Teknik Veriler
Ana Özellikler
Mounting method
Socket outlet strip
With remote signalling contact
-
Number of poles
-
Voltage protection level
1.6 kV
Max. continuous voltage AC
255 V
Total discharge current (8/20) (L+N-PE)
5 kA
Nominal discharge surge current (8/20) (L-N)
3 kA
Nominal load current
16 A
Nominal voltage AC
230 V
Nominal voltage DC
-
Category type 3
evet
Voltage protection level L-N
-
Voltage protection level L-PE/N-PE
-
Signalling at the device
Optical
Max. continuous voltage DC
-
Degree of protection (IP)
IP20
With interference suppressor filter
evet
Max. conductor cross section solid (solid, stranded)
-
Max. conductor cross section flexible (fine-strand)
-
Total discharge current (8/20) (L1+L2+L3+N-PE)
-
Max. overcurrent protection device, parallel connection (fuse)
-
Max. overcurrent protection device, series connection (fuse)
-
İndirilenler

Type 3 surge arrester 230V a.c. SFL-Protector multiple socket outlet
Ürün detayları
SKU Kodu: 909250
EAN Kodu: 4013364132566
Minimum sipariş: 1
