Teknik Veriler
Ana Özellikler
Mounting method
Surface mounted
Connection 1
Screw terminal
Frequency
Lightning impulse current (10/350 µs)
-
With remote signalling contact
-
Number of conductors (without earthing)
4
Limiting frequency
7.7 MHz
Explosion-tested version
evet
Max. continuous voltage AC
-
Nominal discharge surge current (8/20)
20 kA
Nominal load current
-
Voltage protection level core/core
45 V
Voltage protection level core/earth
1100 V
Signalling at the device
-
Max. continuous voltage DC
33 V
Degree of protection (IP)
IP65
Voltage protection level core/signal ground
-
Voltage protection level signal ground/protective ground
-
Nominal voltage AC
Nominal voltage DC
24.0 - 24.0 V
Pro-active thermo-control
evet
Assembly width
160 mm
Signal disconnection
-
Earthing via
Other
İndirilenler

Terminal box for information technology systems
Ürün detayları
SKU Kodu: 989408
EAN Kodu: 4013364120396
Minimum sipariş: 1
