Mounting method

On basic element

Connection 1

Screw terminal

Frequency

Lightning impulse current (10/350 µs)

10 kA

With remote signalling contact

-

Number of conductors (without earthing)

4

Voltage protection level

-

Limiting frequency

2.8 MHz

Explosion-tested version

evet

Max. continuous voltage AC

10.6 V

Nominal discharge surge current (8/20)

20 kA

Nominal load current

1 A

Voltage protection level core/core

19 V

Voltage protection level core/earth

550 V

Max. continuous voltage DC

15 V

Degree of protection (IP)

IP20

Voltage protection level core/signal ground

-

Voltage protection level signal ground/protective ground

-

Nominal voltage AC

Nominal voltage DC

12.0 - 12.0 V

Pro-active thermo-control

evet

Assembly width

12 mm

Signal disconnection

-

Earthing via

DIN rail (top hat rail)
