Mounting method

On basic element

Connection 1

-

Frequency

Lightning impulse current (10/350 µs)

-

With remote signalling contact

-

Number of conductors (without earthing)

4

Limiting frequency

7.8 MHz

Explosion-tested version

-

Max. continuous voltage AC

23.3 V

Nominal discharge surge current (8/20)

20 kA

Nominal load current

1.0 A

Voltage protection level core/core

45 V

Voltage protection level core/earth

550 V

Signalling at the device

-

Max. continuous voltage DC

33 V

Degree of protection (IP)

IP20

Voltage protection level core/signal ground

-

Voltage protection level signal ground/protective ground

-

Nominal voltage AC

Nominal voltage DC

24.0 - 24.0 V

Pro-active thermo-control

-

Assembly width

12 mm

Signal disconnection

-

Earthing via

Other
