Mounting method

DIN rail (top hat rail) 35 mm

Lightning impulse current (10/350 µs)

100 kA

With remote signalling contact

-

Number of conductors (without earthing)

1

Construction size

2 modular spacing

Voltage protection level

4 kV

Suitable for outdoor use

-

Exhausting

-

Follow current extinguishing capability

0.1 kA

Max. continuous voltage AC

255 V

Nominal discharge surge current (8/20)

-

Nominal voltage AC

-

Nominal voltage DC

-

Category type 1

evet

Voltage protection level L-N

-

Signalling at the device

-

Max. continuous voltage DC

-

Degree of protection (IP)

IP20

Voltage protection level N-PE

-

Integrated backup fuse

-

Max. conductor cross section solid (solid, stranded)

50 mm²

Max. conductor cross section flexible (fine-strand)

35 mm²

Voltage protection level (DC+ - DC-)

-

Voltage protection level (DC+/DC- - PE)

-

Specific energy (W/R)

2500 kJ/Ohm

System configuration DC

-

System configuration IT

-

System configuration TN

-

System configuration TN-C

-

System configuration TN-S

-

System configuration TT

evet

System configuration other

-

System configuration TN-C-S

-
