Mounting method

DIN rail (top hat rail) 35 mm

Connection 1

Push-in terminal

Frequency

Lightning impulse current (10/350 µs)

3 kA

With remote signalling contact

-

Number of conductors (without earthing)

2

Limiting frequency

3.5 MHz

Explosion-tested version

-

Max. continuous voltage AC

25.4 V

Nominal discharge surge current (8/20)

10 kA

Nominal load current

0.5 A

Voltage protection level core/core

65 V

Voltage protection level core/earth

1100 V

Signalling at the device

Optical

Max. continuous voltage DC

36 V

Degree of protection (IP)

IP20

Voltage protection level core/signal ground

-

Voltage protection level signal ground/protective ground

-

Nominal voltage AC

Nominal voltage DC

24.0 - 24.0 V

Pro-active thermo-control

evet

Assembly width

6 mm

Signal disconnection

hayır

Earthing via

DIN rail (top hat rail)
