DEHNventil M combined lightning current and surge arrester Type 1 + Type 2
Multipole DEHNventil modular type 1 and type 2 according to EN 61643-11 spark-gap-based combined lightning current and surge arrester consisting of a base part and pluggable protection modules. Maximum availability due to RADAX Flow follow current limitation. Capable of protecting terminal equipment. For protecting low-voltage consumer´s installations against surges and even direct lightning strikes. For installation in conformity with the lightning protection zone concept at the boundaries from 0A – 2.
Ürün kimlikleri
SKU: 951310
EAN: 4013364108172
GTIN: 4013364108172
MPN: DV M TT 255
Kategoriler
Teknik özellikler
| Test class | Type 1 + 2 |
| Max. PV-voltage | - |
| Mounting method | DIN rail (top hat rail) 35 mm |
| Number of poles | 4 |
| Construction size | 8 modular spacing |
| Remote signalling | - |
| Nominal voltage AC | 230 V |
| Nominal voltage DC | - |
