Compact combined arrester for DC power supply systems BLITZDUCTORconnect with status indication Zoomed Image
DEHN

Compact combined arrester for DC power supply systems BLITZDUCTORconnect with status indication

Space-saving, compact combined arrester with a width of 12 mm and push-in connection technology with status indication for protecting one pair in unearthed DC supplies for IT systems and measuring and control circuits.

Ürün detayları

SKU Kodu: 927408

EAN Kodu: 4013364463653

Minimum sipariş: 1

Teknik Veriler

Ana Özellikler

Mounting method

DIN rail (top hat rail) 35 mm

Connection 1

Push-in terminal

Frequency

Lightning impulse current (10/350 µs)

5 kA

With remote signalling contact

-

Number of conductors (without earthing)

2

Voltage protection level

-

Limiting frequency

2 MHz

Explosion-tested version

-

Max. continuous voltage AC

31.8 V

Nominal discharge surge current (8/20)

20 kA

Nominal load current

10 A

Voltage protection level core/core

100 V

Voltage protection level core/earth

800 V

Max. continuous voltage DC

45 V

Degree of protection (IP)

IP20

Voltage protection level core/signal ground

-

Voltage protection level signal ground/protective ground

-

Nominal voltage AC

Nominal voltage DC

24.0 - 24.0 V

Pro-active thermo-control

evet

Assembly width

12 mm

Signal disconnection

-

Earthing via

DIN rail (top hat rail)
