| Width |
115 mm |
| Length |
240 mm |
| EFI00008 |
4.52755 |
| EFI00015 |
- |
| EFI00085 |
0.0023255813953488372093023256 |
| EFI00846 |
4.72440 |
| EFI00943 |
- |
| EFI01438 |
9.44880 |
| EFI01456 |
3.07086 |
| EFI04265 |
9.64565 |
| EFI08732 |
65.620 |
| EFI12090 |
-|- |
| EFI23518 |
1.96850 |
| Function |
Escape route lighting/signage |
| Lamp type |
LED not exchangeable |
| Lamp holder |
- |
| Height/depth |
78 mm |
| Power factor |
0.4 |
| Voltage type |
AC |
| Wiring system |
Continuous circuit/emergency circuit |
| Built-in width |
120 mm |
| Housing colour |
White |
| Material cover |
Plastic, transparent |
| Outer diameter |
- |
| Type of wiring |
Suitable for loop-through wiring |
| With pictogram |
hayır |
| Built-in length |
245 mm |
| Connection type |
Screw connection |
| Impact strength |
IK10 |
| Mounting method |
Surface mounting/recessed mounting |
| Nominal voltage |
220 - 240 V |
| Number of poles |
4 |
| Housing material |
Plastic |
| Built-in diameter |
- |
| Light distributor |
Reflector |
| Max. system power |
2 W |
| Type of indicator |
Single-sided |
| With light source |
evet |
| Battery technology |
NiCd |
| Colour temperature |
6000 - 6000 K |
| Power supply system |
Peripheral (individual battery) |
| With remote control |
hayır |
| Monitoring equipment |
Automatic self test |
| Recognition distance |
20 m |
| Type of control gear |
LED operating device current-controlled |
| Built-in height/depth |
50 mm |
| Nominal operation time |
3 - 3 h |
| Conductor cross section |
1.5 mm² |
| Flickering value Pst LM |
- |
| Number of lighting heads |
|
| Degree of protection (IP) |
IP65 |
| Exchangeable control gear |
hayır |
| Constant light output (CLO) |
evet |
| Degree of protection (NEMA) |
- |
| Suitable for labelling type |
Sticker |
| Stroboscope effect value SVM |
- |
| Luminous flux in standby mode |
- |
| With remote switch connection |
- |
| Suitable for standby switching |
- |
| Suitable for continuous circuit |
- |
| Rated life time L70/B50 at 25 °C |
- |
| Rated life time L80/B10 at 25 °C |
- |
| Suitable for number of light sources |
1 |
| LED nominal current at constant current |
|
| Protection class according to IEC 61140 |
II |
| Energy efficiency class of the built-in lamp |
A++, A+, A (LED) |
| Rated luminous flux according to IEC 62722-2-1 |
110 lm |
| Rated ambient temperature according to IEC 62722-2-1 |
|
| Lowest energy efficiency class of the exchangeable lamp |
- |
| Highest energy efficiency class of the exchangeable lamp |
- |
| Max. number of luminaires per miniature circuit breaker B16 (MCB) |
- |
| Max. number of luminaires per miniature circuit breaker C16 (MCB) |
- |
| Energy efficiency class of the provided exchangeable built-in lamp |
- |
| Failure rate at median useful life of 50,000 h at 25 °C ambient (tq) |
- |
| Failure rate at median useful life of 100,000 h at 25 °C ambient (tq) |
- |
| Lumen maintenance at median useful life of 50,000 h at 25 °C ambient (tq) |
- |
| Lumen maintenance at median useful life of 100,000 h at 25 °C ambient (tq) |
- |
| Luminaire with limited surface temperature, sign "D“ according to EN 60598-2-24 |
- |
