Name: DEHNtrack surge arrester Ur: 2.4kV In: 10kA line discharge class 3, d.c. type
Brand: DEHN
SKU: 990302

DEHNtrack surge arrester Ur: 2.4kV In: 10kA line discharge class 3, d.c. type Zoomed Image

DEHNtrack surge arrester Ur: 2.4kV In: 10kA line discharge class 3, d.c. type

Teknik Veriler

Ana Özellikler

Model

With screen

Height

180 mm

Application

Rated voltage AC

Continuous voltage AC

Creepage path

237 mm

Continuous voltage DC

Rated voltage DC

İndirilenler

Deeplink product page

Circuit diagram

Mounting instruction

Product data sheet

DEHNtrack surge arrester Ur: 2.4kV In: 10kA line discharge class 3, d.c. type

DEHNtrack medium-voltage arresters for protecting d.c. systems and rectifier stations against surges. They are particularly suited for installation in rolling stock, trolley buses and overhead lines. High-temperature vulcanised silicone housing for outdoor use prevents the formation of water and deposits of pollution. Long service life thanks to powerful metal oxide varistors.

Ürün detayları

SKU Kodu: 990302

EAN Kodu: 4013364103092

Minimum sipariş: 1
