Teknik Veriler
Ana Özellikler
Mounting method
DIN rail (top hat rail) 35 mm
Connection 1
Screw terminal
Frequency
Lightning impulse current (10/350 µs)
5 kA
With remote signalling contact
-
Number of conductors (without earthing)
2
Voltage protection level
-
Limiting frequency
-
Explosion-tested version
-
Max. continuous voltage AC
-
Nominal discharge surge current (8/20)
20 kA
Nominal load current
7 A
Voltage protection level core/core
60 V
Voltage protection level core/earth
650 V
Max. continuous voltage DC
45 V
Degree of protection (IP)
IP20
Voltage protection level core/signal ground
-
Voltage protection level signal ground/protective ground
-
Nominal voltage AC
Nominal voltage DC
36.0 - 36.0 V
Pro-active thermo-control
-
Assembly width
27 mm
Signal disconnection
-
Earthing via
Separate conductor
İndirilenler

BLITZDUCTOR VT combined arrester
Ürün detayları
SKU Kodu: 918408
EAN Kodu: 4013364125292
Minimum sipariş: 1
Teknik Veriler
Ana Özellikler
Mounting method
DIN rail (top hat rail) 35 mm
Connection 1
Screw terminal
Frequency
Lightning impulse current (10/350 µs)
5 kA
With remote signalling contact
-
Number of conductors (without earthing)
2
Voltage protection level
-
Limiting frequency
-
Explosion-tested version
-
Max. continuous voltage AC
-
Nominal discharge surge current (8/20)
20 kA
Nominal load current
7 A
Voltage protection level core/core
60 V
Voltage protection level core/earth
650 V
Max. continuous voltage DC
45 V
Degree of protection (IP)
IP20
Voltage protection level core/signal ground
-
Voltage protection level signal ground/protective ground
-
Nominal voltage AC
Nominal voltage DC
36.0 - 36.0 V
Pro-active thermo-control
-
Assembly width
27 mm
Signal disconnection
-
Earthing via
Separate conductor
