ESP 120D-10A Surge Protective Device

Name: ESP 120D-10A Surge Protective Device
Brand: ABB
SKU: 7TCA085460R0328

ESP 120D-10A IN-LINE POWER SPD WITH LED STATUS INDICATION FOR 120V SUPPLIES UP TO 10A

Ürün kimlikleri

SKU: 7TCA085460R0328

EAN: 5415022286991

GTIN: 5415022286991

MPN: ESP 120D-10A

Kategoriler

Switchgear & Circuit Protection Circuit Breakers RCDs

Earthing, lightning and surge protection

Category type 3	evet
Mounting method	DIN rail (top hat rail) 35 mm
Number of poles	1
Nominal voltage AC	120 V
Nominal voltage DC	-
Nominal load current	10 A
Signalling at the device	None
Voltage protection level	1.3 kV
Degree of protection (IP)	IP20
Max. continuous voltage AC	150 V
Max. continuous voltage DC	-
Voltage protection level L-N	1 kV
With remote signalling contact	hayır
Voltage protection level L-PE/N-PE	1 kV
With interference suppressor filter	evet
Total discharge current (8/20) (L+N-PE)	20 kA
Nominal discharge surge current (8/20) (L-N)	20 kA
Total discharge current (8/20) (L1+L2+L3+N-PE)	-
Max. conductor cross section flexible (fine-strand)	6 mm²
Max. conductor cross section solid (solid, stranded)	6 mm²
Max. overcurrent protection device, series connection (fuse)	-
Max. overcurrent protection device, parallel connection (fuse)	-
