Isolating spark gap w. plastic sheath with 2 connections, Rd 10mm, StSt Zoomed Image
DEHN

Isolating spark gap w. plastic sheath with 2 connections, Rd 10mm, StSt

Isolating spark gap for indirectly connecting / earthing functionally isolated installation parts under lightning conditions. For lightning equipotential bonding according to IEC 62305 as well as for use in IT installations according to IEC 60364-5-54.

Ürün detayları

SKU Kodu: 923023

EAN Kodu: 4013364074262

Minimum sipariş: 1

Teknik Veriler

Ana Özellikler

Surface protection

-

Lightning impulse current (10/350 µs)

100 kA

Connection

Round 10 mm

Explosion-tested version

-

Suitable for connection

Other

Nominal discharge surge current (8/20)

-

Material of connection

Stainless steel 304 (V2A)

Degree of protection (IP)

IP65

Rated impulse sparkover voltage

4 kV

Rated power-frequency withstand voltage

300 V
