Teknik Veriler
Ana Özellikler
Mounting method
Connector/cable adapter
Connection 1
BNC, 50 Ohm
Frequency
0.0 - 4000.0 MHz
Lightning impulse current (10/350 µs)
1 kA
With remote signalling contact
-
Number of conductors (without earthing)
1
Limiting frequency
-
Explosion-tested version
-
Max. continuous voltage AC
-
Nominal discharge surge current (8/20)
5 kA
Nominal load current
3.5 A
Voltage protection level core/core
-
Voltage protection level core/earth
-
Signalling at the device
-
Max. continuous voltage DC
135 V
Degree of protection (IP)
IP20
Voltage protection level core/signal ground
650 V
Voltage protection level signal ground/protective ground
-
Nominal voltage AC
Nominal voltage DC
Pro-active thermo-control
-
Assembly width
20 mm
Signal disconnection
hayır
Earthing via
Other
İndirilenler

DEHNgate surge arrester
Ürün detayları
SKU Kodu: 929042
EAN Kodu: 4013364091030
Minimum sipariş: 1
