Single-pole earthing and short-circuit. cable 25mm² with crimped cable lugs
Single-pole earthing and short-circuiting device according to EN/IEC 61230 (DIN VDE 0683-100), cable cross-section: 25 mm², maximum short-circuit current / duration: 7.0 kA / 0.5 s - 2.5; length A = 5000 mm; phase cable equipped with 1x universal clamp Ø20/25 mm, T-pin shaft (Part No. 773 234) and earth cable equipped with 1x universal clamp Ø25/30 mm with handle (Part No. 774 330).
Ürün kimlikleri
SKU: VB1DETL
EAN: 4013364165632
GTIN: 4013364165632
MPN: EKV1+1 25 VB1DETL
Kategoriler
Özellikler
|
Model
|
Cable
|
|
Material
|
Copper
|
|
Fully insulated
|
-
|
|
Number of poles
|
1
|
|
Length earth line
|
-
|
|
Length 1-pole rope
|
5000 mm
|
|
Length phaseline a
|
-
|
|
Length phaseline b
|
-
|
|
Length phaseline c
|
-
|
|
Max. short circuit current
|
7.0 kA
|
|
Connecting part, earth-side
|
Universal clamp 25/30 mm
|
|
Connecting part, phase-side
|
Universal clamp 20/25 mm
|
|
Wire cross section, earth-side
|
25 mm²
|
|
Wire cross section, phase-side
|
25 mm²
|
