ESP 480D1R Surge Protective Device

Name: ESP 480D1R Surge Protective Device
Brand: ABB
SKU: 7TCA085460R0339

ESP 480D1R TYPE 1+2+3 POWER SPD FOR 3 PHASE 480V SUPPLIES, LED STATUS INDICATION ON REMOTE DISPLAY, DIN RAIL MOUNTING

Ürün kimlikleri

SKU: 7TCA085460R0339

EAN: 5415022308044

GTIN: 5415022308044

MPN: ESP 480D1R

Kategoriler

Switchgear & Circuit Protection Circuit Breakers RCDs

Earthing, lightning and surge protection

Category type 2	evet
Max. PV-voltage	-
Mounting method	DIN rail (top hat rail) 35 mm
Construction size	8 modular spacing
Nominal voltage AC	277 V
Nominal voltage DC	-
Leakage-current free	-
Integrated backup fuse	evet
System configuration DC	hayır
System configuration IT	hayır
System configuration TN	evet
System configuration TT	hayır
Signalling at the device	Optical
Voltage protection level	1 kV
Degree of protection (IP)	IP20
System configuration TN-C	evet
System configuration TN-S	evet
Max. continuous voltage AC	350 V
Max. continuous voltage DC	-
System configuration other	hayır
System configuration TN-C-S	evet
Voltage protection level L-N	1 kV
Voltage protection level N-PE	1 kV
With remote signalling contact	evet
Integrated short-circuit protection	-
Max. discharge surge current (8/20)	40 kA
Nominal discharge surge current (8/20)	25 kA
Number of conductors (without earthing)	4
Short-circuit breaking capacity (Isccr)	25 kA
Max. conductor cross section flexible (fine-strand)	25 mm²
Max. conductor cross section solid (solid, stranded)	25 mm²
Integrated short-circuit protection selective to fuse gG	-
Max. overcurrent protection device, series connection (fuse)	-
Max. overcurrent protection device, parallel connection (fuse)	-
