Mounting method

Direct mounting

With remote signalling contact

-

Max. continuous voltage AC

255 V

Nominal discharge surge current (8/20)

5 kA

Nominal load current

16 A

Nominal voltage AC

230 V

Nominal voltage DC

-

Voltage protection level L-N

1.25 kV

Voltage protection level L-PE/N-PE

1.5 kV

Signal critical frequency

120 MHz

Signal - max. continuous voltage AC

-

Signal - max. continuous voltage DC

58 V

Signalling at the device

Optical

Signal nominal discharge surge current (8/20)

10 kA

Signal nominal load current

-

Signal nominal voltage AC

-

Signal nominal voltage DC

-

Signal safety level core/core

0.09 kV

Signal safety level core/earth

0.5 kV

Max. continuous voltage DC

-

Voltage protection level core/signal ground

-

Voltage protection level signal ground/protective ground

-

Connector (information technology)

RJ45

Signal frequency

Total discharge current (8/20)

5 kA
