DEHNrapid LSA protective plug Zoomed Image
DEHN

DEHNrapid LSA protective plug

Protective plug (one pair), energy-coordinated with DRL plug-in SPD block, for use as single-stage protective device for terminal equipment. Low voltage protection level line-line for floating interfaces. To be mounted into EF 10 DRL. Installation recommended only in combination with DRL plug-in SPD block.

Ürün detayları

SKU Kodu: 907441

EAN Kodu: 4013364107694

Minimum sipariş: 1

Teknik Veriler

Ana Özellikler

Mounting method

LSA-plus plug-in

Connection 1

-

Frequency

Lightning impulse current (10/350 µs)

5 kA

With remote signalling contact

-

Number of conductors (without earthing)

2

Limiting frequency

2.7 MHz

Explosion-tested version

-

Max. continuous voltage AC

9.5 V

Nominal discharge surge current (8/20)

10 kA

Nominal load current

0.4 A

Voltage protection level core/core

18 V

Voltage protection level core/earth

-

Signalling at the device

-

Max. continuous voltage DC

14 V

Degree of protection (IP)

IP20

Voltage protection level core/signal ground

-

Voltage protection level signal ground/protective ground

-

Nominal voltage AC

Nominal voltage DC

12.0 - 12.0 V

Pro-active thermo-control

-

Assembly width

9.4 mm

Signal disconnection

-

Earthing via

Other
