Teknik Veriler
Ana Özellikler
Mounting method
Other
Connection 1
Connection cable
Frequency
Lightning impulse current (10/350 µs)
1 kA
With remote signalling contact
-
Number of conductors (without earthing)
4
Limiting frequency
100 MHz
Explosion-tested version
evet
Max. continuous voltage AC
4.2 V
Nominal discharge surge current (8/20)
20 kA
Nominal load current
0.1 A
Voltage protection level core/core
12 V
Voltage protection level core/earth
700 V
Signalling at the device
-
Max. continuous voltage DC
6 V
Degree of protection (IP)
IP67
Voltage protection level core/signal ground
-
Voltage protection level signal ground/protective ground
-
Nominal voltage AC
Nominal voltage DC
5.0 - 5.0 V
Pro-active thermo-control
-
Assembly width
-
Signal disconnection
-
Earthing via
Separate conductor
İndirilenler

Surge arrester DEHNpipe Ex (d) with M20x1.5 male thread
Ürün detayları
SKU Kodu: 929971
EAN Kodu: 4013364120761
Minimum sipariş: 1
Teknik Veriler
Ana Özellikler
Mounting method
Other
Connection 1
Connection cable
Frequency
Lightning impulse current (10/350 µs)
1 kA
With remote signalling contact
-
Number of conductors (without earthing)
4
Limiting frequency
100 MHz
Explosion-tested version
evet
Max. continuous voltage AC
4.2 V
Nominal discharge surge current (8/20)
20 kA
Nominal load current
0.1 A
Voltage protection level core/core
12 V
Voltage protection level core/earth
700 V
Signalling at the device
-
Max. continuous voltage DC
6 V
Degree of protection (IP)
IP67
Voltage protection level core/signal ground
-
Voltage protection level signal ground/protective ground
-
Nominal voltage AC
Nominal voltage DC
5.0 - 5.0 V
Pro-active thermo-control
-
Assembly width
-
Signal disconnection
-
Earthing via
Separate conductor
