Teknik Veriler
Ana Özellikler
Mounting method
On basic element
With remote signalling contact
-
Number of poles
1
Voltage protection level
-
Max. continuous voltage AC
60 V
Total discharge current (8/20) (L+N-PE)
2 kA
Nominal discharge surge current (8/20) (L-N)
1 kA
Nominal load current
25 A
Nominal voltage AC
48 V
Nominal voltage DC
-
Category type 3
evet
Voltage protection level L-N
0.35 kV
Voltage protection level L-PE/N-PE
0.73 kV
Signalling at the device
Optical
Max. continuous voltage DC
60 V
Degree of protection (IP)
-
With interference suppressor filter
-
Max. conductor cross section solid (solid, stranded)
-
Max. conductor cross section flexible (fine-strand)
-
Total discharge current (8/20) (L1+L2+L3+N-PE)
-
Max. overcurrent protection device, parallel connection (fuse)
-
Max. overcurrent protection device, series connection (fuse)
-
İndirilenler

Protection module for DEHNrail M surge arrester
Ürün detayları
SKU Kodu: 953012
EAN Kodu: 4013364109643
Minimum sipariş: 1
Teknik Veriler
Ana Özellikler
Mounting method
On basic element
With remote signalling contact
-
Number of poles
1
Voltage protection level
-
Max. continuous voltage AC
60 V
Total discharge current (8/20) (L+N-PE)
2 kA
Nominal discharge surge current (8/20) (L-N)
1 kA
Nominal load current
25 A
Nominal voltage AC
48 V
Nominal voltage DC
-
Category type 3
evet
Voltage protection level L-N
0.35 kV
Voltage protection level L-PE/N-PE
0.73 kV
Signalling at the device
Optical
Max. continuous voltage DC
60 V
Degree of protection (IP)
-
With interference suppressor filter
-
Max. conductor cross section solid (solid, stranded)
-
Max. conductor cross section flexible (fine-strand)
-
Total discharge current (8/20) (L1+L2+L3+N-PE)
-
Max. overcurrent protection device, parallel connection (fuse)
-
Max. overcurrent protection device, series connection (fuse)
-
