| Category type 2 |
evet |
| Max. PV-voltage |
- |
| Mounting method |
On basic element |
| Construction size |
1 modular spacing |
| Nominal voltage AC |
230 V |
| Nominal voltage DC |
- |
| Leakage-current free |
- |
| Integrated backup fuse |
- |
| System configuration DC |
- |
| System configuration IT |
- |
| System configuration TN |
- |
| System configuration TT |
- |
| Signalling at the device |
Optical |
| Voltage protection level |
1.5 kV |
| Degree of protection (IP) |
- |
| System configuration TN-C |
- |
| System configuration TN-S |
- |
| Max. continuous voltage AC |
275 V |
| Max. continuous voltage DC |
350 V |
| System configuration other |
- |
| System configuration TN-C-S |
- |
| Voltage protection level L-N |
- |
| Voltage protection level N-PE |
- |
| With remote signalling contact |
- |
| Integrated short-circuit protection |
- |
| Max. discharge surge current (8/20) |
20 kA |
| Nominal discharge surge current (8/20) |
10 kA |
| Number of conductors (without earthing) |
- |
| Short-circuit breaking capacity (Isccr) |
- |
| Max. conductor cross section flexible (fine-strand) |
- |
| Max. conductor cross section solid (solid, stranded) |
- |
| Integrated short-circuit protection selective to fuse gG |
- |
| Max. overcurrent protection device, series connection (fuse) |
- |
| Max. overcurrent protection device, parallel connection (fuse) |
- |
