SFL-Protector multiple socket outlet for 482.6mm (19") data cabinets Zoomed Image
DEHN

SFL-Protector multiple socket outlet for 482.6mm (19") data cabinets

SFL-Protector 6X surge arrester with filter (type 3 according to EN 61643-11) with monitoring device and disconnector. Enhanced safety du to Y protective circuit. Multiple socket outlet for protecting the power supply circuit of electronic equipment against transient overvoltages as well as high-frequency interference voltages. For installation in conformity with the lightning protection zone concept at the boundaries from 1 – 2 and higher.

Ürün detayları

SKU Kodu: 909251

EAN Kodu: 4013364132573

Minimum sipariş: 1

Teknik Veriler

Ana Özellikler

Mounting method

Socket outlet strip

With remote signalling contact

-

Number of poles

-

Voltage protection level

1.6 kV

Max. continuous voltage AC

255 V

Total discharge current (8/20) (L+N-PE)

5 kA

Nominal discharge surge current (8/20) (L-N)

3 kA

Nominal load current

16 A

Nominal voltage AC

230 V

Nominal voltage DC

-

Category type 3

evet

Voltage protection level L-N

-

Voltage protection level L-PE/N-PE

-

Signalling at the device

Optical

Max. continuous voltage DC

-

Degree of protection (IP)

IP20

With interference suppressor filter

evet

Max. conductor cross section solid (solid, stranded)

-

Max. conductor cross section flexible (fine-strand)

-

Total discharge current (8/20) (L1+L2+L3+N-PE)

-

Max. overcurrent protection device, parallel connection (fuse)

-

Max. overcurrent protection device, series connection (fuse)

-
