DEHNrecord SD multifunctional measuring and analysis device voltage supply 24 VDC Zoomed Image
DEHN

DEHNrecord SD multifunctional measuring and analysis device voltage supply 24 VDC

Integral, multifunctional measuring equipment based on edge computing in a compact housing for easy integration and retrofitting on DIN rails. Device for measuring the voltage quality according to EN 61000-4-30, class-A-certified, and limit values as per EN 50160. Measurement of temporary, power-frequency overvoltages according to EN50550. Communication link provided through Modbus TCP and MQTT 3.1 Azure.

Ürün detayları

SKU Kodu: 910921

EAN Kodu: 4013364460270

Minimum sipariş: 1

Teknik Veriler

Ana Özellikler

Width

90 mm

Height

107 mm

Depth

66 mm

Display

None

Number of digital inputs

3

Number of digital outputs

2

Number of analogue inputs

-

Number of analogue outputs

-

Voltage type (supply voltage)

DC

Supporting protocol for PROFIBUS

-

Supporting protocol for Modbus

evet

Supporting protocol for other bus systems

-

Degree of protection (IP), front side

IP20

Number of Ethernet connections

1

Supporting protocol for PROFINET IO

-

Supply voltage AC 50 Hz

Supply voltage AC 60 Hz

Supply voltage DC

18.0 - 30.0 V

Nominal voltage (Un) N-L

0.0 - 230.0 V

Nominal voltage (Un) L-L

Measuring range for frequency

42.5 - 57.5 Hz

Display resolution (horizontal)

-

Display resolution (vertical)

-

Accuracy class active energy according to IEC 62053-22

Other

Accuracy class reactive energy according to IEC 62053-23

Other

Sampling frequency

-

Accuracy class according to IEC 61000-4-30

A

Measurement of harmonics in frequency range 2 kHz - 9 kHz

-

Measurement of harmonics in frequency range 9 kHz - 150 kHz

-

Flicker according to IEC 61000-4-15

-

With transient detection

-

Sampling frequency for transient detection

-

Data evaluation according to EN 50160

evet

Data transfer via PQDif

-

Fault record transmission via COMTRADE

-

Number of voltage measurement inputs

4

Number of current measurement inputs

4

Supporting protocol for IEC 61850 Ethernet

-

Supporting protocol for OPC UA PubSub

-

With audit logging (audit log)

-

With firmware signature

evet

With logging of security events (security event log)

-

With Role Based Access Control (RBAC)

-

Web server with HTTPS transfer protocol

evet

Remote display

evet
