Three-pole earthing and short-circuiting cable 50mm² with crimped cable lugs
Three-pole earthing and short-circuiting device according to EN/IEC 61230 (DIN VDE 0683-100), cable cross-section: 50 mm² / 50 mm², maximum short-circuit current / duration: 14.0 kA / 0.5 s - 2.5; length A=B=C= 600 mm, length D = 1800 mm; phase cables equipped with 3x rigid ball head cap Ø20 mm, hexagon shaft (Part No. 772 310) and earth cable equipped with 1x earth connecting element M12 with wing nut (Part No. 775 621).
Ürün kimlikleri
SKU: VU8P6LE
EAN: 4013364165380
GTIN: 4013364165380
MPN: EKV3+1 50 G VU8P6LE
Kategoriler
Özellikler
|
Model
|
Cable
|
|
Material
|
Copper
|
|
Fully insulated
|
-
|
|
Number of poles
|
3
|
|
Length earth line
|
1800 mm
|
|
Length 1-pole rope
|
-
|
|
Length phaseline a
|
600 mm
|
|
Length phaseline b
|
600 mm
|
|
Length phaseline c
|
600 mm
|
|
Max. short circuit current
|
14.0 kA
|
|
Connecting part, earth-side
|
Earth connecting element with wing nut M12
|
|
Connecting part, phase-side
|
Spherical head bonnet 20 mm
|
|
Wire cross section, earth-side
|
50 mm²
|
|
Wire cross section, phase-side
|
50 mm²
|
