Mounting method

Other

Connection 1

D-Sub 9-pole

Frequency

Lightning impulse current (10/350 µs)

-

With remote signalling contact

-

Number of conductors (without earthing)

5

Limiting frequency

90 MHz

Explosion-tested version

-

Max. continuous voltage AC

-

Nominal discharge surge current (8/20)

0.4 kA

Nominal load current

-

Voltage protection level core/core

25 V

Voltage protection level core/earth

-

Signalling at the device

-

Max. continuous voltage DC

7 V

Degree of protection (IP)

IP40

Voltage protection level core/signal ground

25 V

Voltage protection level signal ground/protective ground

18 V

Nominal voltage AC

Nominal voltage DC

6.0 - 6.0 V

Pro-active thermo-control

-

Assembly width

31 mm

Signal disconnection

-

Earthing via

Separate conductor
