Mounting method

Other

Connection 1

Connection cable

Frequency

Lightning impulse current (10/350 µs)

1.5 kA

With remote signalling contact

-

Number of conductors (without earthing)

4

Limiting frequency

-

Explosion-tested version

-

Max. continuous voltage AC

25.4 V

Nominal discharge surge current (8/20)

20 kA

Nominal load current

0.55 A

Voltage protection level core/core

50 V

Voltage protection level core/earth

1200 V

Signalling at the device

-

Max. continuous voltage DC

36 V

Degree of protection (IP)

IP67

Voltage protection level core/signal ground

-

Voltage protection level signal ground/protective ground

-

Nominal voltage AC

Nominal voltage DC

24.0 - 24.0 V

Pro-active thermo-control

-

Assembly width

-

Signal disconnection

-

Earthing via

Separate conductor
