Varistor-based-protection module for DEHNguard M PV (type 2 surge arrester) Zoomed Image
DEHN

Varistor-based-protection module for DEHNguard M PV (type 2 surge arrester)

Protection module for DEHNguard modular arresters (type 2 according to EN 61643-31)

Ürün detayları

SKU Kodu: 952054

EAN Kodu: 4013364127975

Minimum sipariş: 1

Teknik Veriler

Ana Özellikler

Mounting method

On basic element

With remote signalling contact

-

Number of conductors (without earthing)

-

Construction size

1 modular spacing

Voltage protection level

2.25 kV

Max. continuous voltage AC

-

Nominal discharge surge current (8/20)

12.5 kA

Nominal voltage AC

-

Nominal voltage DC

-

Category type 2

evet

Voltage protection level L-N

-

Signalling at the device

Optical

Max. continuous voltage DC

600 V

Degree of protection (IP)

-

Max. PV-voltage

-

Voltage protection level N-PE

-

Integrated backup fuse

-

Max. conductor cross section solid (solid, stranded)

-

Max. conductor cross section flexible (fine-strand)

-

System configuration DC

-

System configuration IT

-

System configuration TN

-

System configuration TN-C

-

System configuration TN-S

-

System configuration TT

-

System configuration other

-

System configuration TN-C-S

-

Max. discharge surge current (8/20)

25 kA

Short-circuit breaking capacity (Isccr)

-

Max. overcurrent protection device, parallel connection (fuse)

-

Max. overcurrent protection device, series connection (fuse)

-

Integrated short-circuit protection

-

Integrated short-circuit protection selective to fuse gG

-

Leakage-current free

-
