Teknik Veriler
Ana Özellikler
Mounting method
DIN rail (top hat rail) 35 mm
Colour
Green/yellow
Width
12 mm
Height
47 mm
Depth
50 mm
Operating temperature
Inflammability class of insulation material according to UL94
-
Closing plate required
-
Type of electrical connection 1
Screw connection
Type of electrical connection 2
Screw connection
PEN function possible
-
Number of levels
-
Number of clamp positions per level
-
Connectable conductor cross section solid-core
6.0 - 25.0 mm²
Connectable conductor cross section fine-strand with cable end sleeve
Connectable conductor cross section fine-strand without cable end sleeve
Connectable conductor cross section multi-wired
6.0 - 16.0 mm²
Material insulation body
Thermoplastic
İndirilenler

Protective conductor terminal 16 mm² with universal base
Ürün detayları
SKU Kodu: 910099
EAN Kodu: 4013364037298
Minimum sipariş: 1
