Teknik Veriler
Ana Özellikler
Mounting method
DIN rail (top hat rail) 35 mm
With remote signalling contact
-
Number of poles
2
Voltage protection level
-
Max. continuous voltage AC
150 V
Total discharge current (8/20) (L+N-PE)
4 kA
Nominal discharge surge current (8/20) (L-N)
2 kA
Nominal load current
25 A
Nominal voltage AC
120 V
Nominal voltage DC
-
Category type 3
evet
Voltage protection level L-N
0.64 kV
Voltage protection level L-PE/N-PE
0.8 kV
Signalling at the device
Optical
Max. continuous voltage DC
150 V
Degree of protection (IP)
IP20
With interference suppressor filter
-
Max. conductor cross section solid (solid, stranded)
4 mm²
Max. conductor cross section flexible (fine-strand)
2.5 mm²
Total discharge current (8/20) (L1+L2+L3+N-PE)
-
Max. overcurrent protection device, parallel connection (fuse)
25 A
Max. overcurrent protection device, series connection (fuse)
25 A
İndirilenler

DEHNrail M surge arrester
Ürün detayları
SKU Kodu: 953204
EAN Kodu: 4013364109704
Minimum sipariş: 1
Teknik Veriler
Ana Özellikler
Mounting method
DIN rail (top hat rail) 35 mm
With remote signalling contact
-
Number of poles
2
Voltage protection level
-
Max. continuous voltage AC
150 V
Total discharge current (8/20) (L+N-PE)
4 kA
Nominal discharge surge current (8/20) (L-N)
2 kA
Nominal load current
25 A
Nominal voltage AC
120 V
Nominal voltage DC
-
Category type 3
evet
Voltage protection level L-N
0.64 kV
Voltage protection level L-PE/N-PE
0.8 kV
Signalling at the device
Optical
Max. continuous voltage DC
150 V
Degree of protection (IP)
IP20
With interference suppressor filter
-
Max. conductor cross section solid (solid, stranded)
4 mm²
Max. conductor cross section flexible (fine-strand)
2.5 mm²
Total discharge current (8/20) (L1+L2+L3+N-PE)
-
Max. overcurrent protection device, parallel connection (fuse)
25 A
Max. overcurrent protection device, series connection (fuse)
25 A
