Surge arrester module for intrins. safe measuring circuits BLITZDUCTOR XT Ex (i)
Space-saving LifeCheck-equipped surge arrester module for protecting one pair in intrinsically safe measuring circuits and RS485 bus systems. Insulation strength > 500 V line-earth. If LifeCheck detects thermal and electrical overload, the arrester has to be replaced. This status is indicated contactlessly by DEHNrecord LC / SCM / MCM.
Ürün kimlikleri
SKU: 920538
EAN: 4013364125285
GTIN: 4013364125285
MPN: BXT ML2 BD HF EX 6
Kategoriler
Teknik özellikler
| Frequency | |
| Connection 1 | - |
| Earthing via | Other |
| Assembly width | 12 mm |
| Mounting method | On basic element |
| Limiting frequency | 100 MHz |
| Nominal voltage AC | |
| Nominal voltage DC | 6.0 - 6.0 V |
