daily at  www.siemens.com/industrymall . 3VM9214-0JC22  3/15 0.705 EAR99 N 3VM9214-0JJ13  3/14 0.600 EAR99 N 3VM9214-0JJ22  3/14 0.698 EAR99 N 3VM9214-0KB01  3/22 0.050 EAR99 N 3VM9214-0KB03  3/22 0.015 EAR99 N 3VM9214-0KB04  3/23 0.131 EAR99 N 3VM9214-0KB05  3/23 0.309 EAR99 N 3VM9214-0KP00  3/21 1.770 EAR99 N 3VM9214-0KP10  3/21 0.629 EAR99 N 3VM9214-0QA00  3/16 0.132 EAR99 N 3VM9214-0QE00  3/17 0.557 EAR99 N 3VM9214-0RS20  3/27 1.000 EAR99 N 3VM9217-0EK11  3/7 1.000 EAR99 N 3VM9217-0EK15  3/7 1.000 EAR99 N 3VM9217-0EK21  3/7 1.000 EAR99 N 3VM9217-0EK25  3/7 1.000 EAR99 N 3VM9217-0FK21  3/7 1.000 EAR99 N 3VM9217-0FK25  3/7 1.000 EAR99 N 3VM9217-0GA80  3/7 0.020 EAR99 N 3VM9217-0KB02  3/22 0.045 EAR99 N 3VM9252-0WA00  3/17 0.045 EAR99 N 3VM9253-0JA11  3/13 0.173 EAR99 N 3VM9253-0JA12  3/13 0.203 EAR99 N 3VM9253-0JB12  3/13 0.130 EAR99 N 3VM9253-0JC13 3/24 0.465 EAR99 N 3VM9253-0JC22  3/24 0.529 EAR99 N 3VM9253-0JG12  3/13 0.123 EAR99 N 3VM9253-0QB00  3/16 0.248 EAR99 N 3VM9253-0QC00  3/16 0.309 EAR99 N 3VM9254-0JA11  3/13 0.227 EAR99 N 3VM9254-0JA12  3/13 0.267 EAR99 N 3VM9254-0JB12  3/13 0.165 EAR99 N 3VM9254-0JC13 3/24 0.611 EAR99 N 3VM9254-0JC22  3/24 0.705 EAR99 N 3VM9254-0JG12  3/13 0.153 EAR99 N 3VM9254-0QB00  3/16 0.334 EAR99 N 3VM9254-0QC00  3/16 0.422 EAR99 N 3VM9257-0SA10  3/29 0.024 EAR99 N 3VM9908-0BB10  3/5 0.078 EAR99 N 3VM9908-0BB11  3/5 0.078 EAR99 N 3VM9908-0BB12  3/5 0.077 EAR99 N 3VM9908-0BB13  3/5 0.078 EAR99 N 3VM9908-0BB14  3/5 0.077 EAR99 N 3VM9908-0BB15  3/5 0.077 EAR99 N 3VM9908-0BB16  3/5 0.078 EAR99 N 3VM9908-0BB20  3/5 0.080 EAR99 N 3VM9908-0BB21  3/5 0.079 EAR99 N 3VM9908-0BB22  3/5 0.080 EAR99 N 3VM9908-0BB23  3/5 0.081 EAR99 N 3VM9908-0BB24  3/5 0.079 EAR99 N 3VM9908-0BB25  3/5 0.078 EAR99 N 3VM9908-0BB26  3/5 0.091 EAR99 N 3VM9908-0BB27  3/5 0.079 EAR99 N 3VM9987-0KP80  3/22 0.073 EAR99 N 3VM9988-0AA12  3/5 0.023 EAR99 N 3VM9988-0AA13  3/5 0.023 EAR99 N Article No. Page Weight Export markings kg ECCN AL 3VM9988-0AB12  3/5 1.000 EAR99 N 3VM9908-0AB13  3/5 0.022 EAR99 N 3VM9908-0BL10  3/5 1.000 EAR99 N 3VM9908-0BL20  3/5 0.081 EAR99 N 3VM9908-0BL30  3/5 0.810 EAR99 N 3VM9908-0BL31  3/5 0.080 EAR99 N 3VM9908-0BL32  3/5 0.080 EAR99 N 3VM9908-0BL33  3/5 1.000 EAR99 N 8UD1 8UD1721-0AB11  3/7 0.164 EAR99 N 8UD1721-0AB15  3/7 0.164 EAR99 N 8UD1721-0AB21  3/7 0.217 EAR99 N 8UD1721-0AB25  3/7 0.216 EAR99 N 8UD1900-2DA00  3/7 0.025 EAR99 N 8UD1900-2WA00  3/7 0.129 EAR99 N 8UD1900-2WB00  3/7 0.280 EAR99 N 8US1 8US1213-4AP03  3/29 1.020 N N 8US1213-4AU01  3/29 0.569 N N Article No. Page Weight Export markings kg ECCN AL © Siemens AG 2015

4/21 Siemens LV 31 · 2015 4 Appendix Conditions of sale and delivery ■ Overview  By using this catalog you can acquire hardware and software products described therein from Siemens AG subject to the following terms. Please note! The scope, the quality and the con-ditions for supplies and services, including software products, by any Siemens entity having a registered office outside of Germany, shall be subject exclusively to the General Terms and Conditions of the respective Siemens entity. The following terms apply exclusively for orders placed with Siemens AG. For customers with a seat or registered office in Germany The “General Terms of Payment” as well as the “General Conditions for the Supply of Products and Services of the Electrical and Electronics Industry” shall apply.For software products, the “General License Conditions for Software Products for Automation and Drives for Customers with a Seat or registered Office in Germany” shall apply. For customers with a seat or registered office outside of Germany The “General Terms of Payment” as well as the “General Conditions for Supplies of Siemens, Automation and Drives for Customers with a Seat or registered Office outside of Germany” shall apply.For software products, the “General License Conditions for Software Products for Automation and Drives for Customers with a Seat or registered Office outside of Germany” shall apply. General The dimensions are in mm. In Germany, according to the German law on units in measuring technology, data in inches only apply to devices for export. Illustrations are not binding.Insofar as there are no remarks on the corresponding pages, - especially with regard to data, dimensions and weights given - these are subject to change without prior notice.The prices are in  € (Euro) ex works, exclusive packaging. The sales tax (value added tax) is not included in the prices. It shall be debited separately at the respective rate according to the applicable legal regulations.Prices are subject to change without prior notice. We will debit the prices valid at the time of delivery.Surcharges will be added to the prices of products that contain silver, copper, aluminum, lead and/or gold if the respective ba-sic official prices for these metals are exceeded. These surchar-ges will be determined based on the official price and the metal factor of the respective product.The surcharge will be calculated on the basis of the official price on the day prior to receipt of the order or prior to the release order.The metal factor determines the official price as of which the me-tal surcharges are charged and the calculation method used. The metal factor, provided it is relevant, is included with the price information of the respective products. You will find • an exact explanation of the metal factor,  • the text of the Comprehensive Terms and Conditions of Sale  and Delivery of Siemens AG in the Internet under www.siemens.com/automation/salesmaterial-as/catalog/en/ terms_of_trade_en.pdf Export regulations Siemens shall not be obligated to fulfill this agreement if such ful-fillment is prevented by any impediments arising out of national or international foreign trade or customs requirements or any embargoes or other sanctions.If Purchaser transfers goods (hardware and/ or software and/ or technology as well as corresponding documentation, regardless of the mode of provision) delivered by Siemens or works and services (including all kinds of technical support) performed by Siemens to a third party worldwide, Purchaser shall comply with all applicable national and international (re-) export control regulations. In any event Purchaser shall comply with the (re-) export control regulations of the Federal Republic of Germany, of the European Union and of the United States of America.If required to conduct export control checks, Purchaser, upon request by Siemens, shall promptly provide Siemens with all information pertaining to particular end customer, destination and intended use of goods, works and services provided by Siemens, as well as any export control restrictions existing.Purchaser shall indemnify and hold harmless Siemens from and against any claim, proceeding, action, fine, loss, cost and damages arising out of or relating to any noncompliance with export control regulations by Purchaser, and Purchaser shall compensate Siemens for all losses and expenses resulting the-reof, unless such noncompliance was not caused by fault of the Purchaser. This provision does not imply a change in burden of proof.The products listed in this catalog / price list may be subject to European / German and/or US export regulations.Therefore, any export requiring a license is subject to approval by the competent authorities.According to current provisions, the following export regulations must be observed with respect to the products featured in this catalog / price list: Even without a label, or with label "AL:N" or "ECCN:N", authoriza-tion may be required due to the final end-use and destination for which the goods are to be used.In addition, you can preview the export designations via our "Industry Mall" online catalog system in the respective product description. The deciding factors are the AL or ECCN export authorization indicated on order confirmations, delivery notes and invoices. Errors excepted and subject to change without prior notice. AL Number of the German Export List Products marked other than “N” require an export license. In the case of software products, the export designations of the relevant data medium must also be generally adhered to. Goods labeled with an “AL“ not equal to “N” are subject to Eu-ropean or German export authorization when being exported out of the EU. ECCN Export Control Classification Number Products marked other than “N” are subject to a reexport license to specific countries. In the case of software products, the export designations of the relevant data medium must also be generally adhered to. Goods labeled with “ECCN“ not equal to “N” are subject to US re-export authorization. © Siemens AG 2015

4/22 Siemens LV 31 · 2015 4 Appendix Notes © Siemens AG 2015

4/23 Siemens LV 31 · 2015 4 Appendix Notes © Siemens AG 2015

4/24 Siemens LV 31 · 2015 4 Appendix Notes © Siemens AG 2015
