Mounting method

Mast/wall

Connection 1

RJ45

Frequency

Lightning impulse current (10/350 µs)

-

With remote signalling contact

-

Number of conductors (without earthing)

8

Limiting frequency

250 MHz

Explosion-tested version

-

Max. continuous voltage AC

6 V

Nominal discharge surge current (8/20)

10 kA

Nominal load current

1 A

Voltage protection level core/core

180 V

Voltage protection level core/earth

600 V

Signalling at the device

-

Max. continuous voltage DC

8.5 V

Degree of protection (IP)

IP66

Voltage protection level core/signal ground

-

Voltage protection level signal ground/protective ground

-

Nominal voltage AC

Nominal voltage DC

5.0 - 5.0 V

Pro-active thermo-control

-

Assembly width

118 mm

Signal disconnection

-

Earthing via

Separate conductor
