Mounting method

Surface mounted

Connection 1

Clamp

Frequency

Lightning impulse current (10/350 µs)

7.5 kA

With remote signalling contact

-

Number of conductors (without earthing)

2

Voltage protection level

-

Limiting frequency

425 MHz

Explosion-tested version

-

Max. continuous voltage AC

127 V

Nominal discharge surge current (8/20)

20 kA

Nominal load current

1 A

Voltage protection level core/core

700 V

Voltage protection level core/earth

550 V

Max. continuous voltage DC

180 V

Degree of protection (IP)

IP20

Voltage protection level core/signal ground

-

Voltage protection level signal ground/protective ground

-

Nominal voltage AC

Nominal voltage DC

180.0 - 180.0 V

Pro-active thermo-control

-

Assembly width

45 mm

Signal disconnection

-

Earthing via

-
