Telescopic earthing rod w. plug-in coup. L 1760-3015mm w. cone coupling SQL
Telescopic earthing stick, T-pin shaft. Operating head with robust aluminium bayonet coupling and pressure spring for safely supporting the portable earthing and short-circuiting device for outdoor switchgear installations and overhead lines according to EN 50110 (DIN VDE 0105-100). Continuously telescopable via aluminium star knob. End fitting with anti-rotation plastic plug-in coupling for easy and quick extension of handle including ring eye end fitting.
Ürün kimlikleri
SKU: 769300
EAN: 4013364080867
GTIN: 4013364080867
MPN: ESTC SQL STK 3000
Kategoriler
Teknik özellikler
| Diameter | 43 mm |
| Total length | 1760.0 - 2945.0 mm |
| Max. head load | 20 kg |
| Type of device | Earthing rod |
| Immersing depth | - |
| Nominal voltage | |
| Recording head for | Spindle with cross pin |
| Scope of application | Outdoor installations |
