Surge arrester Type 2 DEHNcord 3-pole w. connecting cable IP65
Three-pole DEHNcord L type 2 surge arrester according to EN 61643-11 with a compact design for use in the junction boxes of LED mast lights with disconnection of the load circuit in the event of a fault and protection of the control phase. For installation in conformity with the lightning protection zone concept at the boundaries from 0B – 1 and higher.
Ürün kimlikleri
SKU: 900447
EAN: 4013364282216
GTIN: 4013364282216
MPN: DCOR L 3P 275 SO IP
Kategoriler
Özellikler
|
Category type 2
|
evet
|
|
Max. PV-voltage
|
-
|
|
Mounting method
|
Direct mounting
|
|
Construction size
|
Other
|
|
Nominal voltage AC
|
230 V
|
|
Nominal voltage DC
|
-
|
|
Leakage-current free
|
-
|
|
Integrated backup fuse
|
-
|
|
System configuration DC
|
-
|
|
System configuration IT
|
-
|
|
System configuration TN
|
-
|
|
System configuration TT
|
-
|
|
Signalling at the device
|
Optical
|
|
Voltage protection level
|
-
|
|
Degree of protection (IP)
|
IP65
|
|
System configuration TN-C
|
-
|
|
System configuration TN-S
|
-
|
|
Max. continuous voltage AC
|
275 V
|
|
Max. continuous voltage DC
|
-
|
|
System configuration other
|
-
|
|
System configuration TN-C-S
|
-
|
|
Voltage protection level L-N
|
1.5 kV
|
|
Voltage protection level N-PE
|
1.5 kV
|
|
With remote signalling contact
|
-
|
|
Integrated short-circuit protection
|
-
|
|
Max. discharge surge current (8/20)
|
10 kA
|
|
Nominal discharge surge current (8/20)
|
5 kA
|
|
Number of conductors (without earthing)
|
3
|
|
Short-circuit breaking capacity (Isccr)
|
6 kA
|
|
Max. conductor cross section flexible (fine-strand)
|
-
|
|
Max. conductor cross section solid (solid, stranded)
|
-
|
|
Integrated short-circuit protection selective to fuse gG
|
-
|
|
Max. overcurrent protection device, series connection (fuse)
|
-
|
|
Max. overcurrent protection device, parallel connection (fuse)
|
16 A
|
