Modular combined arrester for 1 pair BLITZDUCTORconnect with status indication Zoomed Image
DEHN

Modular combined arrester for 1 pair BLITZDUCTORconnect with status indication

Space-saving, modular combined arrester with a width of 6 mm and push-in connection technology with status indication for protecting one pair of unearthed high-frequency bus systems as well as balanced interfaces. With signal disconnection for maintenance purposes.

Ürün detayları

SKU Kodu: 927275

EAN Kodu: 4013364468566

Minimum sipariş: 1

Teknik Veriler

Ana Özellikler

Mounting method

DIN rail (top hat rail) 35 mm

Connection 1

Push-in terminal

Frequency

Lightning impulse current (10/350 µs)

3 kA

With remote signalling contact

-

Number of conductors (without earthing)

2

Voltage protection level

-

Limiting frequency

100 MHz

Explosion-tested version

-

Max. continuous voltage AC

25.4 V

Nominal discharge surge current (8/20)

10 kA

Nominal load current

0.75 A

Voltage protection level core/core

85 V

Voltage protection level core/earth

650 V

Max. continuous voltage DC

36 V

Degree of protection (IP)

IP20

Voltage protection level core/signal ground

-

Voltage protection level signal ground/protective ground

-

Nominal voltage AC

Nominal voltage DC

24.0 - 24.0 V

Pro-active thermo-control

evet

Assembly width

6 mm

Signal disconnection

evet

Earthing via

DIN rail (top hat rail)
