| Depth |
119 mm |
| Width |
89 mm |
| Height |
131 mm |
| EFI00008 |
- |
| EFI00040 |
- |
| EFI00049 |
- |
| EFI00332 |
- |
| EFI00846 |
- |
| Stabilized |
evet |
| Power output |
240 W |
| Built-in width |
89 mm |
| Built-in height |
131 mm |
| Modular version |
hayır |
| Power consumption |
264 VA |
| Short-circuit-proof |
evet |
| Max. output current 1 |
- |
| Max. output current 2 |
|
| Max. output current 3 |
|
| Wall mounting possible |
hayır |
| Rated supply voltage DC |
480 - 820 V |
| Direct mounting possible |
hayır |
| Degree of protection (IP) |
IP20 |
| Output voltage stabilized |
evet |
| SIL according to IEC 61508 |
None |
| Suitable for rail mounting |
evet |
| Degree of protection (NEMA) |
1 |
| Type of electric connection |
Screw connection |
| 1st secondary output voltage |
48 - 48 V |
| 2nd secondary output voltage |
|
| 3rd secondary output voltage |
|
| Secondary voltage adjustable |
hayır |
| Rated supply voltage AC 50 Hz |
340 - 575 V |
| Rated supply voltage AC 60 Hz |
340 - 575 V |
| Suitable for safety functions |
hayır |
| Voltage type (supply voltage) |
AC/DC |
| Nominal value output current 1 |
5 A |
| Nominal value output current 2 |
|
| Nominal value output current 3 |
|
| Nominal value output voltage 1 |
48 V |
| Nominal value output voltage 2 |
|
| Nominal value output voltage 3 |
|
| Width in number of modular spacings |
- |
| Performance level according to EN ISO 13849-1 |
None |
