Teknik Veriler
Ana Özellikler
Mounting method
Direct mounting
With remote signalling contact
-
Max. continuous voltage AC
255 V
Nominal discharge surge current (8/20)
5 kA
Nominal load current
16 A
Nominal voltage AC
230 V
Nominal voltage DC
-
Voltage protection level L-N
1.25 kV
Voltage protection level L-PE/N-PE
1.5 kV
Signal critical frequency
50 MHz
Signal - max. continuous voltage AC
-
Signal - max. continuous voltage DC
180 V
Signalling at the device
Optical
Signal nominal discharge surge current (8/20)
-
Signal nominal load current
-
Signal nominal voltage AC
-
Signal nominal voltage DC
-
Signal safety level core/core
0.3 kV
Signal safety level core/earth
0.5 kV
Max. continuous voltage DC
-
Voltage protection level core/signal ground
-
Voltage protection level signal ground/protective ground
-
Connector (information technology)
RJ12
Signal frequency
Total discharge current (8/20)
-
İndirilenler

Surge arrester DEHNprotector combined adapter for power and data side
Ürün detayları
SKU Kodu: 909310
EAN Kodu: 4013364117747
Minimum sipariş: 1
