Teknik Veriler
Ana Özellikler
Mounting method
DIN rail (top hat rail) 35 mm
With remote signalling contact
-
Number of poles
4
Voltage protection level
-
Max. continuous voltage AC
255 V
Total discharge current (8/20) (L+N-PE)
-
Nominal discharge surge current (8/20) (L-N)
3 kA
Nominal load current
25 A
Nominal voltage AC
230 V
Nominal voltage DC
-
Category type 3
evet
Voltage protection level L-N
1 kV
Voltage protection level L-PE/N-PE
1.5 kV
Signalling at the device
Optical
Max. continuous voltage DC
-
Degree of protection (IP)
IP20
With interference suppressor filter
-
Max. conductor cross section solid (solid, stranded)
4 mm²
Max. conductor cross section flexible (fine-strand)
2.5 mm²
Total discharge current (8/20) (L1+L2+L3+N-PE)
8 kA
Max. overcurrent protection device, parallel connection (fuse)
25 A
Max. overcurrent protection device, series connection (fuse)
25 A
İndirilenler

DEHNrail M surge arrester
Ürün detayları
SKU Kodu: 953400
EAN Kodu: 4013364115767
Minimum sipariş: 1
Teknik Veriler
Ana Özellikler
Mounting method
DIN rail (top hat rail) 35 mm
With remote signalling contact
-
Number of poles
4
Voltage protection level
-
Max. continuous voltage AC
255 V
Total discharge current (8/20) (L+N-PE)
-
Nominal discharge surge current (8/20) (L-N)
3 kA
Nominal load current
25 A
Nominal voltage AC
230 V
Nominal voltage DC
-
Category type 3
evet
Voltage protection level L-N
1 kV
Voltage protection level L-PE/N-PE
1.5 kV
Signalling at the device
Optical
Max. continuous voltage DC
-
Degree of protection (IP)
IP20
With interference suppressor filter
-
Max. conductor cross section solid (solid, stranded)
4 mm²
Max. conductor cross section flexible (fine-strand)
2.5 mm²
Total discharge current (8/20) (L1+L2+L3+N-PE)
8 kA
Max. overcurrent protection device, parallel connection (fuse)
25 A
Max. overcurrent protection device, series connection (fuse)
25 A
