PCB-mounted 2-pole base for BLITZDUCTORconnect prot. modules
BLITZDUCTORconnect base part as a space-saving, two-pole basic unit for installation on printed circuit boards by means of soldering process. Supports a protection module with signal disconnection when arrester is removed. Integrated remote signalling contact (break contact / make contact) Since no components of the protective circuit are situated in the base part, maintenance work is restricted to the protection modules.
Ürün kimlikleri
SKU: 927305
EAN: 4013364454699
GTIN: 4013364454699
MPN: BCO BAS PCB FM
Kategoriler
Teknik özellikler
| Application | Information technology |
| Mounting method | Print mounting |
| Number of poles | 2 |
| Explosion-tested version | - |
| Signalling at the device | - |
| With decoupling inductance | - |
| With remote signalling contact | evet |
