| EFI00218 |
3.248025 |
| EFI07337 |
0|0.1085 |
| EFI07343 |
0|0.0775 |
| EFI07515 |
-13|140 |
| Frequency |
50 - 60 Hz |
| Voltage type |
Other |
| Rated current |
1.6 A |
| Rated voltage |
400 V |
| Built-in depth |
82.5 mm |
| Explosion-proof |
hayır |
| Pollution degree |
3 |
| Over voltage category |
4 |
| Current limiting class |
3 |
| Release characteristic |
B |
| Number of poles (total) |
3 |
| Degree of protection (IP) |
IP20 |
| Number of protected poles |
3 |
| Flush-mounted installation |
evet |
| Rated insulation voltage Ui |
690 V |
| Additional equipment possible |
evet |
| Width in number of modular spacings |
4.5 |
| Ambient temperature during operating |
-25 - 60 °C |
| Rated impulse withstand voltage Uimp |
8 kV |
| Concurrently switching neutral conductor |
evet |
| Connectable conductor cross section solid-core |
|
| Connectable conductor cross section multi-wired |
|
| Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V |
- |
| Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V |
25 kA |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V |
- |
| Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V |
50 kA |
