DEHNgate surge arrester Zoomed Image
DEHN

DEHNgate surge arrester

The space-saving surge arrester with BNC socket can be mounted on DIN rails for protecting video and camera systems. Available with direct (VCD) or indirect shield connection (VCID) depending on the type to avoid being effected by leakage pickups.

Ürün detayları

SKU Kodu: 909711

EAN Kodu: 4013364118980

Minimum sipariş: 1

Teknik Veriler

Ana Özellikler

Mounting method

DIN rail (top hat rail) 35 mm

Connection 1

BNC, 75 Ohm

Frequency

0.0 - 300.0 MHz

Lightning impulse current (10/350 µs)

1 kA

With remote signalling contact

-

Number of conductors (without earthing)

1

Limiting frequency

-

Explosion-tested version

-

Max. continuous voltage AC

-

Nominal discharge surge current (8/20)

5 kA

Nominal load current

0.1 A

Voltage protection level core/core

-

Voltage protection level core/earth

-

Signalling at the device

-

Max. continuous voltage DC

6.4 V

Degree of protection (IP)

IP10

Voltage protection level core/signal ground

-

Voltage protection level signal ground/protective ground

-

Nominal voltage AC

Nominal voltage DC

5.0 - 5.0 V

Pro-active thermo-control

-

Assembly width

19 mm

Signal disconnection

-

Earthing via

Other
